Ocean Matrix OMX-01DVDV0001 Bedienungsanleitung

Rev1a

Ocean Matrix

812 Kings Highway •Saugerties, NY 12477

www.oceanmatrix.com

Specifications

Transmission Distance up to 1080p@60 Hz up to 328 feet over Cat 5e/6

Bandwidth 1.65Gbps

Dimensions Each Unit 3-3/8 x 2-1/2 x 7/8 Inches

Weight Each Unit 5.3 oz

Includes 1- Transmitter, 1-Receiver, 12VDC/1A Locking Power Supply,

4-Mounting Brackets, 8-Screws

DVI Monitor

Typical Configuration

DVI Source Transmitter Receiver

DVI

Cable

INSTALLATION & SPECIFICATIONS

OMX-01DVDV0001

1080p/60 DVI Video Monitor Signal Extender Kit

1 DVI Output Connector

2 Cat 5e/6 Input

3 Cat 5e/6 Indicator LED

4 12 VDC Power Input Jack

5 Power Indicator LED

1 DVI Input Connector

2 Cat 5e/6 Output

3 Cat 5e/6 Indicator LED

4 12 VDC Power Input Jack

5 Power Indicator LED

2 5 43

2 5

TRANSMITTER RECEIVER

Cat5e/6

Cable DVI

Cable

Note: Connect a power supply to either the transmitter or the receiver, not both.

Rev1a

Ocean Matrix

812 Kings Highway •Saugerties, NY 12477

www.oceanmatrix.com

SAFETY PRECAUTIONS

 To prevent fire or shock hazard, do not expose this equipment to dust or high humidity. Do not use in an

unprotected outdoor installation or in areas classified as overly damp or wet.

 The installation temperature should be kept between 32°F to 140°F (0°C to 60°C). Avoid direct sunlight exposure or extreme

changes of temperature over a short period of time.

 Do not place the unit on an unstable base and avoid heavy impact.

 Proper ventilation is required for permanent installation. Do not block or cover enclosure openings as they protect the unit from

overheating.

 Prior to cleaning, turn the power off and unplug the unit from all connections. Use a damp cloth. Do not use liquid or aerosol

cleaners.

 Do not overload outlets and extension cords as this may result in a risk of fire or electric shock.

 Enclosure entry is dangerous. Never push objects of any kind, including liquids, through openings as they may touch dangerous

voltage points or short-out parts that could result in a fire or electric shock.

 Do not open or service this unit yourself as opening or removing covers may expose you to dangerous voltage and other hazards.

 There are no user-serviceable parts inside the unit. If the unit requires service contact your authorized dealer, or authorized repair

service company.

FCC Caution

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

Class A Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Federal Communications Commission (FCC) Compliance Notices
