WARNINGSPULSE User Manual
PULSE
User Manual
PULSE User Manual 3TABLE OF CONTENTS
Warnings 4
Labels 6
Indications for Use 8
Risks and Benefits of the NormaTec PULSE Recovery System 8
Illustrations 9
Operating Instructions 13
Setup the System
Adjust the Intensity and Time
Start the Session
What to Expect
Finishing Treatment
To Stop or Pause the Session
To Turn O the Device
How to Use Zone Boost
Using the Internal Battery
Optional Settings 16
How to Adjust Rest Time
How to Change the Massage Pattern
How to Change the Number of Zones
Caring for the System 17
Cleaning the System
Maintaining the System
Storing the System
Additional Accessories and Replacement Parts
Technical Information 18
Troubleshooting 24
Warranty Information 25
NormaTec PULSE Control Unit Limited Two-Year Warranty
NormaTec Attachments and Other Accessories Limited One-Year Warranty
Return Policy 26
PULSE User Manual
Table of Contents
4WARNINGS
Read the entire instruction manual before using the NormaTec PULSE Recovery System.
• Do not attempt to take apart the system. The system has no user-serviceable parts. When service
or repairs are required, please contact customer service at 866.658.5896.
• Only use the power supply and power cord provided with the system. Using a dierent power
supply or cord may cause the system to operate incorrectly.
• To avoid risk of electric shock, do not use the system near water, such as near a bathtub, kitchen
sink, laundry tub, or swimming pool.
• Never spill liquid of any kind on the NormaTec PULSE Recovery system to avoid damage and risk
of electric shock.
• Do not place the system, cord, or any accessories where they could be damaged, present a fall
hazard, or become an obstruction to others.
• Keep the open ports of the NormaTec Control Unit, NormaTec Hose interconnect and Power Inlet
free of debris.
• If the power supply or power cord is damaged, the PULSE Control Unit is dropped or damaged,
liquid is spilled on the system, or if the system does not operate normally when the operating
instructions are followed turn the system o by pushing the PULSE Control Unit’s Power Button
and then unplugging the system from the wall outlet. Contact customer service at 866.658.5896
for assistance.
• Do not puncture or otherwise damage the inflatable Attachments (legs, arms, hips, or custom
attachments) since this may cause the system to operate incorrectly.
• Do not walk while wearing the inflatable Attachments (to avoid falling).
• The inflatable Attachments are designed to be used by only one person at a time.
• Do not use this product if you are experiencing inflammation, an infection, pain of unknown origin,
bleeding (internal or external) at or near the site of application, or if you have a wound at or near
the site of application.
• Do not use this product if you are under the care of a physician or have a contraindication
requiring the use of any medical device.
• Do not use this product on sensitive skin.
• Do not hold the unit by the NormaTec Hose.
• Do not use this product if you have any of the following conditions:
— Acute pulmonary edema
— Acute thrombophlebitis
— Acute congestive cardiac failure
— Acute infections
— Deep vein thrombosis (DVT)
— Episodes of pulmonary embolism
— Wounds, lesions, or tumors at or near the site of application
— Where increased venous and lymphatic return is undesirable
— Bone fractures or dislocations at or near the site of application
WARNINGS
5
WARNINGSPULSE User Manual
• This product contains a lithium ion battery. Dispose of this product in accordance with local
regulations.
• Do not use the PULSE Control Unit air output or NormaTec Hose to direct pressurized air towards
your eyes, nose, mouth, or ears. Doing so may lead to serious injury.
• Use without supervision by children, unconscious persons, or incapacitated persons may be
dangerous.
• Make sure the power input connector on the NormaTec Control Unit is easily accessible at all
times in order to disconnect power if required.
WARNING!
No modification of this equipment is allowed.
WARNING!
If you experience severe pain, any unusual symptoms or want to remove pressure in an emergency
during use:
• Stop the device by pressing the Power Button.
• Disconnect the Attachment connector of the NormaTec Hose from either the PULSE Control Unit
or body Attachment
• Remove the Attachment(s) from your limb(s).
• Promptly consult your licensed healthcare practitioner, as required.
The NormaTec PULSE contains a Li-Ion Battery and if discarded needs to disposed of in accordance
with local regulations.
Save this manual for future reference.
6LABELS
The following labels and symbols appear on the Control Unit, garments and/or packaging.
SYMBOL DESCRIPTION LOCATION
IP21 Degree of protection against ingress of water On base of Control Unit
Read instructions before use On base of Control Unit
Read instructions before use On Attachment tag
Level of protection type BF equipment On base of Control Unit
Double insulation On power adapter
Direct current On base of Control Unit
Alternating current In manual
Eciency level In manual
Manufacturer’s name and address On base of Control Unit and
Attachment tag
Date of manufacture On base of Control Unit
For indoor use On manual
Separate collection for waste electrical and
electronic equipment On base of Control Unit
Serial number of the console On base of Control Unit
RoHS
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
compliant
On base of Control Unit
Fragile, handle with care On package
Keep dry On package
This side up On package
Labels
PULSE User Manual 7LABELS
Keep away from sunlight On package
93%RH
10%RH
Transportation & storage humidity limitation On package
1060hPa
700hPa
Transportation & storage atmospheric pressure
limitation On package
-4ºF
-20ºC
70ºC
158ºF
-4ºF
-20ºC
70ºC
158ºF Transportation & storage temperature limitation On package
Place in and out of mode. On power button
Do not wash On Attachment tag
Do not dry-clean On Attachment tag
Do not tumble dry On Attachment tag
Do not bleach On Attachment tag
Do not iron On Attachment tag
Zone Boost icon On Control Unit
Warning symbol In manual
Tip In manual
PULSE User Manual
*Warning symbol – Used to identify a hazard that may lead to death or serious injury.
*** Tip – Used to describe guidance to make use easier. Risk to user is considered negligible.
*
**
8INDICATIONS FOR USE
& RISKS AND BENEFITS
The NormaTec PULSE Recovery System is an air pressure massager indicated to temporarily relieve
minor muscle aches and/or pains and to temporarily increase circulation to the treated areas.
The risks and benefits of using the NormaTec Recovery System are the same as having a massage. If
the massage feels uncomfortable, you can reduce the intensity or stop the session.
Similar to a massage, the benefits can include the temporary relief of minor muscle aches and pains. It
can also temporarily increase circulation in the area being massaged.
Please call customer service at 866.658.5896 if you have any questions.
Indications for use
Risks and Benefits of the Normatec Recovery System
PULSE User Manual 9ILLUSTRATIONS
PULSE CONTROL UNIT
1. Power Button
2. Time Adjustment Button (decrease)
3. Time Adjustment Button (increase)
4. Pressure Adjustment Button (decrease)
5. Pressure Adjustment Button (increase)
6. Display Screen
7. Zone Boost Button
8. Play/Pause Button
9. Air Outlet and Power Inlet
Illustrations
1
3
5
2
4
6
8
9
7
PULSE User Manual
10 ILLUSTRATIONS
NORMATEC HOSE
1. Junction Box Air Outlet
2. Junction Box Air Outlet
3. Junction Box
4. Blocking Plug (on the underside of the Junction Box)
5. NormaTec Hose Connector (connects to PULSE Control Unit)
1
35
2
4
PULSE User Manual 11ILLUSTRATIONS
LEG ATTACHMENT
1. Attachment Connector
2. Zones
ARM ATTACHMENT
1. Attachment Connector
2. Zones
1
2
1
2
