Oki B 6100 Bedienungsanleitung

Network Interface Card

Installation Guide:

for OKI B6100 Printer

07039201 Iss. 01

2Ethernet Network Interface Card Configuration Guide

The information in this guide may change without notice. The manufacturer assumes no responsibility for any

errors which may appear in this guide.

OKI, OkiLPR and OkiLAN are registered trademarks of Oki Electric Industry Company, Ltd. DEC,

thickwire, thinwire, VMS, VT100, and ULTRIX are trademarks of Digital Equipment Corporation. UNIX is

a registered trademark of The Open Group. Ethernet is a trademark of XEROX. NetWare is a trademark of

Novell Corp. AppleTalk, Chooser, and Macintosh are trademarks of Apple Computer Corp. Windows NT

used with permission.

in any form or by any means without the written permission of the manufacturer.

Ethernet Network Interface Card Configuration Guide 3

About this Manual

This manual is organized in the following chapters and appendices:

Chapter 1 Introduction

This chapter describes the functionality and physical characteristics of the Ethernet Network Interface Card

(NIC).

Chapter 2 Ethernet Network Interface Configuration

This chapter will familiarize you with the configuration requirements for your NIC in a variety of different

environments to include AppleTalk, Local Area Transport (LAT), Netware and TCP/IP.

Chapter 3 Ethernet Network Interface Card (NIC) Installation

This chapter explains the procedure for installing the Ethernet Network Interface Card.

Chapter 4 Network Utility Software

This chapter provides information on network utility software included with your printer.

Appendix A Troubleshooting

This appendix offers various troubleshooting procedures and technical support advice.

Appendix B Frequently Used Commands

This appendix lists some of the most frequently-used commands of the Print Server command set.

◆◆◆

Ethernet Network Interface Card Configuration Guide 4

Chapter 1

Introduction

In this Chapter. . .

•“About this Chapter” on page 1-2

•“Product Description” on page 1-2

•“Physical Characteristics” on page 1-2

•“Protocols Supported” on page 1-3

1-2 Ethernet Network Interface Card Configuration Guide

About this Chapter

This chapter describes the functionality and physical characteristics of the Ethernet Network Interface Card

(NIC).

Product Description

The Ethernet Network Interface Card (NIC) is an internal multiprotocol print server that provides shared

network access to the printer for a variety of network protocols and operating systems. The NIC supports

the following protocols: TCP/IP, AppleTalk (EtherTalk), Local Area Transport (LAT), and IPX (NetWare).

The NIC can queue multiple pending jobs and service those jobs in the order that they are received from the

hosts.

Physical Characteristics

The front panel of the Ethernet NIC has a TEST/RESET button and four LEDs. The NIC supports

10BasetT and 100BaseT using an RJ45 connector for shielded and twisted pair standard Ethernet cabling.

Number Description

1TEST/RESET button - when pressed briefly while powering up the unit, returns

the NIC to its original factory default configuration.

2NIC LED - blinks yellow quickly at power on and slowly during normal operation

to show unit is functioning.

3BNC - Lights solid green to when a valid BNC network is attached to the NIC.

4RJ45 port - for 10Base-T or 100Base-T network connections.

5NET LED - blinks yellow to reflect network activity.

6BASE-T LED - lights solid green to indicate a valid 10Base-T or 100Base-T

connection.

234

Ethernet Network Interface Card Configuration Guide 1-3

NOTE: Once installed, the Ethernet NIC will automatically sense the network connection and will

automatically configure the RJ-45 connection accordingly.

Protocols Supported

The following protocols are supported by your Ethernet NIC:

• Novell NetWare (IPX/SPX)

•Telnet

•EtherTalk

•DECLAT

• TCP/IP

•SNMP

• Printer MIB Web-based status and control

◆ ◆ ◆

1-4 Ethernet Network Interface Card Configuration Guide

Chapter 2

Ethernet Network Interface

Configuration

In this Chapter. . .

•“About this Chapter” on page 2-2

•“Control Panel Settings” on page 2-2

•“EZWebCon Configuration” on page 2-5

•“Incoming Logins” on page 2-5

•“Services” on page 2-6

•“AppleTalk Configuration” on page 2-6

•“LAT Configuration” on page 2-7

•“NetWare Configuration” on page 2-8

•“TCP/IP Configuration” on page 2-11

2-2 Ethernet Network Interface Card Configuration Guide

About this Chapter

This chapter will familiarize you with the configuration requirements for your NIC in a variety of different

environments to include AppleTalk, Local Area Transport (LAT), Netware and TCP/IP.

Control Panel Settings

When you install network options in the network card slots 1 and 2, the Network 1 and Network 2 control

panel submenus appear within the Interface Menu. The interface submenu contains the settings relevant to

the data input sources, interpreter selection, etc.

Net 1 Setup

This menu selection is used to configure the printer’s Net 1 port.

NOTE: This entire Net 1 Setup menu tree is only visible when an optional network interface is installed in

the Net 1 slot.

Menu Paper Menu

Interface Menu Port

Parallel Setup

Serial Setup

Network 1 Setup

Network 2 Setup

PS Menu

PCL Menu

System Menu

Quality Menu

Functions

Flash Menu

Disk Menu

AVAILABLE SELECTIONS INTERPRETER

AUTO SWITCH (see Notes 1 and 3 below)

PCL

POSTSCRIPT 3

DEFAULT AUTO SWITCH

FORMAT (see Note 3 below)

NORMAL

BINARY

RAW

DEFAULT RAW

NETWORK CHANNEL

NETWARE

OFF

DEFAULT ON
