Oki B4200 Bedienungsanleitung

RS232-C Serial

Interface Card

Installation Instructions

RS232-C Serial Interface Card Part Number: 70042701

Oki Data Americas, Inc., Mt. Laurel, NJ 08054

http://www.okidata.com

1. Unpack the serial card and

remove any shipping materials.

2. Turn off the printer and remove

the power cord and interface

cable.

3. Remove the access panel screw.

4. Lift off the access panel.

5.Install the Serial Interface Card:

a. Align the connector at the

bottom of the card with the

connector on the main board.

It

helps to align the screw holes (1)

to position the card correctly

.

b. Press the card down until the

connectors are fully engaged

and the card is securely

installed.

6. Insert and tighten the screws (1).

7. Replace the access panel:

a. Snap off the breakout tab.

b. Align tabs at panel bottom with

holes in printer frame.

c. Swing panel up and into place.

d. Replace the screw.

8. Verify Installation:

Print a MenuMap-

a. Press the Menu button one or

more times until INFO.MENU

appears on the display.

b. Press SELECT twice. The

MenuMap prints.

c. RS232C MENU should appear

in the second column. If it isn’t

there, check to be sure that the

card is installed correctly.

To change RS232-C settings:

See the User’s Guide on the CD

included with your printer for

instructions to select interface

settings in the printer Menu.

58366401
