Oki C9650n Service-Handbuch

Contents

Replacement Supplies ........5

Purchasing Information ............ 5

Part Numbers .......................... 5

Using the Printer Menu ......7

Changing Settings ................... 7

Menu Summary ....................... 8

Changing Paper (Media)

Settings ............................... 9

Changing Default Settings .......10

Print Media ......................11

Paper Weight .........................11

Loading Trays 1–5 ..................13

Loading the MP Tray ...............14

Exit Paths ........................16

Face Down (Top Exit) ..............16

Face Up (Side Exit) .................17

Recommended Media .......18

Paper ....................................18

Card Stock ............................18

Labels ...................................19

Envelopes .............................19

Transparencies .......................19

Paper (Media) Jams ........ 20

Tray Side Cover .....................21

Printer Side Cover ..................22

Printer Top Cover ...................23

Duplexer ...............................27

Maintenance ................... 30

Cleaning the LED Heads ..........30

Cleaning the Paper Tray

Feed Rollers .........................32

Reports ........................... 36

Printing Reports .....................36

Error Messages ............... 37

Help Button ...........................37

Service Information ........ 38

Table des matières

Fournitures de

remplacement ..................39

Renseignements concernant

les achats ............................39

Numéros de pièce ...................40

Utilisation du menu

d'impression ....................41

Modifier le paramètres ............41

Sommaire du menu ................42

Modification des paramètres

papier .................................43

Modification des paramètres

par défaut ...........................44

Support d'impression .......45

Grammage des supports .........45

Chargement des plateaux

1-5 .....................................47

Chargement du bac

multifonction .......................48

Sorties .............................50

Face vers le bas

(sortie du dessus) .................50

Face vers le haut

(sortie latérale) ....................51

Supports recommandés .. 52

Papier ...................................52

Cartonné ...............................52

Étiquettes ..............................53

Enveloppes ............................53

Transparents .........................53

Bourrages papier

(support) ........................ 54

Couvercle latéral de bac ..........55

Couvercle latéral

de l'imprimante ....................56

Capot supérieur

de l'imprimante ....................57

Unité recto verso ....................61

Entretien ......................... 64

Nettoyage de la matrice

à DEL ..................................64

Nettoyage des rouleaux d'alimen-

tation du plateau de papier ....66

Rapports ......................... 70

Impression de Rapports ..........70

Messages d'erreur ........... 71

le bouton Help .......................71

Information de service .... 72

Contenido

Suministros de repuesto ..73

Información de compras ..........73

Número de partes ..................73

Cómo utilizar el menú de la

impresora ........................75

Cambiar configuración ............75

Resumen del menú .................76

Cómo cambiar la configuración

del papel .............................77

Cambio de los valores

predeterminados ..................78

Medios de impresión ........79

Gramaje del papel ..................79

Bandejas de papel 1-5 ............81

Cómo cargar papel en la

Bandeja multiuso ..................82

Rutas de salida ................84

Cara Abajo (Salida superior) ....84

Cara Arriba (Salida lateral) ......85

Medios de impresión

recomendados .................86

Papel ....................................86

Cartulina ...............................86

Etiquetas ...............................87

Sobres ..................................87

Transparencias .......................87

Atascos de papel

(Medios) .......................... 88

Tapa lateral de la bandeja .......89

Tapa lateral de la impresora .....90

Tapa superior de la

impresora ............................91

Unidad duplex ........................95

Mantenimiento ................ 98

Limpieza de la Cabezales

LED ....................................98

Limpieza de los rodillos de

alimentación de las bandejas

de papel ............................100

Informes ........................104

Cómo imprimir los informes ...104

Mensajes de error ..........105

el tecla Help ........................105

Información sobre los

Servicios de apoyo al

cliente ............................106

Sumário

Suprimentos de

reposição .......................107

Informações para compra ..... 107

Números dos componentes ....107

Utilização dos menus da

impressora ....................109

Altere as configurações .........109

Resumo dos menus ..............110

Alteração das configurações

do papel (mídia) .................111

Alteração das configurações

padrão ..............................112

Mídia de impressão ........113

Gramatura do papel ..............113

Carregamento das bandejas

1 a 5 ................................115

Carregamento da bandeja

multifuncional ....................116

Percursos de saída .........118

Face para baixo

(Saída superior) .................118

Face de impressão para cima

(Saída lateral) ....................119

Mídia de impressão

recomendada .................120

Papel ..................................120

Cartão ................................120

Etiquetas .............................121

Envelopes ...........................121

Transparências .....................121

Atolamentos de mídia ....122

Tampa lateral da bandeja ......123

Tampa lateral da impressora...124

Tampa superior da impressora 125

Unidade duplex ....................129

Manutenção ...................132

Limpeza do pente de LEDs .....132

Limpeza dos roletes de alimentação

da bandeja para papel .........134

Relatórios ......................138

Impressão de relatórios .........138

Mensagens de erro .........139

Botão Help ..........................139

Informações sobre

assistência técnica .........140

Replacement Supplies

Purchasing Information, Part Numbers

Where to Purchase

• Consult the dealer where you

purchased your printer

• Consult an Oki Data Authorized

Sales or Service Dealer. For the

nearest dealer, call

1-800-654-3282.

•U.S., Puerto Rico, Guam, U.S.

Virgin Islands only: Order on the

Internet at

www.okiprintingsolutions.com

•U.S. only: Order toll-free at

1-800-654-3282, using VISA

MasterCard

or AMEX

• Check office supply catalogs.

Use Oki Supply Manager

• Calculates your usage based on

information you provide.

• Sends you an E-mail when it’s time

to reorder.

To register, go to

www.okiprintingsolutions.com

Part Numbers

Important!

Consumables designated “C9000

Series” do not work with these printers.

Use only Type C7 Toner Cartridges and

Image Drums having the part numbers

listed below.

Toner Cartridges, Type C7

Color OKI Part #

Black............................ 42918984

Cyan ............................ 42918983

Magenta ....................... 42918982

Yellow........................... 42918981


Image Drums, Type C7

Color OKI Part #

Black............................ 42918168

Cyan ............................ 42918167

Magenta ....................... 42918166

Yellow........................... 42918165

Other Items

Item OKI Part #

Fuser ()........... 42931701, 120V

.......... 42931702, 230V

Transfer Belt ().......... 42931601

Toner Waste Bottle ......... 42869401




1f.tif, 2f.tif

Replacement Supplies

Part Numbers (cont.)

Using the Printer Menu

Changing Settings

1. Press

Enter

2. Use the

∇

key to scroll down to the

Function you wish to change.

3. Press

Enter

4. Continue to use the

∇

and

Enter

keys to drill down to the item you

wish to change.

5. Use the

∇

key to move down to the

setting you wish to engage.

6. Press

Enter

An asterisk appears next to the

setting.

7. Press

ON LINE

to exit the Menu

mode.

For more information, see the on-line

User's Guide on the Documentation

CD provided with your printer or at

http://my.okidata.com

C96_Ready


C96_Fu

nctions_

Menu_a.

jpg

– Configuration

•Page Count, Supplies Life

•Network and System Settings,

etc.

– Print Information

•Printer & Network Configurations

•Print Demo Page

•Lists, etc.

– Print Secure Job

(Password Protected)

Appears only if the Hard Disk

Drive (HDD) (optional on Models

C9650n and C9650dn) is

installed.

•Print out confidential documents

downloaded to the HDD

–Menus

•Set the size, weight and type of

media for the various feed trays

– Admin Setup

(Password Protected)

•Various Network Setups

•Print Setup

•PS and PCL Setups

•IBM and Epson Setups

•Color Setup

•Memory and Flash Memory

Setups

•HDD and System Setups

•Reset/Save/Restore Settings

– Calibration

•Density adjustments

•Registration

•Color tuning

– Print Statistics

(Password Protected)

Using the Printer Menu

Menu Summary

Why Change?

Wrong media settings can cause:

• poor quality printing

•flaking

• damage to the printer

Media Weight

The default media weight setting for

all trays is AUTO.

Individual Print Jobs

If you are using special media for only

one print job, you can adjust the

media settings in the driver. Load the

media in the appropriate tray (usually

the MP tray). In your application, click

File

→

Print and adjust the media

settings as necessary.

All Print Jobs (Defaults)

1. Press

Enter

∇

key

→

Menus. Press

Enter

3. With Tray Configuration

highlighted, press

Enter

∇

key

→

tray to be configured.

Press

Enter

5. Use the

∇

and

Enter

keys to scroll

through the submenus and to make

your setting changes.

6. Press

ON LINE

to exit the Menu

Mode.

Using the Printer Menu

Changing Paper (Media) Settings

Andere Handbücher für C9650n

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Oki Multifunktionsdrucker Handbücher

Oki

Oki CX 1145 MFP Bedienungsanleitung

Oki

Oki MC852 Montage- und Wartungsanleitung

Oki

Oki MC363 Einrichtungshandbuch

Oki

Oki C9800hdn Bedienungsanleitung

Oki

Oki B2500 MFP Schulungshandbuch

Oki

Oki CX4545 MFP Bedienungsanleitung

Oki

Oki C9300dn Bedienungsanleitung

Oki

Oki MC332dn Installationsanleitung

Oki

Oki CX4545 MFP Konfigurationshandbuch

Oki

Oki CX2033MFP Bedienungsanleitung

Oki

Oki CX2731MFP Bedienungsanleitung

Oki

Oki MC360 MFP Bedienungsanleitung

Oki

Oki CX 1145 MFP Konfigurationshandbuch

Oki

Oki C5550 MFP Bedienungsanleitung

Oki

Oki MPS4700mb Originalbetriebsanleitung

Oki

Oki ES9160 MFP/ES9170 MFPES9460 MFP Bedienungsanleitung

Oki

Oki MPS4200mb Kurzanleitung

Oki

Oki CX3641 MFP Gebrauchs- und Pflegehandbuch

Oki

Oki C9800hdn Schulungshandbuch

Oki

Oki MC573 Einrichtungshandbuch

Oki

Oki MC860 MFP Kurzanleitung

Oki

Oki MC760 Bedienungsanleitung

Oki

Oki MC780fx Bedienungsanleitung

Oki

Oki MC361dn Bedienungsanleitung

Beliebte Multifunktionsdrucker Handbücher anderer Marken

Triumph Adler

Triumph Adler DC 2016 Handbuch

Epson

Epson WorkForce WF-2510 Benutzerhandbuch

Epson

Epson Stylus Scan 2000 Installations- und Betriebshandbuch

Epson

Epson PictureMate Snap PM 240 Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub C35 Bedienungsanleitung

Brother

Brother MFC-J430w Bedienungsanleitung

Konica Minolta

Konica Minolta BIZHUB 558 Bedienungsanleitung

Lexmark

Lexmark MX710 Series Handbuch

Brother

Brother MFC-9760 Bedienungsanleitung

Lexmark

Lexmark XC8155 Bedienungsanleitung

Lexmark

Lexmark X642E Bedienungsanleitung

Sharp

Sharp MX-2310U Leitfaden

Aficio

Aficio 200 Bedienungsanleitung

Canon

Canon ImageCLASS 2300 Handbuch

Ricoh

Ricoh Pro C900 Bedienungsanleitung

Lexmark

Lexmark X925 Bedienungsanleitung

Brother

Brother Business Smart MFC-J4510dw Bedienungsanleitung

Epson

Epson Stylus CX8400 Series Bedienungsanleitung
