Novus NVC-230C Bedienungsanleitung

USER`S MANUAL VER. 1.0

COLOR CAMERA

NVC-230C

NOVUS SECURITY Sp. z o.o.

359 Pulawska Str., 02-801 Warsaw, Poland

tel: +4822-546-0-500; fax: +4822-546-0-519

[email protected]; www.novuscctv.com

NVC-230C color camera user’s manual, v.1.0

COLOR CCD CAMERA

Operating Instructions

CAUTION

1. Please use correct power adaptor, AC24V (regulated), to operate this unit. The power tolerance of

this unit is AC 24V ± 10% (AC21.6V~26.4V), over maximum AC26.4V power input will damage this

unit.

2. Video output (BNC connector) of this unit can be only connected to monitor. Please check the

wiring of video output before power on. If the power is offered through video output, the unit will be

damaged.

1. Do zasilania kamery należy użyćwłaściwego zasilacza prądu stałego : AC24V (regulowane).

Tolerancja napięcia dla tej kamery wynosi: 24 VAC ± 10 % (21.6 -26.4 VAC).Przyłożenie do kamery

napięcia większego od dopuszczalnego tj. powyżej 26.4 VAC, może spowodowaćuszkodzenie kamery.

2. Wyjście wizyjne kamery (BNC) można połączyćwyłącznie z właściwymi wejściami urządzeńCCTV

Przed połączeniem kamery z innymi urządzeniami CCTV należy sprawdzićokablowanie. Jeśli wraz z

wizjązostanie podany inny sygnał, o napięciu większym niż1 V p-p, kamera może ulec uszkodzeniu.

1. Por favor use el correcto adaptador de energía eléctrica AC24V (regulado) para operar esta

unidad, La tolerancia de energía de esta unidad es de AC24V ± 10% (AC21.6V~26.4V). Sobrepasar el

máximo de AC26.4V de la potencia de entrada dañara esta unidad.

2. La potencia de salida del video (Conector BNC) de esta unidad puede ser solo conectado al

monitor. Por favor revise los cables del video antes de encenderles. Si la energía es dada por la

potencia de salida del video, la unidad se dañara.

1. Bitte schließen Sie das Gerät an das Netzgerät (AC24V) an. Die Toleraz der Stromversorgung ist

24V AC ± 10% (AC21.6V~26.4V). Abweichende Werte können zu Beschädigungen am Gerät führen.

2. Verbinden Sie den Video-Ausgang (BNC-Anschluß) mit dem Video-Eingang des Monitors. Bevor

Sie die Spannungsversorgung einschalten, überprüfen Sie Bitte den korrekten Anschluß des Video-

Ausgangs. Falsche Anschlußbelegungen können zu Beschädigungen an den Geräten führen.

NVC-230C color camera user’s manual, v.1.0

Thank you for choosing this high quality camera, before attempting to connect or operate this product,

please read these instructions completely and carefully.

COLOR CCTV CAMERA OPERATING MANUAL

SPECIFICATIONS

Pick up Element 1/3" Panasonic Color CCD image sensor

Number of Pixel 512(H) x 582(V) <PAL>

Resolution 420 TV lines

Min. Illumination 0.5 Lux / F1.2

S/N Ratio More than 48dB (AGC off)

Gamma 0.45

Electronic Shutter 1/50 to 1/100,000 sec.

Iris Mode V.D. / D.D. / AES selectable

Video Output 1.0Vp-p composite,75 Ohm

Lens Mount C/CS mount changeable

White Balance Hold / ATW selectable

Back Light Compensation On / Off

Sharpness Soft / Sharp selectable

Microphone Yes

Power Source AC24V±10% / 0.2 A

Power Consumption 3 W

Dimension (mm) 118(L) x 62(W) x 50(H)

Weight 370 g

WARNING:

TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

NVC-230C color camera user’s manual, v.1.0

GENERAL

This color CCD video camera equipped with a 1/3” Panasonic CCD (charge coupled device)

providesextremely long life and high reliability. The camera provides more than

420TV lines resolution and different view angle of lenses are selectable. Microphone is also

designed for this 24 hours standby surveillance camera.

FEATURES

1. Horizontal resolution of 420 TV lines.

2. Built in Auto Electronic Shutter.

3. Minimum illumination of 0.5Lux/F1.2.

4. Signal-to-noise ratio of 48dB.

5. Long life and high reliability.

Major Operating Control and Functions

1. Flange Back Adjustment Ring

Suitable for CS-mount lens, When use C-mount lens, please use the CS-C conversion Ring.

2. Back focal lock screw

The camera is set at the standard back focal position. Depending on types of lenses, however slight

adjustment may be necessary. Adjust the lens back-focus by turning the focusing knob.

3. Auto iris Lens Connector Supplies power and control signals to an auto iris lens.

SOFT

HOLD

BLC

SHARP

ATW

OFF

AES

AUTO IRISAC 24V

PL 2

V.D. D.D.

LEVEL

VIDEO AUDIO

NVC-230C color camera user’s manual, v.1.0

4. DC Drive Level Adjustment

When you use a Direct Drive Lens, you can adjust the DC Drive Level for the bright of video output.

5. Power LED Indicator

The Power LED Indicator indicates normal during operation.

6. AC24V Input Terminal

This terminal is for connecting the 24V AC power supply.

7. Video Output Connector (VIDEO OUT)

This connector is for connecting with the VIDEO IN connector of the video monitor.

8. Selectors: AES/AI, BLC/OFF, SOFT/SHARP, HOLD/ATW

AES/AI Allows you to select the mode according to the lens type that is used with this camera.

AES: Select this mode when a fixed iris lens or manual iris lens is used with this camera.

AI: Select this mode when an auto iris lens is used with this camera.

BLC/ OFF BLC -Back Light Compensation

ON: Allows to enhance the foreground object on strong light condition

OFF: To be used on standard light condition

SOFT/SHARP Allows to choose the view contours sharpness

HOLD/ATW White balance. Two selectable modes.

HOLD: It is advised when the White Balance has to be constant.

ATW: used in most applications

9. IRIS V.D./D.D. Selector

Lets you select the mode according to the lens type that is used with this camera.

V.D.：Select this mode when a VIDEO Drive auto iris lens is used with this camera.

D.D.：Select this mode when a Direct Drive auto iris lens is used with this camera.

10. Audio Output Connector (AUDIO OUT)

This connector is for connecting with the AUDIO IN connector of the video monitor.

CONNECTIONS

1. Mount a lens onto the camera.

2. Set the lens selection switch (AES/AI).

3. Connect a video terminal of the camera (VIDEO) and the video input terminal of the video monitor

with a 75 Ohm coaxial cable.

4. Connect an audio terminal of the camera (AUDIO) and the audio input terminal of the video

monitor.

5. Connect the power terminal of the camera to a 24V AC regulated power supply.

NVC-230C color camera user’s manual, v.1.0

Installation of Auto Iris Lens Connector

Install the lens connector when using a Video drive lens.

The installation should be made by qualified service personnel or system installers

Cut the iris control cable at the edge of the lens connector to remove the existing lens connector and

then remove the outer cable cover of the supplied connector as shown in the diagram.

The pin assignment of the auto iris lens connector is as follows:

VIDEO DC

Pin 1 Power source Damp -

Pin 2 Video signal Damp +

Pin 3 Not used Driver +

Pin 4 Ground, Shield Driver -

Solder the lens cable to the pins of the supplied connector

Focus or Flange-Back Adjustment

The following adjustment should be made by qualified service personnel or system installers.

1. Mount the lens by turning it clockwise on the lens mount of the camera.

2. Loosen the screws on the flange-back adjusting ring.

3. Turn the flange-back adjusting ring to the desired position.

4. Tighten the screws on the flange-back adjusting ring.

Standard Accessories

Main body *1

HEX wrench *1

C mount adaptor ring * 1

Iris header *1

Instruction manual *1

NOVUS SECURITY Sp. z o.o.
