NiteRider Evolution Smart Bedienungsanleitung
Halogen
NiMH
USER GUIDE
Evolution Smart
NiteRider and Evolution Smart are trademarks of NiteRider, Inc.
All other trademarks are the property of their respective owners.
The information in this document is subject to change without notice.
© 2005 NiteRider, Inc. All rights reserved.
DISCOVER THE NIGHT!
Thank you for choosing the Evolution Smart™ system from
NiteRider, the innovator in technical lighting systems. The
Evolution Smart incorporates fast charging and NiteRider’s
patented “smart” battery and lamp technologies that extend
system life. The Evolution Smart system includes:
• Halogen lamp with four brightness levels and three flash
modes for safety
• Compact, lightweight nickel metal hydride (NiMH) battery
• 2.5-hour fast charger
• Fuel (battery) gauge
• Frame and helmet mounting
To get the most from your NiteRider light, we urge you to
familiarize yourself with the following safety and operation
instructions.
1
PROTECTING
YOUR INVESTMENT
When not in use, always disconnect the headlamp from the
battery. To unplug, grasp the connector, not the cable.
Properly charge your battery to maximize its lifespan
(see “Battery Charging and Care” on page 12). To avoid
damaging your system, only charge your NiteRider battery
with the appropriate NiteRider charger.
While Evolution Smart will perform in wet weather conditions,
submerging it in water will damage the system. If you need a
submersible light, NiteRider manufactures industrial-grade
dive light systems. For information, contact NiteRider Dive
Lights at 858.268.3850 or visit www.niteriderdive.com.
RIDING AT NIGHT
While the Evolution Smart will improve your control and
enjoyment of night riding, please remember that cycling at
night is an inherently dangerous activity. In addition to using
your lighting system properly and riding with extreme caution,
NiteRider urges you to:
• never ride alone
• always let someone know where you are going
• wear a helmet and reflective clothing
• carry an auxiliary light and emergency supplies.
NiteRider, Inc.
8205 Ronson Road, Suite E
San Diego, CA 92111 USA
800.466.8366
www.niterider.com
SUPPORT
If you experience difficulties during product installation or
operation, NiteRider provides free telephone support on
weekdays from 8:00 AM to 4:30 PM (Pacific Time) at
800.466.8366, ext. 4. You may also e-mail us at
support@niterider.com.
WARRANTY
NiteRider stands behind its products with the following
warranties:
• Lifetime warranty on all mechanical components
• 1 year on cables and connectors, electronic components,
and printed circuit boards
• 180 days on rechargeable batteries and fast chargers
• 60 days on halogen bulbs
To repair or replace your product while under warranty, return
it (postage prepaid and insured with original sales receipt) to
the address below. Out-of-warranty repair service is also
available. For complete warranty information, please visit our
website.
2
3
TABLE OF CONTENTS
Parts List and Identification
. . . . . . . . . . . . . . . . . . . . . . 4
Quick Start
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mounting the Headlamp
. . . . . . . . . . . . . . . . . . . . . . . . . 6
Universal Handlebar Mount . . . . . . . . . . . . . . . . . . . . . . 6
Helmet Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Inserting the Headlamp . . . . . . . . . . . . . . . . . . . . . . . . . 7
Mounting the Battery
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Frame Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pocket or Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Flash and Walking Modes . . . . . . . . . . . . . . . . . . . . . . 10
Fuel Gauge and Automatic Shut Off. . . . . . . . . . . . . . 11
Battery Charging and Care
. . . . . . . . . . . . . . . . . . . . . 12
Using the 2.5-hour Fast Charger . . . . . . . . . . . . . . . . . 12
Battery Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Smart Battery Protection . . . . . . . . . . . . . . . . . . . . . . . . 12
Storage . . . . . . . . . . . . . . . . . . . . . . . . Inside Back Cover
Run Times
. . . . . . . . . . . . . . . . . . . . . . . . Inside Back Cover
4
PARTS LIST
AND IDENTIFICATION
Please verify the contents of your Evolution Smart system:
A. 15 Watt-6 Volt halogen headlamp
B. 4.5 Ah-6 Volt NiMH battery (pocket/frame mount)
C. Charger power cord
D. Universal handlebar mount
E. 2.5-hour fast charger
F. Helmet mount
G. 36” helmet cord
H. Velcro cable tie
A
E
B
C
F
D
G
H
5
QUICK START
1. Fully charge the battery before the first use. See “Using the
2.5-hour Fast Charger” on page 12.
2. To mount the headlamp and battery, see “Mounting the
Headlamp” on page 6 and “Mounting the Battery” on
page 8.
3. Connect the battery to the headlamp.
4. To turn the light on for normal operation, press and hold the
headlamp power button for one second. Cycle through the
three brightness levels by pressing and releasing the
power button.
5. To access the flash and walking modes, see “Flash and
Walking Modes” on page 9.
6. To turn the system off, press and hold the power button for
one second.
6
MOUNTING THE HEADLAMP
The Evolution Smart headlamp can be mounted to the
handlebar or a helmet.
Universal Handlebar Mount
The Universal Handlebar Mount (UHM) is designed to fit on
virtually any handlebar. Included with the mount is a 2.5-mm
Allen wrench, a pair of black rubber bumpers already in
place, and a thin rubber shim to customize the fit on large
handlebars up to 32 mm in diameter.
Turn the knob counter-clockwise, allowing the hinge to swing
open. Place the mount on the handlebar on the left side the
stem, orienting the rectangular notch in the slider clip to the
rear. Swing the hinge down to make contact with the
handlebar. Swing the hex bolt up, seating the knob into its
recess. Turn the knob clockwise to tighten and secure the
mount to the handlebar.
The UHM can be adjusted to accommodate any handlebar
angle. By loosening the 2.5 x 30 mm Allen screw, you can
move the swing arm back and forth to straighten the
headlamp. Tighten the 2.5 x 30 mm screw after the
adjustment.
NOTCH
SWING ARM
2.5 x 30 MM
SCREW
HINGE
KNOB
HEX BOLT
SLIDER CLIP
2.5 x 12 MM
SCREW
7
To pivot the headlamp, loosen the 2.5 x 12 mm screw located
under the slider clip and swing arm and rotate the headlamp
to the desired position. Make this adjustment before
tightening the 2.5 x 30 mm screw.
Helmet Mount
1. Unclamp the straps on each
side of the helmet mount and
pull them free.
2. Position the plastic mounting
plate as close to the centerline
of the helmet as possible,
orienting the parallel grooves on
the slider clip to the rear.
3. Feed each strap into and out of
two helmet vents, circling each
strap back to the upper edge of
the corresponding clamp.
4. Fasten the straps by inserting
them into the clamps.
Inserting the Headlamp into
the Handlebar or Helmet Mount
Insert the headlamp mount into the handlebar or helmet
mount slider clip from the rear of the slider clip forward.
Gently rocking the lamp as you slide it may help. Do not push
the release lever when inserting the headlamp into the slider
clip; let the lamp snap into place by itself.
To remove the headlamp, push the release lever and slide the
lamp backward.
Note
: After mounting the headlamp, adjust the headlamp so
it illuminates the road properly without distracting oncoming
riders.
8
MOUNTING THE BATTERY
The battery can be mounted to the bike frame or placed in a
jersey pocket, hydration pack, or fanny pack.
Warning
: For safety reasons, a cyclist should never be
tethered to the bike. If the headlamp is mounted to the
helmet, do not mount the battery to the frame. Conversely, if
the headlamp is mounted to the handlebar, do not place the
battery in a pocket or pack.
Frame Mount
1. Thread the wide Velcro tie
through the slots on the top of
the battery clip.
2. Attach the concave surface of
the battery to a safe,
convenient location on the
frame (typically under the top
or down tube), placing the
Velcro strap over the tube but
under any shift or brake cables.
3. Secure the handlebar cord to
the frame using the thin Velcro
tie. Make sure the cord does
not interfere with any moving
parts.
