NTI VOPEX-C5V-x Bedienungsanleitung

1MAN072 Rev 7-24-06

VOPEX-C5VA-x

VOPEX-C5V-x

VOPEX-C5SVA-x

VOPEX-C5SV-x

VOPEX-C5HDTV-x

VOPEX-C5HDA-x

VIDEO/AUDIO or VIDEO ONLY

SPLITTER/EXTENDER

Quick Installation Guide

The VOPEX Series Cat5 Video/Audio Splitter/Extender (VOPEX) is designed to enable one Video/Audio source to be viewed and

heard in 4, 8, or 16 different remote locations. Remote video and audio devices can be located as much as 600 feet away from the

source via Category 5 unshielded twisted-pair cable. The VOPEX also allows a local video and audio device to be located near the

source.

Position the VOPEX such that all connections can be made without straining the cables. The CAT5 cables should be routed away

from any sources of magnetic fields or electrical interference that might reduce the quality of the video and audio signals (i.e. AC

motors, welding equipment, etc.).

Materials Included with this kit:

¾VOPEX-C5VA-x / -C5V-x / -C5SVA-x / -C5SV-x / -C5HDTV-x / -C5HDA-x (one of these)

¾120VAC or 240VAC at 50 or 60Hz-9VDC/1.5A AC Adapter

¾Line cord, country specific

¾CD with a pdf file of this manual and pdf file of the Quick Installation Guide

¾This Quick Installation Guide

Additional materials Included:

For Model Video Cable Stereo plug Cable

VOPEX-C5VA-x VEXT-3 SA-3-MM

VOPEX-C5V-x VEXT-3 Not applicable

VOPEX-C5SVA-x SVEXT-3-MM SA-3-MM

VOPEX-C5SV-x SVEXT-3-MM Not applicable

VOPEX-C5HDTV-x CMPSAEXT-1.5-MM (see image-right)

Legend:

•x= 4, 8, or 16 for number of ports

•MM- indicates male-male connectors

•VEXT-3- 15HD male-female video cable for connecting the VOPEX to the video source

•SA-3-MM 3.5mm stereo plug -stereo plug cable for connecting the VOPEX to the audio source

•SVEXT-3-MM 4-pin miniDIN male-male s-video cable- for connecting the VOPEX-C5SVA / -C5SV-x to the video source

OPEX

Series

(Receiver not included)

(Viewed with the

cable laid flat)

Component

Video

connectors

Stereo Audio

connectors

CMPSAEXT-1.5-MM

2MAN072 Rev 7-24-06

•CMPSAEXT-1.5-MM 5-in-1 coax cable (3-75 ohm component video and 2-RCA stereo)-for connecting VOPEX-C5HDTV-x to the

audio and video source

Installation

1. Connect a video cable between the "Video" or "INPUT" ("Y Pb Pr") connectors and the video source.

2. Connect an audio cable between the "Line In" or "INPUT" ("L" and "R" or "Digital") connectors and the audio source.

3. Connect a local video device to the "Monitor" or "LOCAL OUTPUT" ("Y Pb Pr") connector.

4. Connect a local audio device to the "Line Out" or "LOCAL OUTPUT" ("L" and "R" or "Digital") connector.

5. Connect one end of a CAT5 cable to a "Cat5" port on the VOPEX and the other end to the "Cat5" port on an XTENDEX Receiver

9VDC

1.5A

-+876543 2 1

Line

Out

Line

Cat5

Video

Moni tor

NTI NETWORK

TECHNOLOGIES

INCORPORATED

Tel :33 0 -5 62 -70 7 0

Fax: 33 0-562- 199 9

1275 Dann er Dr

Aurora,OH 44202

www.nti1.com

VOPEX-C5VA-8

(Rear View)

VEXT-3

(supplied)

SA-3-MM

(supplied)

9VDC

1.5A

-+87654321

Line

Out

Line

Cat5

NTI NETW ORK

TECHN OL OG IES

INCORPO RATED

Tel:330-562-7070

Fax :33 0 -5 62- 199 9

1275 Dann er Dr

Aur or a, OH 44 20 2

www.nti1.com

S-VinS-Vout

VOPEX-C5SVA-8

(Rear View)

SA-3-MM

(supplied)

SVEXT-3-MM

(supplied)

To Digtal

Audio Source

9VDC

1.5A

-+8765432 1

Cat5

NTI NETWORK

TECHNOLOGIES

INCORPORATED

Tel:330-562-7070

Fax:330-562-1999

1275DannerD r

Aurora,O H 44202

ww w. nt i1 .co m

INPUT LOCAL OUTPUT

YPb Pr YPbPr

Digital Dig ital

VOPEX-C5HDA-8

(Rear View)

coax cable

for digital

audio

75 ohm RCA

cables

To HD Video

Source

9VDC

1.5A

-+876543 21

Line

Out

Line

Cat5

Video

Mon itor

NTI NETWORK

TECHNOLOGIES

INCORPORATED

Tel :3 3 0-5 6 2 -70 70

Fax : 33 0- 5 62- 199 9

1275 Dann er Dr

Aurora,OH 44202

www.nti1.com

VOPEX-C5VA-8

(Rear View)

VGA

Multi-Scan

Monitor

Local User's Monitor and Speakers

CAT5 cable to

Receiver

9VDC

1.5A

-+876543 21

Cat5

NTI NETWORK

TECHNOLOGIES

INCORPORATED

Tel:330-562-7070

Fax:330-562-1999

1275Danner D r

Aurora,OH 44202

www. nti1 .c om

INPUT LOCAL OUTPUT

YPb Pr YPbPr

Digit al Dig it al

VOPEX-C5HDA-8

(Rear View)

coax cable

for digital

audio

75 ohm RCA

cables

Digital Audio

Receiver

HDTV

CAT5 cable to

Receiver

9VDC

1.5A

-+87654 3 2 1

Cat5

NTI NETWORK

T ECH NO L O GIE S

INC ORP OR ATED

Tel:330-562-7070

Fax : 33 0-56 2- 19 99

1275 D anner Dr

Aurora, OH 4 4202

w ww. nti1 .c o m

INPUT LOCAL OUTPUT

RLYPbPr RLYPbPr

VOPEX-C5HDTV-8

(Rear View)

To HD Video

Source

To Stereo

Audio Source

CMPSAEXT-1.5-MM

(supplied)

3MAN072 Rev 7-24-06

Green Power LED

ellow Traffic LED

CAT5 Cable to

VOPEX

ST-C5HDTV-600 Receiver

(Rear View)

NTI R

Netw ork Tech nologies Inc

XTENDEX

(Front View)

NTI R

Netw ork Tech nologies Inc

XTENDEX

ST-C5HDTV-600 Receiver

HDTV

Stereo

Speakers

Self-Powered

Amplifier

Remote Television

6. Attach video and audio devices to the XTENDEX Receiver(s)

7. Attach the 9VDC 1.5A power supply to the VOPEX, and the 9VDC 1.0A

power supply to the Receiver.

8. Power up all devices, the VOPEX, and the Receiver.

WARNING: Never connect the VOPEX-C5VA-x Extender/Splitter to an Ethernet card, Ethernet router, hub or

switch or other Ethernet RJ45 connector of an Ethernet device. Damage to devices connected to the Ethernet may result.

Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should

not be run underground, outdoors or between buildings.

WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.

For more details, specifications, and troubleshooting tips, see the Installation and Operation Manual or go to

www.networktechinc.com.
