OKIDATA Microline ML395C Bedienungsanleitung

Page: 1

Service Guide ML395/395C

Chapter 0 About This Manual

ML395 // ML395C

Dot Matrix Printers

Adobe Acrobat printable reference

copy of the OKIDATA Service Training Manual.

09/17/97

Note: This Adobe Acrobat version of the Okidata Service Training Manual was built with the

pictures rendered at 300 dpi, which is ideal for printing, but does not view on most

displays well.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Table of Contents Page

Service Guide ML395/395C

0 About This Manual

Front Cover 1

....Manual Copyright 2

1 Product Specifications

1.1 Overview - General Information 3

1.2 Product Specifications 4

1.3 Paper Specifications 5

1.4 Physical Specifications 6

1.5 Power Requirements 7

1.6 Environmental Conditions 8

1.7 Agency Approvals 9

1.8 Options 10

1.9 Consumables 11

1.10 Memory Specifications 12

1.11 Printer Reliability 13

2 Principles of Operation

2.1Electrical Operation - General Information 14

....2.1.02 Microprocessors (MPUs) and Peripheral Circuits 15

....2.1.03 Initialization 16

....2.1.04 Interface Control 17

....2.1.05 Printhead Drive Circuit 18

....2.1.06 Spacing Drive Circuit 19

....2.1.07 Line Feed Circuit 20

....2.1.08 Alarm Circuits 21

....2.1.09 Paper End Detection Circuit 22

....2.1.10 Power Supply 23

2.2 Mechanical Operation 24

....2.2.02 Spacing 25

....2.2.03 Ribbon Drive 26

....2.2.04 Paper Feed 27

....2.2.05 Paper-End Detection 28

....2.2.06 Automatic Paper Loading 29

....2.2.07 Paper Park 30

3 Maintenance & Disassembly

3.1Maintenance - General Information 31

....3.1.02 Maintenance Items 32

....3.1.03 Maintenance Precautions 33

3.2 Disassembly/Assembly Procedures - General Information 34

....3.2.01 Preliminary Items Printhead 35

....3.2.02 Ribbon Guide 36

....3.2.03 Ribbon Protector 37

....3.2.04 Upper Cover Assembly 38

Table of Contents Page

....3.2.05 Operator Panel Assembly 39

....3.2.06 Control Board (TFCB) 40

....3.2.07 Interface Connector Board (TFIF or LQPN) 41

....3.2.08 Printer Mechanism 42

....3.2.09 Platen Assembly 43

....3.2.10 Line Feed Motor 44

....3.2.11 Head Cable Assembly 45

....3.2.12 Sensor Board 46

....3.2.13 Ribbon Feed Assembly 47

....3.2.14 Space Motor Assembly 48

....3.2.15 Space Belt 49

....3.2.16 Cooling Fan 50

....3.2.17 Bail/Ribbon Motor Assembly 51

....3.2.18 Paper Bail Assembly 52

....3.2.19 Carriage and Carriage Shaft 53

....3.2.20 Paper Pressure Guide 54

....3.2.21 Printhead Gap / Release Lever Microswitches 55

....3.2.22 Push Tractor Assembly 56

....3.2.23 Power Supply Unit 57

....3.2.24 Ribbon Shift Arm Spring / Ribbon Shift Arm 58

....3.2.25 Roller Lever 59

....3.2.26 Ribbon Guide 60

....3.2.27 Bail Open Cam and Bail Open Gear 61

....3.2.28 Ribbon Shift Cam and Ribbon Shift Gear 62

....3.2.29 Ribbon Shift Cam Lever Assembly 63

....3.2.30 Printer Unit 64

....3.2.31 BTFD Printed Circuit Board 65

....3.2.32 Tension Spring 66

....3.2.33 Sheet Guide 67

....3.2.34 BTF Front Door Assembly 68

....3.2.35 Drive Pulley and Mini-pitch Belt 69

....3.2.36 Line Feed Motor 70

....3.2.37 Tractor Assembly 71

3.3 Printer Adjustments - Printhead Gap 72

....3.3.02 Line Feed Belt Tension 73

....3.3.03 Color Adjustment (Microline 395C Printer) 74

....3.3.04 Key Combinations 75

....3.3.05 Menu Operation - Menu Mode 76

........Menu Print 77

........Sample Menu 78

........Menu Settings 79

........Menu Reset 80

........Limited Operation 81

....3.3.06 Top of Form 82

Table of Contents Page

....3.3.07 Paper Park 83

....3.3.08 Forms Tear Off 84

3.4 Cleaning 85

3.5 Lubrication 86

........Lubrication Points (Monochrome and Color) 87

............Lubrication Points (Monochrome and Color) -

Continued 88

............Lubrication Points (Monochrome and Color) -

Continued 89

........Lubrication Points (Color) 90

........Lubrication Points (Options) 91

3.6 Shipping Instructions - Return For Service 92

....3.6.02 All Other Returns 93

4 Failure & Repair Analysis

4.1 Overview 94

....4.1.02 Printer Serial Number Identification 95

4.2 Reporting Problems - General Information 96

....4.2.02 Problem Lists 97

....4.2.03 Reporting Methods 98

4.3 Troubleshooting Updates - General Information 99

....4.3.02 Okilink II 100

....4.3.03 Faxable Facts 101

....4.3.04 Technical Service Bulletins 102

4.4 Troubleshooting Tips - Preliminary Checks 103

....4.4.02 Problem Categories 104

....4.4.03 START HERE Flowchart 105

....4.4.04 Tips for Preventing Image Problems 106

....4.4.05 Common Problems 107

4.5 Abnormal Output 108

4.6 Fault Alarms - General Information 109

4.7 Repair Analysis Procedures (RAPS) - Using The RAPS 110

....4.7.02 RAP Index 111

........RAP 01: Power Lamp Does Not Light 112

........RAP 02: Space Error (ALARM 5B) 113

........RAP 03: Head Homing Error (ALARM 53) 114

........RAP 04: Ribbon Homing Error (ALARM 57) 115

........RAP 05: Bail Home Error (ALARM 5C) 116

........RAP 06: Wrong Character, Character Omission, or Dot

Omission 117

........RAP 07: Ribbon Feed Trouble 118

........RAP 08: Line Feed Trouble 119

........RAP 09: Malfunction of Operator Panel Switch 120

........RAP 10A: Data Receive Failure 121

........RAP 10B: Parallel Interface Problem 122

Table of Contents Page

........RAP 10C: Serial Interface Problem 123

........RAP 10D: Data Receive Failure (Alarm Light Lit) 124

........RAP 11: Color Ribbon Shift Problem 125

4.8 Printer Tests 126

....4.8.02 Font Test 127

....4.8.03 Serial Interface - Loopback Test 128

....4.8.04 Hexadecimal Dump 129

4.9 Resistance Checks - General Information 130

....4.9.02 Printhead Resistance Check 131

....4.9.03 Line Feed Motor Resistance Check 132

....4.9.04 Space Motor Resistance Check 133

....4.9.05 Ribbon Motor Resistance Check 134

A Board Diagrams

A.1 Overview - General Information 135

A.2 Index To Charts 136

....A.2.01 Main Controller Board (TFCB) 137

............ML395/395C Jumper Plugs SP2 : Jim

Fitzpatrick/Project Leader/Okidata; 11/18/96 138

....A.2.02 Power Supply Board (POW) 139

....A.2.03 Interface Board (TFIF) 140

............Change sp102 jumper : Eric

Tomenga/OKI_ELECTRIC/US 141

............Shorting Plug SP102 : Jim Fitzpatrick/Project

Leader/Okidata; 11/18/96 142

....A.2.04 Sensor Board (LQEW) 143

....A.2.05 Operator Panel (TFOP) 144

B Illustrated Parts Listing

B1.1 Overview - General Information 145

....B.1.02 Definition of Terms 146

....B.1.03 Parts Ordering Information 147

B.2 Charts 148

....B.2.01 Upper Cover Assembly 149

....B.2.02 Printer Unit General Assembly 150

....B.2.03 Operator Panel 151

....B.2.04 Carriage Assembly (Black and White) 152

....B.2.05 Carriage Assembly (Color) 153

....B.2.06 Printer Unit - Black and White (1 of 3) 154

....B.2.07 Printer Unit - Black and White (2 of 3) 155

....B.2.08 Printer Unit - Black and White (3 of 3) 156

....B.2.09 Printer Unit - Color (1 of 3) 157

....B.2.10 Printer Unit - Color (2 of 3) 158

....B.2.11 Printer Unit - Color (3 of 3) 159

....B.2.12 Cables and Connectors 160

....B.2.13 Options 161

Table of Contents Page

....B.2.14 Pull Tractor Assembly (Option) 162

....B.2.15 Bottom Tractor Feed Unit (Push) [BTF] (Option) 163

....B.2.16 BTF Pull-Up Roller Assembly (Option) 164

....B.2.17 Consumables 165

....B.2.18 Packing Materials 166

....B.2.19 Documentation 167

Page: 2

Service Guide ML395/395C

Chapter 0 About This Manual

This document may not be reproduced without the written permission of the Okidata ® Technical Training

Group. Every effort has been made to ensure the accuracy of the information contained in this training

course. Okidata is not responsible for errors beyond its control.

First Edition May, 1993 P/N 59260501

Second Edition October, 1994 P/N 59260502

Written and produced by the Okidata Technical Training Group

Please send any comments on this publication to the address listed below.

Technical Training Group

Okidata

532 Fellowship Road

Mount Laurel, NJ 08054-3499

Okilink Login Name: Technical Training

OKI is a registered trademark of Oki Electric Industry Company, Ltd.; marques deposee de Oki Electric

Industry Company, Ltd.; marca registrada, Oki Electric Industry Company, Ltd.

OKIDATA is a registered trademark of Oki Electric Industry Company, Ltd.; marques deposee de Oki

Electric Industry Company, Ltd.; marca registrada, Oki Electric Industry Company, Ltd.

MICROLINE is a registered trademark of Oki Electric Industry Company, Ltd.; marque depose de Oki

Electric Industry Company, Ltd.

Centronics is a registered trademark of the Centronics Data Computer Corp.

Epson is a registered trademark of Seiko Epson Corporation.

IBM is a registered trademark of International Business Machine Corporation.

Microsoft is a registered trademark of Microsoft Corporation.

MS-DOS is a registered trademark of Microsoft Corporation.

PC is a registered trademark of International Business Machine Corporation.

Proprinter is a registered trademark of International Business Machine Corporation.

Windows is a trademark of Microsoft Corporation

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 3

Service Guide ML395/395C

Chapter 1 Product Specifications

1.1 OVERVIEW

1.1.01 General Information

The Microline 395 is a high speed, dot matrix printer, which utilizes a 24 wire printhead. The Microline 395

comes standard with both an RS232-C Serial Interface and a Centronics Parallel Interface. The printer is

available in either a standard version (Microline 395; single color output) or a color capable version

(Microline 395C; multiple color output). The Microline 395 is capable of emulating the Epson LQ 850/1050

or the IBM Proprinter XL24 printers. The Microline 395C emulates the Epson LQ 2550, Epson

LQ850/1050 or the IBM Proprinter XL24.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 4

Service Guide ML395/395C

Chapter 1 Product Specifications

1.2 PRODUCT SPECIFICATIONS

1.2.01 Paper Feed Method

Built-in push tractor

Friction feed

1.2.02 Paper Path

Bottom Feed

Rear Feed

Top Feed

1.2.03 Printhead Type

Staggered, 24 pin, stored energy printhead

1.2.04 Interface Methods

Both are Standard

Centronics Parallel Interface

RS232-C Serial Interface

1.2.05 Print Speed

Pitch Head Gap

Setting High Speed

Draft Utility Near Letter

Quality Letter Quality

10 cpi 1,2 405 cps 202 cps 135 cps

12 cpi 1,2 607 cps 486 cps 242 cps 162 cps

15 cpi 1,2 607 cps 303 cps 202 cps

17.1 cpi 1,2 347 cps 231 cps

20 cpi 1,2 405 cps 270 cps

10 cpi 3+ 352 cps 175 cps 117 cps

12 cpi 3+ 422 cps 211 cps 140 cps

15 cpi 3+ 528 cps 263 cps 175 cps

17.1 cpi 3+ 528 cps 300 cps 200 cps

20 cpi 3+ 352 cps 234 cps

cpi - Characters Per Inch

cps - Characters Per Second

1.2.06 Symbol Sets

Standard ASCII

Epson Character Set

IBM Character Set I and Set II

IBM Proprinter All Character Set

International Characters

Line Graphics

Code Page 850, 863,437

1.2.07 Standard Fonts

Utility (Used in Utility and High Speed Draft Modes)

Courier

Swiss

Roman

Orator

1.2.08 Line Feed Increments

1/6" n/180"

1/8" n/216"

n/60" n/360"

n/72"

1.2.09 Line Feed Time

55 ms @ 6 LPI

8.0 IPS (inches per second) slew rate @ gap 1,2

6.0 IPS (inches per second) slew rate @ gap 3+

1.2.10 Paper Out Detection

Printhead distance from edge of paper when End of Paper is detected

Rear Feed: 5.8"

Bottom Feed: 2.4"

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere OKIDATA Drucker Handbücher

OKIDATA

OKIDATA OL830 Bedienungsanleitung

OKIDATA

OKIDATA OL400e Series Bedienungsanleitung

OKIDATA

OKIDATA MICROLINE 320 Bedienungsanleitung

OKIDATA

OKIDATA Okipage 16n Bedienungsanleitung

OKIDATA

OKIDATA Microline 395 Anleitung zur Verwendung

OKIDATA

OKIDATA ML184Turbo Bedienungsanleitung

OKIDATA

OKIDATA MICROLINE 320 Bedienungsanleitung

OKIDATA

OKIDATA ML390 Turbo Bedienungsanleitung

OKIDATA

OKIDATA PT330 Montageanleitung

OKIDATA

OKIDATA ML320 Turbo Bedienungsanleitung

OKIDATA

OKIDATA Okipage 16n Bedienungsanleitung

OKIDATA

OKIDATA OKIMATE 20 Bedienungsanleitung

OKIDATA

OKIDATA ML390 Turbo Bedienungsanleitung

OKIDATA

OKIDATA MICROLINE 320 Bedienungsanleitung

OKIDATA

OKIDATA OL400e Series Montage- und Bedienungsanleitung

OKIDATA

OKIDATA Pacemark 2410 Bedienungsanleitung

OKIDATA

OKIDATA Pacemark 3410 Anleitung zur Verwendung

OKIDATA

OKIDATA MICROLINE ML590 Bedienungsanleitung

OKIDATA

OKIDATA Pacemark 3410 Bedienungsanleitung

OKIDATA

OKIDATA Microline ML395 Bedienungsanleitung

OKIDATA

OKIDATA PT390 Montageanleitung

OKIDATA

OKIDATA Microline ML395 Bedienungsanleitung

OKIDATA

OKIDATA OKIMATE 20 Bedienungsanleitung

OKIDATA

OKIDATA Pacemark 3410 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
