Norcold DE-0061 Bedienungsanleitung

PART NO.624380

NORCOLD 03/28/2007

EV0061

DE0061T

DV0061 SERIES

DE0061

PARTS LIST

DV0061 SERIES PARTS LIST - PAGE 2

DOOR - UPPER (FREEZER) - DV0061 SERIES

NO. PART # DESCRIPTION DE0061 DE0061T EV0061

1 621560 DOORLINERASSY-FOAMED/UPPER X X X

2 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK X X X

3 621519 PANEL RETAINER-BLACK/UPPER DOOR/HINGESIDE X X X

4 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK X X X

5 618619 BIN-DOOR SHELF/SMALL/WHITE X X X

6 621520 DOOR HANDLE ASSY-VERTICAL X X X

7 621518 PANEL RETAINER-BLACK/UPPERDOOR/HANDLESIDE X X X

8 618160 CAP-HINGEPLUG/BLACK X X X

NS 619569 BOLT-CAP SHOULDER/TORX HEAD X X X

NS = NOT SHOWN

DV0061 SERIES PARTS LIST - PAGE 3

DOOR - LOWER (FRESH FOOD) - DV0061 SERIES

NO. PART # DESCRIPTION DE0061 DE0061T EV0061

1 621559 DOOR LINER ASSY-FOAMED/LOWER X X X

2 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK X X X

3 621548 PANEL RETAINER-BLACK/LOWER DOOR/HINGESIDE X X X

4 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK X X X

5 623696 BIN-DOOR-LARGE WHITE X X X

6 618619 BIN-DOOR SHELF/SMALL/WHITE X X X

7 621547 PANEL RETAINER-BLACK/LOWER DOOR/HANDLE SIDE X X X

8 621520 DOOR HANDLE ASSY-VERTICAL X X X

9 618160 CAP-HINGEPLUG/BLACK X X X

NS 619569 BOLT-CAP SHOULDER/TORX HEAD X X X

NS = NOT SHOWN

DV0061 SERIES PARTS LIST - PAGE 4

CABINET ASSEMBLY - FRONT VIEW - DV0061

DV0061 SERIES PARTS LIST - PAGE 5

CABINET ASSEMBLY - FRONT VIEW - DV0061

NO. PART # DESCRIPTION DE0061 DE0061T EV0061

1 169000600 POWER SUPPLY-AC (SP-298B) X X

169000610 POWERSUPPLY-AC (SP-298A) X

2 621634 GRILL-TOP/VENTILATION X X X

3 163011300 POWER SUPPLY-DC/SP-297 X X

163011310 POWERSUPPLY-DC/SP-296 X

4 FUSE-BLADE/15 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) X X X

5 160220100 KNOB-THERMOSTAT X X X

6 623128 TRIM PIECE-SIDE/RH X X X

7 619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLACK X X X

8 618144 HINGEBUSHING-DOOR HINGE/BLACK X X X

9 618145 HINGEPIN-DOOR/PANEL DOORS/BLACK X X X

10 61630422 ICECUBETRAY-PLASTIC X X X

11 621557 STRIKEPLATE-BLACK X X X

12 621534 DRIP TRAY-INSIDE/EVAPORATOR X X X

13 621580 SHELF-WIRE/FULL X X X

14 623135 SHELF-WIRE/WITH CUTOUT X X X

NS 623121 CLAMP-SHELF RETAINING LOOP 3/8" X X X

15 617756 TRAY-SHELF/WHITE/CUT OUT X X X

16 621691 CRISPER COVER-GLASS SHELF X X X

NS 61580322 RETAINER-GLASS SHELF (NOT SHOWN) X X X

17 621692 CRISPER-DV0061 SERIES X X X

18 621573 GRILL ASSY-BOTTOM X X X

19 619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK X X X

20 623133 CHANNEL-BOTTOM RAIL X X X

21 621697 COVER-STRIKEPLATE/BLACK X X X

22 621621 HINGECAP-CENTERPOST/BLACK X X X

23 621563 HINGE-CENTER X X X

24 621620 HINGE CENTERPOST-STUD/CENTER HINGE X X X

25 623129 TRIM PIECE-SIDE/LH X X X

26 621625 DIVIDER ASSY-FOAMED X X X

NS 61629722 LAMP BRACKET ASSY X X X

NS 61628922 LAMP-GE#214-2/DC LIGHT BULB X X X

NS 621827 COVER-LAMP BRACKET X X X

NS 623119 SWITCH-CABINET LIGHT X X X

27 160929310 FANONLY-50 CYCLE/LARGE X X X

28 169000700 CIRCUIT BOARD-LIGHT CONTROL X X X

29 161013500 COOLING UNIT-DE0061/EV0061 X X X

NS = NOT SHOWN

DV0061 SERIES PARTS LIST - PAGE 6

CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0061 SERIES

DV0061 SERIES PARTS LIST - PAGE 7

CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0061 SERIES

NO. PART # DESCRIPTION DE0061 DE0061T EV0061

1 169000600 POWERSUPPLY-AC (SP-298B) X X

169000610 POWERSUPPLY-AC (SP-298A) X

2 163011300 POWER SUPPLY-DC/SP-297 X X

163011310 POWER SUPPLY-DC/SP-296 X

3 FUSE-BLADE/15 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) X X X

4 169000700 CIRCUIT BOARD-LIGHT CONTROL X X X

5 621634 GRILL-TOP/VENTILATION X X X

6 623133 CHANNEL-BOTTOM RAIL X X X

7 320101300 HOLDER-CONDENSER X X X

8 322249400 HOLDER-CONDENSER/UPPER X X X

9 160929310 FANONLY-50 CYCLE/LARGE X X X

10 161013500 COOLING UNIT-DE0061/EV0061 X X

11 621529 FOAM PLUG PANEL ASSY-EVAPORATOR ACCESS X X X

12 621570 GASKET-EVAPORATORPLUG X X X

NS 192116604 CORD WITH TERMINAL-GROUND CORD X X X

NS 190264700 COUPLER ASSY-COOLING UNIT TO EXTENSION X X X

NS 605505440 THERMISTER-EVAPORATOR X X X

NS 190282010 COUPLER ASSY-DC INPUT CORD X X X

NS FUSE-GLASS/15 AMP/DC CORD (AUTOMOTIVE SUPPLY) X X X

NS 601064730 COUPLER ASSY-DC POWER SUPPLY TO CORD/COOLING UNIT X X X

NS 601064800 COUPLER ASSY-DC POWER SUPPLY TO FAN X X X

NS 601064600 COUPLER ASSY-DC POWER SUPPLY TO THERMISTER X X X

NS - NOT SHOWN
