iConverter 2FXM Plug-in Module QUICK START GUIDE

TheOmnitroniConverter®2FXMNetworkInterfaceDevice(NID)

with integrated management provides Fast Ethernet

(100BASE-FX) fiber-to-fiber media conversion.

The 2FXM conforms to Ethernet in the First Mile (EFM) fiber

standards to support Fiber-to-the-X (FTTX) Metropolitan and

Enterprise LAN networks. Built-in Operation, Administration

and Maintenance (OAM) functionality enables the 2FXM to

operate as a managed demarcation point at the customer

premises and network edge, offering service provisioning

functions, such as Quality of Service and Bandwidth Control

(rate-limiting) capabilities.

The2FXMmodulecanbemanagedusingOmnitron’sNetOutlookTMSNMPManagement

Software, 3rd Party SNMP Client, Telnet or the Command Line Interface (CLI).

Formoreinformation,including the complete User Manual on the2FXMPlug-inmodule,

access Omnitron’s documentation download web page to view all relevant documents:

http://www.omnitron-systems.com/downloads.php

INSTALLATION PROCEDURE

1) Configure DIP-Switches

2) Install Module in Chassis and Connect Cables

3) Configure Module via Command Line Interface

4) Verify Operation

1) CONFIGURE DIP-SWITCHES

DIP-SWITCH BANK 1

SW1 - PAUSE ENABLE

When the Pause Enable DIP-switch is in the

LEFT “Off” position (factory default), the 2FXM

disables the fiber ports’ ability to send and

receive Pause frames during network

congestion. Setting this DIP-switch to the

RIGHT “On” position, enables the 2FXM to

receive Pause frames from its link partner. This

enables the 2FXM to stop transmitting traffic to

its link partner and store incoming frames from

the other port in the internal buffer until the

congestion clears. If the internal buffer of the

2FXM becomes congested, it will transmit a

Pause frame to its link partner.

SW2 - FIBER PORT 1 FULL/HALF DUPLEX

Setting this DIP-switch to Half-Duplex “HDX” facilitates a connection that supports Half-

Duplex. Setting this DIP-switch to Full-Duplex “FDX” facilitates a connection that

supports Full-Duplex operation.

Management Options iConverter, Serial Agent

Network Management

1: Chassis and Module Management

2: Set Module Name Preferences

Management Module Preferences

3: IP and Control Preferences

4: SNMP Preferences

5: Abandon Preference Changes

6: Save Preference Changes

7: Restore Factory Defaults

8: Restart Management Module

9: Other Networking Features

Management Module Maintenance

10: Firmware Update

11: Set Date/Time

IP Address = 192.168.1.220

Chassis Number = 1

Enter Choice, <H>elp, E<x>it >

Figure D: Command Line Interface Menu Options

TheCLIinterfaceallows for the detailedconfigurationofthe module. It is recommended

to configure the module with an IP address associated with the attached network.

Also, SNMP traphost address should be configured if the module is managed with an

SNMP-based Management System. See the 2FXM User Manual for complete

information.

4) VERIFY OPERATION

Once the module has been

installed and configured per

steps 1 - 3, verify the module

is operational by viewing the

LED indicators.

The Power LED indicates the

module is receiving power

from the chassis.

The Fiber Optic link LEDs

indicate the fiber optic

connections have been

established. Verify the Link

Mode selection is set to Link

Segment (LS). Until a stable

link is established, leave the

Link Mode configured for LS.

After a Link presence is established, the Link Mode selection can be modified.

Switch 1

Switch 8

LEFT

Switch 1

Switch 8

Bank 2

Bank 1

RIGHT

Figure A: DIP-Switch Locations

LED Function

"Legend" Color Off State On / Blinking State

Power "Pwr" Amber No power On: Module has power

Power Supply Status

#X Amber Chassis Power

Supply not installed

On: Power available from

installed Power Supply #X

Blinking: No power available

from installed Power Supply#X

Port 1

Fiber Link Activity

"P1" Green No Fiber Link On: Fiber link is active

Blinking: Fiber Data Activity

Port 1

Half/Full Duplex

"FDX" Green Half-Duplex On: Full-Duplex

Chassis Management

Master/Slave

"Msr/Slv" Green Chassis Slave

Mode

On: Chassis Master

Blinking: Operating in OAM

Mode

Port 2

Fiber Link Activity

"P2" Green No Fiber Link On: Fiber link is active

Blinking: Fiber Data Activity

Port 2

Half/Full Duplex

"FDX" Green Half-Duplex On: Full-Duplex

Figure E: LED Indicators

Form 040-08940-002 D 12/07

Omnitron Systems Technology * 140 Technology Dr. #500 * Irvine, CA 92618

949.250.6510 tel * 949.250.6514 fax * www.omnitron-systems.com

installed management modules to the RIGHT “SL” position to enable Slave-Only

mode.

SW5, SW6, SW7, SW8 - RESERVED

These DIP-switches are for factory use only and must always remain in the LEFT

position (factory default).

2) INSTALL MODULE IN CHASSIS AND CONNECT CABLES

a. Carefully slide the module into an open slot in the chassis. Align the module with

the installation guides and ensure that the module is firmly seated against the

backplane. Secure the module by fastening the front panel thumbscrew (push in

and turn clockwise to tighten) to the chassis front. Verify the “Pwr” LED is ON

(indicating the chassis is powered).

b. Insert the SFP Fiber transceivers into the Port 1 and Port 2 SFPreceptacles on the

2FXM.

NOTE: The release latch of the SFP Fiber transceiver must be in the closed

position before insertion.

d. Connect an appropriate multimode or single-mode fiber cable to the SFP fiber

ports of the installed module. It is important to ensure that the transmit (TX) is

attached to the receive side of the device at the other end and the receive (RX) is

attached to the transmit side. Single-fiber (SF) media converter models operate in

pairs. The TX wavelength must match the RX wavelength at the other end and the

RX wavelength must match the TX wavelength at the other end.

NOTE: In order to support Remote OAM Management Mode, Port 1 of the

2FXM must be connected to the Port 1 on the 2FXM or link partner.

3) CONFIGURE MODULE VIA COMMAND LINE INTERFACE

To access the Command Line Interface (CLI), connect the 2FXM RS-232 Console Port

to the COM port of a computer equipped with terminal emulation software such as

HyperTerminal. The Console Port (DCE) is a mini DIN-6 female connector which can

be changed to a DB-9 connector with the included adapter. The 2FXM Console Port is

a standard asynchronous serial interface.

Start HyperTerminal and select the correct COM Port in the HyperTerminal “Connect

To:” window. Set the serial port to the following:

Bits Per Second 57,600

Stop Bits 1

Data Bits 8

Parity NONE

Hardware Flow Control NONE

Once connected, press <ENTER> to bring up a command line prompt on the attached

PC. A new 2FXM module does not have a password, and will skip the Password

Entry screen and go straight to the Management Options screen. If a password has

been set, the Password Entry screen will be displayed. Type the password and press

<ENTER>, the 2FXM will respond with the Management Options screen:

SW3 AND SW4 - RESERVED

These DIP-switches are for factory use only and must always remain in the LEFT

(factory default) position.

SW5 - FIBER PORT 2 FULL/HALF DUPLEX

Setting this DIP-switch to Half-Duplex “HDX” facilitates a connection that supports

Half-Duplex. Setting this DIP-switch to Full-Duplex “FDX” facilitates a connection that

supports Full-Duplex operation.

SW6, SW7, SW8 - LINK MODES

Themodulesupportsmultiplelinkmodesfor fault detection and isolation. Link Segment

should be used for the initial installation of the module. Once installed and operational,

the link mode can be modified.

Switch Left

(Factory Default) Right SW6 SW7 SW8 Link Mode Selection

SW1 Off:

Pause Disable PAUS:

Pause Enable Left Left Left Link Segment (LS)

(Factory Default)

SW2 FDX:

Fiber Port 1Full-Duplex HDX:

Fiber Port 1Half-Duplex Right Left Left Link Propagate (LP)

SW3 Reserved Reserved Left Right Left Remote Fault Detect + Link

Segment (RFD + LS)

SW4 Reserved Reserved Right Right Left Remote Fault Detect + Link

Propagate (RFD + LP)

SW5 FDX:

Fiber Port 2 Full-Duplex HDX:

Fiber Port 2Half-Duplex Left Left Right Symmetrical Fault Detect (SFD)

SW6

See Link Mode Selection

Right Left Right Illegal Setting

SW7 Left Right Right Illegal Setting

SW8 Right Right Right Illegal Setting

Figure B: DIP-Switch Bank 1

DIP-SWITCH BANK 2

SW1, SW2 - BACKPLANE ENABLE

When the DIP-switch is in the LEFT “DS” position (factory default), the Backplane Port

of the 2FXM is isolated from the chassis’ Ethernet Backplane. When the DIP-switch

is in the RIGHT “EN” position, the Backplane Port is enabled. This allows Ethernet

Backplane connectivity to an adjacent module via the chassis Backplane Link “A” or

“B” depending on the switch setting.

SW4 - MASTER/SLAVE

When the 2FXM module is installed

in a chassis with an iConverter

Network Management Module

(NMM), set DIP-switch to the LEFT

“M/SL” position (factory default).

The assignment of mastership is

automatically negotiated by the

installed management modules. To

designate the 2FXM module as the

master of the chassis, set the DIP-

switch to the LEFT “M/SL” position,

and set the DIP-switch of the other

Switch Left

(Factory Default) Right

SW1 A-DS: Disabled

Backplane Port A A-EN: Enabled

Backplane Port A

SW2 B-DS: Disabled

Backplane Port B B-EN: Enabled

Backplane Port B

SW3 Reserved Reserved

SW4 M/SL:

Auto Select SL:

Slave-Mode Only

SW5 - SW8 Reserved Reserved

Figure C: DIP-Switch Bank 2

Andere Omnitron Systems Technology Medienkonverter Handbücher

Omnitron Systems Technology

Omnitron Systems Technology iConverter CWDM/X Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter 10/100VT Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter GM4-PoE+ Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter XGT+ Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology Omnitron iConverter GX/TM2 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology 8599R Series Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology FlexPoint 100Fx/Tx Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology miConverter GX/T Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology E1 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter 100Tx Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology miConverter GX/T Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter 2FXM2 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter 2GXM2 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter Gx AN Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter X21 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology Serial RS-422 and RS-485 to Fiber Media Converter... Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter GX/T2 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter Gx AN Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter T3/E3 Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology XM5-1G Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology OmniRepeater AS400/3X Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology iConverter 2GXM Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology 10/100 Media Converter miConverter Bedienungsanleitung

Omnitron Systems Technology

Omnitron Systems Technology Omnitron iConverter GX/TM2 Bedienungsanleitung

Beliebte Medienkonverter Handbücher anderer Marken

SoundTraxx

SoundTraxx Blunami BLU-2200 Bedienungsanleitung

SPROLINK

SPROLINK VA1 Bedienungsanleitung

Acclaim Lighting

Acclaim Lighting DDC-1-AC Bedienungsanleitung

Nikon

Nikon AF-S TC-20E III Bedienungsanleitung

Axis

Axis AXIS Q7406 Bedienungsanleitung

Omega

Omega TAC80B-J Bedienungsanleitung

Zoom

Zoom Thunderbolt TAC-2R Bedienungsanleitung

OST

OST iConverter 10/100M Bedienungsanleitung

Vertiv

Vertiv Netsure Bedienungsanleitung

birddog

birddog MINI Bedienungsanleitung

Roland

Roland GI-10 Bedienungsanleitung

Wallenstein

Wallenstein WX310 Bedienungsanleitung

Pace

Pace MSS 200-1 Bedienungsanleitung

Solar Converters

Solar Converters EQ 12/24-50 Bedienungsanleitung

CYP

CYP EL-7400V Bedienungsanleitung

TIE

TIE MIDI 1i1o Bedienungsanleitung

DCS

DCS Vivaldi Upsampler Bedienungsanleitung

Westermo

Westermo MCW-211 SERIES Bedienungsanleitung
