Olympia electronics GR-8/leds Bedienungsanleitung

GR-8/leds, GR-9/leds

NON-MAINTAINED / MAINTAINED

EMERGENCY LUMINAIRES

Thank you for your trust in our products

Olympia Electronics - European manufacturer

IP42

Test button

Non

maintained

Maintained

MSC

Self-

contained

15m

Light output

100lm

These luminaires are used indoors (ta 40 C) on the wall, where

emergency light is needed. Each luminaire must be permanently

connected to the mains power supply. In normal operation the

illumination LEDs are lit as well as the green indicating charge LEDs,

when the battery is charging. In case of a mains power supply failure the

luminaire will light the led strip automatically in emergency mode.

When the mains power supply is restored the device turns to normal

operation.

Non-Maintained / Maintained operation there is an option to select

the non maintained or maintained operation by placing the jumper to

the appropriate place according to the Figure 4 (see page 2).

INSTALLATION

To install the luminaire follow the installation instructions on page 2.

ΑΤΤΕΝΤΙΟΝ!!!

1. Operations for installation, maintainance or testing must be done

by authorized personnel only.

2. The device must be connected to the mains power supply

through a fuse dependent by the total amount of the line’s

power load.

3. It is suggested to check every month the indication LED for

battery charging, and by pushing the TEST button to check the

emergency circuit. The led strip should light as long as the TEST

button is pressed.

4. It is suggested to check every 6 months the minimum autononous

duration by disconnecting the mains power supply. Count the

time that the led strip lights and in case of less time than the

nominal autonomy, the battery must be replaced. If the measured

time is considerably less than the nominal autonomy

In case of battery or led strip replacement, these must

be replaced by parts of the same type, by the manufacturer or by

a competent person.

t i

in battery

recycling points. Do not incinerate.

The light source contained in this luminaire shall only be

replaced by the manufacturer, his agent or a similar qualified

person.

NOTE! The light source is non-user replaceable.

If the luminaire doesn’t work as described

above contact the installer.

contact the

installer.

5. In case of inactive use for a period greater than 2 months,

disconnect the battery by pulling out the battery’s connector.

6.I s not allowed to discard batteries into

common trash bins, they must be discarded only

923378005_09_009

Luminaire

Mounting accessories

Manual

Package Contents

General

Dismantle the device carefully using a flat bladed screwdriver.

Mount the plastic base on the wall (the test button must be

facing downwards) using the included mounting accessories in

points B and C.

Pass the mains cables through the hole (point A) and secure it

with a suitable bracket (not included) to ensure immobilization

of the cable at a distance of no more than 5cm from the

luminaire’s cable entry. ATTENTION!! To maintain the IP rating,

the outer diameter of the power cable must be at least 8.2 mm².

923378005_09_009

Installation instructions

Non maintained

operation

Maintained

operation

923378005_09_009

Refit carefully the removed plastic parts and power on the

device.

NOTE!! After finishing the installation you must power the luminaire

for at least 24 hours in order to completely charge the battery. The

rated autonomy duration can be achieved after that time.

It can be done only by a competent person and after the mains

interruption.

1. Dismantle the device (step 1 of the installation instructions).

2. Disconnect the connector and remove the old battery.

3. Connect the new battery with the same type (step 6 of the

installation instructions) and place it in the position of the old one.

4. Follow the step 7 of the installation procedure and power on the

device.

Battery Replacement

Connect the mains cables to the terminal block.

Connect the battery`s cable with the appropriate terminal.

OPERATION VOLTAGE

MAXIMUM POWER CONSUMPTION

BATTERY (Ni-Cd)

INDICATIONS - CONTROLS

CHARGE TIME

MINIMUM DURATION

LIGHT SOURCE

ILLUMINATION (MAINS/EMERGENCY )

DEGREES OF COVER PROTECTION

PRODUCED IN ACCORDANCE WITH

OPERATION TEMPERATURE RANGE

VIEWING DISTANCE

RELATIVE HUMIDITY

CONSTRUCTION MATERIAL

EXTERNAL DIMENSION (L x W x H)

WEIGHT

GUARANTEE

GR-8/leds

GR-9/leds

3 W / 3.5 VA2.7 W / 3 VA

220-240V AC / 50-60Hz

3.6V/1Ah3.6V/0.6Ah

Charge LEDs, TEST button

24 hours

1.5 hour

12 white LEDs

40lm / 100lm

IP42

EN 60598-1, EN 60598-2-22, ΕΝ 55015,

ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3

5 to 40 C

Up to 95%

ABS/PC, PC

15m

240 x 90 x 44 mm

345gr. 350gr.

3 years (1 year for the battery)

3 hours

38lm / 100lm

(*) Maintained operation: The luminaire lights its illumination source, when it

is powered by the mains power supply or not.

Non Maintained operation: The luminaire lights its illumination source, only in

power supply’s failure.

Note!! The installer should fill in, on the specification label, the letter G if the

luminaire is used as a safety sign.

X190A

NOTE: LED= Light Emitting Diode

LABELING EXPLANATION:

X: Self contained

1: Maintained (*)

A: Including test device

G: Internally illuminated

90: 1.5 hour duration

180: 3 hours duration

923378005_09_009

Technical Characteristics

LED Characteristics

Olympia Electronics S.A.MANUFACTURER

45 C max. across the board °

2.9-3.6V DC

780mW

2201159

Non reversible connection between main pcb and led module

MODEL NUMBER

VOLTAGE RANGE

CONNECTIONS

NOMINAL POWER

TEMPERATURE (tc)

period of warranty is specified in the official catalogue of Olympia Electronics and also in

the technical leaflet, which accompanies each product. This warranty ceases to exist if

the buyer does not follow the technical instructions included in official documents given

by Olympia Electronics or if the buyer modifies the goods provided or has any repairs or

re-setting done by a third party, unless Olympia Electronics has fully agreed to them in

writing. Products that have been damaged can be returned to the premises of our

company for repair or replacement, as long as the warranty period is valid.

Olympia Electronics reserves the right to repair or to replace the returned goods and to

or not charge the buyer depending on the reason of defection. Olympia Electronics

reserves the right to charge or not the buyer the transportation cost.

Olympia Electronics guarantees the quality, condition and operation of the goods. The

72 . . . .

P.C. 60300 P.O. Box 06 Εginio Pierias Greece

nd km O N R Thessaloniki-Katerini

www.olympia-electronics.gr

info@olympia-electronics.gr

923378005_09_009

Warranty
