Programmable Multi-Axis Controller

Startup Guide

Vision System FH Series

(IDEv4)

CK3E-

□□□□

CK3M-CPU1

□

NY51

□

-A

□□□

O043-E1-01

About Copyrights and Trademarks

Microsoft product screen shots are reprinted with permission from Microsoft Corporation.

Windows is a registered trademark of Microsoft Corporation in the United States and other

countries.

EtherCAT® is a patented technology and registered trademark licensed by Beckhoff Automation

GmbH, Germany.

Sysmac is a trademark or registered trademark of OMRON Corporation in Japan and other

countries for OMRON factory automation products.

Company names and product names in this document are trademarks or registered trademarks

of their respective companies.

Contents

1. Related Manuals................................................................................. 4

2. Terms and Definitions........................................................................ 5

3. Precautions ........................................................................................ 6

4. Overview............................................................................................. 7

5. Applicable Devices and Device Configuration................................ 8

5.1. Applicable Devices............................................................................... 8

5.2. Device Configuration............................................................................ 9

6. EtherCAT Connection Procedure ................................................... 10

6.1. Workflow ............................................................................................ 10

6.2. Preparation for the Controller Setup................................................... 10

6.3. Installation of ESI Files....................................................................... 16

6.4. EtherCAT Communications Setup...................................................... 17

6.5. Controller Settings.............................................................................. 24

7. Appendix Saving and Loading a Project........................................ 29

7.1. Saving a Project................................................................................. 29

7.2. Loading and Downloading a Project................................................... 31

8. Appendix Troubleshooting.............................................................. 34

8.1. Factors Causing EtherCAT Communications To Be Unavailable, and Corrective Actions

........................................................................................................... 34

8.2. How to Check for Errors..................................................................... 35

9. Appendix ECAT[i] Structure Elements........................................... 38

10. Revision History............................................................................... 39

1. Related Manuals

To ensure system safety, always read and follow the information provided in all Safety

Precautions and Precautions for Safe Use in the manuals for the devices that are used in the

system.

The following shows the manuals for OMRON Corporation (hereafter referred to as OMRON)

and Delta Tau Data Systems, Inc (DT).

Manufacturer Manual No. Model Manual name

OMRON I610-E1 Model CK3E-110

Programmable Multi-Axis Controller

Hardware User’s Manual

OMRON O036-E2 Model CK3M-CPU11 CK3M-series Programmable

Multi-Axis Controller

Hardware User’s Manual

OMRON W580-E1 Model

NY512-A6001XX21391X

Industrial PC Platform NY-series

IPC Programmable Multi-Axis

Controller Hardware User’s Manual

OMRON Z365-E1 Model FH-□

Model FHV□-□

Model FZ5-□

Vision System User’s Manual

OMRON Z342-E1

Model FH-□

Model FHV□-□

Model FZ5-□

Vision System User’s Manual

(Communications Settings)

DT O014-E - Power PMAC User’s Manual

DT O015-E - Power PMAC Software Reference

Manual

DT O016-E - Power PMAC IDE Users Manual

2. Terms and Definitions

Term Explanation and Definition

Slave Slaves are devices connected to EtherCAT. There are various types of

slaves such as servo drivers handling position data and I/O terminals

handling the bit signals.

Object Represents information such as in-slave data and parameters.

PDO

communications

(Communications

using Process Data

Objects)

One type of EtherCAT communications in which Process Data Objects

(PDOs) are used to exchange information cyclically and in real time.

This is also called “process data communications”.

PDO Mapping The association of objects used for PDO communications.

PDO Entry PDO entries are the pointers to individual objects used for PDO

mapping.

ESI file

(EtherCAT Slave

Information file)

An ESI file contains information unique to the EtherCAT slaves in XML

format.

You can load ESI files into the Power PMAC IDE, to easily allocate

slave process data and make other settings.

ENI file

(EtherCAT Network

Information file)

An ENI file contains the network configuration information related to

EtherCAT slaves.

Power PMAC IDE This computer software is used to configure the Controller, create user

programs, and monitor the programs.

PMAC is an acronym for Programmable Multi-Axis Controller.

3. Precautions

(1) Understand the specifications of devices that are used in the system. Allow some margin

for ratings and performance. Provide safety measures, such as for installing a safety

circuit, in order to ensure safety and minimize the risk of abnormal occurrences.

(2) To ensure system safety, always read and follow the information provided in all Safety

Precautions and Precautions for Safe Use in the manuals for each device that is used in

the system.

(3) The user is encouraged to confirm the standards and regulations that the system must

conform to.

(4) It is prohibited to copy, reproduce, or distribute a part or the whole of this document

without the permission of OMRON Corporation.

(5) The information contained in this document is current as of April 2019.

It is subject to change without prior notice for improvement purposes.

The following notations are used in this document.

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury, or may result in serious

injury or death.Additionally, there may be severe property

damage.

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury, or property damage.

Precautions for Correct Use

Precautions on what to do and what not to do to ensure correct operation and performance.

Additional Information

Additional information to read as required.

This information is provided to increase understanding or make operations easier.

Symbols

The filled circle symbol indicates operations that you must carry out.

The specific operation is shown in the circle and explained in text.

This example indicates a “general precaution” for something that you must

carry out.

4. Overview

This document describes the procedures used to connect the OMRON Vision System FH

Series model FH-1050/FH-1050- or model FH-3050/FH-3050- (hereafter referred to

as the Slave) using OMRON Programmable Multi-Axis Controller model CK3E-□□□□/

CK3M-CPU11/NY51□-A□□□ (hereafter referred to as the Controller) and EtherCAT, as

well as for checking the connection.

Refer to Section 6. EtherCAT Connection Procedure to learn about the setting methods and

key points to perform PDO communications via EtherCAT.

5. Applicable Devices and Device Configuration

5.1. Applicable Devices

The applicable devices are as follows:

Manufacturer Name Model

OMRON Programmable Multi-Axis Controller

Model CK3E-

□□□□

OMRON Programmable Multi-Axis Controller Model CK3M-CPU11

OMRON Programmable Multi-Axis Controller

Industrial Box PC Model NY51□-A□□□

OMRON FH Sensor Controller Model FH-1/FH-1-

Model FH-3/FH-3-

OMRON 0.3 megapixel digital camera

0.3 megapixel compact digital camera

0.3 megapixel compact digital camera,

pen type

0.3 megapixel high-speed camera

0.3 megapixel high-speed CMOS camera

2 megapixel digital camera

2 megapixel high-speed CMOS camera

4 megapixel high-speed CMOS camera

5 megapixel digital camera

Intelligent camera

Intelligent compact camera

Auto-focus camera

Model FZ-SC/S

Model FZ-SFC/SF

Model FZ-SPC/SP

Model FZ-SHC/SH

Model FH-SC/SM

Model FZ-SC2M/S2M

Model FH-SC02/SM02

Model FH-SC04/SM04

Model FZ-SC5M2/S5M2

Model FZ-SLC15/SLC100 Model

Model FZ-SQ010F/SQ050F

/SQ100F/SQ100N

Model FZ-SZC15/SZC100

OMRON Camera Cable Model FZ-VS□

Precautions for Correct Use

In this document, the devices with models and versions listed in Section 5.2 are used as

examples of applicable devices to describe the procedures to connect the devices and check

their connections.

You cannot use devices with versions lower than the versions listed in Section 5.2.

To use the devices mentioned above with models not listed in Section 5.2 or versions higher

than those listed in Section 5.2, check the differences in the specifications by referring to the

manuals before operating the devices.

Additional Information

This document describes the procedures to establish the network connections. It does not

provide information on operations, installations, wiring methods, device functionalities, or

device operations, which are not related to the connection procedures. For more information,

refer to the manuals or contact your OMRON representative.

5.2. Device Configuration

The hardware components to reproduce the connection procedures in this document are as

follows:

Manufacturer Name Model Version

OMRON

Programmable Multi-Axis

Controller

Model NY51□-A□□□

Ver.2.5 or

later

OMRON FH Sensor Controller Model FH-3050

Ver. 5.00

OMRON

Camera

Model FZ-SC04

OMRON

Camera cable

Model FZ-VS3

DT Power PMAC IDE - Ver.4.2.1.19

Precautions for Correct Use

Prepare the ESI file described in this section in advance. Contact your OMRON

representative for information on how to procure the ESI file.

Precautions for Correct Use

Do not share the connection line of EtherCAT communications with other Ethernet networks.

Do not use devices for Ethernet such as a switching hub.

Use the Ethernet cable (double shielding with aluminum tape and braiding) of Category 5 or

higher, and use the shielded connector of Category 5 or higher.

Connect the cable shield to the connector hood at both ends of the cable.

Additional Information

This document describes model NY51□-A□□□ as an example. The same procedures can

apply to model CK3E-□□□□/ CK3M-CPU1□1.

Model FH-3050

EtherCAT

communications

Model NY51□-A□□□

Power PMAC IDE

6. EtherCAT Connection Procedure

This section describes the procedure for connecting the Controller with the Slave via

EtherCAT. The description assumes that the Controller is set to factory default.

6.1. Workflow

Take the following steps to operate the PDO communications via EtherCAT after connecting

the Controller with the Slave via EtherCAT.

6.2 Preparation for the Controller Setup Prepare the Controller settings.

▼

6.2.1 Creation of a New Project

▼

6.2.2 Initial Settings of the Controller

▽

6.3 Installation of ESI Files Install the ESI file for the Slave into

PowerPMAC IDE.

▽

6.4 EtherCAT Communications Setup Set up EtherCAT communications.

▼

6.4.1 Communications Setup for the EtherCAT Master

▼

6.4.2 Distributed Clock Setup

▼

6.4.3 PDO Map Settings

▼

6.4.4 Creation of an EtherCAT Network Information File

▽

6.5 Controller Settings Set up the Controller.

▼

6.5.1 EtherCAT Communications Check

▼

6.5.2 Writing the User Program

▼

6.5.3 Project Data Transfer

6.2. Preparation for the Controller Setup

Prepare the Controller settings.

Install Power PMAC IDE on the computer in advance.

Creation of a New Project6.2.1.

Andere Handbücher für fh series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Omron Bildverarbeitungssystem Handbücher

Omron

Omron FJ-3000-10 Bedienungsanleitung

Omron

Omron FJ-350 Bedienungsanleitung

Omron

Omron FLV-FX100R Bedienungsanleitung

Omron

Omron STC-APB503PCL Montageanleitung

Omron

Omron FQ2-S1 Bedienungsanleitung

Omron

Omron FLV-CL Series Bedienungsanleitung

Omron

Omron Vision Sensor FH Series Bedienungsanleitung

Omron

Omron Vision Sensor FH Series Bedienungsanleitung

Omron

Omron STC-MBS312POE Montageanleitung

Omron

Omron STC-HD203 Series Montageanleitung

Omron

Omron fh series Bedienungsanleitung

Omron

Omron FJ-300 Series Bedienungsanleitung

Omron

Omron fh-1 series Bedienungsanleitung

Omron

Omron Vision Sensor FH Series Bedienungsanleitung

Omron

Omron FLV IR Series Bedienungsanleitung

Omron

Omron FLV-DB Series Bedienungsanleitung

Omron

Omron FLV-EP Series Bedienungsanleitung

Omron

Omron fh series Bedienungsanleitung

Omron

Omron FH-L550 Bedienungsanleitung

Omron

Omron SYSMAC FH Series Bedienungsanleitung

Omron

Omron CoaXPress STC-MBS510CXP6 Montageanleitung

Omron

Omron FLV-FB Series Bedienungsanleitung

Omron

Omron fh series Bedienungsanleitung

Omron

Omron fh-1 series Bedienungsanleitung

Beliebte Bildverarbeitungssystem Handbücher anderer Marken

Festo

Festo SBOC-M-R1B-H Bedienungsanleitung

Banner

Banner VE200G1B Bedienungsanleitung

SVS-Vistek

SVS-Vistek CoaxPress EoSens Creation 1.1CXP2 Bedienungsanleitung

Sony

Sony Vision Exchange PEQ-C100 Bedienungsanleitung

Datalogic

Datalogic MX-U81 Montageanleitung

Cognex

Cognex In-Sight D900 Series Bedienungsanleitung

Spektrum

Spektrum SPMVR2520 Bedienungsanleitung

Huaray

Huaray Movidius Series Bedienungsanleitung

Daheng Imaging

Daheng Imaging MERCURY2 USB3 Bedienungsanleitung

SVS-Vistek

SVS-Vistek exo174 U3 Series Bedienungsanleitung

Teledyne

Teledyne e2v Eliixa+ Series Bedienungsanleitung

Photron

Photron FASTCAM Mini CX Series Bedienungsanleitung

National Instruments

National Instruments Vision CVS-1455 Bedienungsanleitung

iGen

iGen NV20/20 Bedienungsanleitung

JAI

JAI GO-5100MP-USB Bedienungsanleitung

Ark Vision Systems

Ark Vision Systems AVS-Monitor 7 FHD Bedienungsanleitung

Cognex

Cognex In-Sight 9902L Bedienungsanleitung

Feniex

Feniex C-5500 Bedienungsanleitung

Omron fh series Benutzerhandbuch

Beliebte Bildverarbeitungssystem Handbücher anderer Marken
