Nortel ASN Abmessungen

Retirement Bulletin

Bulletin Number: R-2006-0232-Global

Date: 01 January 2007

Multiprotocol Router Access Stack Node (ASN)

Manufacture Discontinue Notice

REVISION HISTORY

Date Revision # Summary of Changes

01 January 2007 Original bulletin This is the original publication

Last Time Order Date: April 30, 2007

Last Ship Date: May 31, 2007

Manufacture Discontinue (MD) Date: May 31, 2007

End of Life (EOL) Date: June 1, 2012

Last Supported Software Release: BayRS 15.7, 15.6, 15.4

Market Regions Affected: Global, NA, CALA, EMEA, and Asia Pacific

Introduction

The Multiprotocol Router ASN product portfolio is being discontinued by Nortel*. The last

order date is April 30, 2007 with the table below providing a list of discontinued codes. Any

Multiprotocol Router ASN order codes not listed in the table have also been discontinued.

The recommended replacement product for the Multiprotocol Router ASN is the Secure

Router 3120. Please note that the Secure Router products are IP WAN routers and do not

support legacy multiprotocol features of the BayRS family, including the Multiprotocol Router

ASN. The Secure Router 3120 provides superior price/performance with advanced features

in the areas of Routing, WAN, VPN, Security, Quality of Service and Network Management.

Technical support for the Multiprotocol Router ASN products will continue through the

normal Nortel Technical Support Center. This notice will also serve as the final EOL notice

for the order codes identified below and no additional notice will be issued.

Definition

Manufacture Discontinue (MD) – This notice serves as formal communication of Nortel

Networks’ intent to MD the product(s) noted. No further orders will be accepted as of the

Nortel Page 1 of 5

Last Time Order Date shown above and no further shipments made after the product has

been discontinued. The MD of these products should not be interpreted as the

discontinuance of any Nortel Networks agreements to support the existing field population.

Services to the existing product base will continue to be provided until the End of Life (EOL)

date shown above.

Product Overview (See Table for Detail)

SYSTEM COMPONENTS

Base Units

AF0002B03

ASN2 Base Unit 0MB AC Redundant (Includes European Schuko

power cord)

AF0002C03 ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in the UK and Ireland)

AF0002D03 ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in Japan)

AF0002E03 ASN2 Base Unit 0MB AC Redundant (Includes North American

power cord)

AF0002F03

ASN2 Base Unit 0MB AC Redundant (Includes Australian power

cord, also used in New Zealand and the PRC)

AF0002G03

ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in Denmark)

AF0002H03

ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in India/South Africa)

AF0002K03

ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in Italy)

AF0002L03 ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in Switzerland)

AF0002M03

ASN2 Base Unit 0MB AC Redundant (Includes North American

10A/220 power cord)

AF0002W03

ASN2 Base Unit 0MB AC Redundant (Includes power cord used

in Israel.)

AF0002A15 ASN2 Base Unit 16M 48V Power. (No power cord included)

AF0002A16 ASN2 Base Unit 32M 48V Power. (No power cord included)

AF0002B12 ASN2 Base Unit 16M AC Redundant Power (Includes European

Schuko power cord)

AF0002B13 ASN2 Base Unit 32M AC Redundant Power (Includes European

Schuko power cord)

AF0002C12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in the UK and Ireland)

AF0002C13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in the UK and Ireland)

AF0002D12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in Japan)

AF0002D13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in Japan)

AF0002E12 ASN2 Base Unit 16M AC Redundant Power (Includes North

American power cord)

AF0002E13 ASN2 Base Unit 32M AC Redundant Power (Includes North

American power cord)

AF0002F12 ASN2 Base Unit 16M AC Redundant Power (Includes Australian

power cord, also used in New Zealand and the PRC)

AF0002F13 ASN2 Base Unit 32M AC Redundant Power (Includes Australian

power cord, also used in New Zealand and the PRC)

Nortel Page 2 of 5

AF0002G12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in Denmark)

AF0002G13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in Denmark)

AF0002H12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in India/South Africa)

AF0002H13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in India/South Africa)

AF0002K12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in Italy)

AF0002K13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in Italy)

AF0002L12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in Switzerland)

AF0002L13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in Switzerland)

AF0002M12 ASN2 Base Unit 16M AC Redundant Power (Includes North

American 10A/220 power cord)

AF0002M13 ASN2 Base Unit 32M AC Redundant Power (Includes North

American 10A/220 power cord)

AF0002W12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord

used in Israel.)

AF0002W13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord

used in Israel.)

ASN and HRPSU Power Cords

AA0018020 Power Cord: North America (U.S., Canada, Mexico, South Korea)

15A/110-120V AC

AA0020001 Model AA0020001 15A/100V Japan (Japan)

AA002001E6 Model AA0020001 15A/100V Japan (Japan)

DRAM/Flash Memory

50027 8M DRAM to 16M DRAM ASN Field Upgrade includes 2 SIMMs to

replace all existing DRAM for 16MB operation.

AA0011001 4M Flash Card Spare – Formatted

AA0011002 8M Flash Card Spare – Formatted

AA0011005 16M Flash Card Spare – Formatted

AF0011004 16M DRAM field kit

AF0011005 32M DRAM field kit/8M or 16M to 32M field upgrade (previous

order number 50028)

LAN Network Modules

34000 Dual Ethernet Net Module

34000-S Dual Ethernet Net Module Spare

34002 Dual Token Net Module

34002-S Dual Token Net Module Spare

34010 Single 100BASE-T Net module

34010-S Single 100BASE-T Net module Spare

AF1204001 Multimode FDDI Net Module (previous order number 34003)

AF1211001 Multimode FDDI Net Module Spare (previous order number

34003-S)

WAN Network Modules

34001 Dual Sync Net Module

34001-S Dual Sync Net Module Spare

34005 ISDN BRI/Dual Sync Net Module

34005-S ISDN BRI/Dual Sync Net Module Spare (Boxed)

Nortel Page 3 of 5

34008 Quad BRI Net Module for ASN

34008-S Quad BRI Net Module Spare

50023 ASN ISDN BRI Field Upgrade/Spare

AF2104004 MCE1 Net Module for channelized E1 and ISDN PRI

AF2104006 Quad Sync Net Module (Factory Installed)

AF2104010 MCE1 Net Module for channelized E1 and ISDN PRI Spare

AF2104016 Dual MCT1 Factory Installed (requires v 11.01 Software)

AF2104020 High Speed Serial Interface (HSSI) Net Module (requires v12.0

software)

AF2111001 Dual MCT1 Field Upgrade (requires v 11.01 Software)

AF2111005 Quad Sync Net Module Spare

AF2111006 High Speed Serial Interface (HSSI) Net Module Field Upgrade

(requires v12.0 software)

Optional Modules

34007 SPEX-Hot Swap Net Module

34007-S SPEX-Hot Swap Net Module Spare

7166 SPEX-Hot Swap Cable

AA0004001 ASN2 Fast Packet Cache - Factory Installed

AA0011004 ASN2 Fast Packet Cache – Spare

AF2104007 32-Contexts Hardware Compression co-processor Net Module

AF2104012 128-Contexts Hardware Compression co-processor Net Module

AF2104013 128-Contexts Hardware Compression co-processor Net Module -

Spare

AF2104015 32-Contexts Hardware Compression co-processor Net Module -

Spare

Options for Redundant Power Supply

AA0002001 HRPSU Base Unit Single AC input

AA0005003 HRPSU Power Module AC 200watt (24-pin)

AA0011029 HRPSU Rack Mount Replacement Kit

AA0018016 HRPSU output cable 200watt (24-pin)

AA0018017 HRPSU output cable 130watt (16-pin)

AA0018018 HRPSU output adapter 16-pin cable(s) to single base unit

Options

AF0011024 ASN2 Rack Mount Replacement Kit

Software Dependencies

Software support on the product will continue per Nortel support policy. BayRS 15.7 will

continue to be fully supported for one year after manufacture discontinuation and limited

support for four more years after full support ends. BayRS 15.6 and 15.4 will continue to

have limited support for five years after manufacture discontinuation.

Alternative/Replacement Products/Solutions

The recommended replacement product for Multiprotocol Router ASN is the Secure Router

3120. Please note that Secure Router products are IP WAN routers and do not support

legacy multiprotocol features of the BayRS family, including the Multiprotocol Router ASN.

The Secure Router 3120, however, provides superior price/performance with advanced

Nortel Page 4 of 5

features in the areas of Routing, WAN, VPN, Security, Quality of Service and Network

Management.

Related Product and Sales & Marketing Bulletins (if applicable)

Not applicable.

Customer Actions

Customers are advised to consider this notification in conducting last time buys or planning

a product replacement with the Nortel Secure Router 3120 family. For more information,

please contact your Nortel Networks account representative. Content herein is not intended

to supercede existing customer contractual commitments.

*Nortel, the Nortel logo and the Globemark are trademarks of Nortel.

Nortel Networks Limited. All other trademarks are the property of their respective owners.

The information in this document is subject to change without notice. Nortel reserves the right to make changes, without notice,

in equipment design as engineering or manufacturing methods may warrant. The statements, configurations, technical data,

and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied

warranty. Users must take full responsibility for their applications of any products specified in this document. The information in

this document is proprietary to Nortel Networks Limited.

To view the most recent version of this bulletin, please visit Nortel’s Partner Information Center on the web at:

http://www.nortel.com/pic.

Nortel Page 5 of 5
