PROFINET

Future-proof communication network

» Media redundancy

» Open standard

» Easy configuration

PROFINET – Open Industrial

Ethernet standard for automation

As a leading and innovative global supplier

of industrial automation systems, Omron delivers

equipment for installations throughout the world.

Recognising that needs differ between users,

applications and countries, Omron pursues

an open-standards policy that has proved to be the

key to success. This extends to networking and

connectivity, where we are constantly increasing

our scope. Omron played a pioneering role,

e.g. in developing DeviceNet and CompoNet and

in addition to offering a wide range of products

for CIP-based networks we actively

support PROFIBUS-DP, by far the world’s

most popular system.

Networks, the next generation

Building on our experience with PROFIBUS, Omron

is now a front runner in the support and development

of PROFINET-IO, an open ‘Industrial Ethernet’ solution

set to become Europe’s next-generation field network.

PROFINET-IO meets all requirements of industrial

automation and provides the higher speeds necessary

as intelligent devices become more complex.

PROFINET is more adaptable than conventional bus

systems, enabling users to optimize it for their own

required functionality. Today, Omron is a leader in

bringing PROFINET-compatible modules to the market.

PROFINET cyclic data and standard

UDP or TCP/IP data can share

one cable.

Built-in switches cut cost

Conventionally, Ethernet networks use a star topology, which

requires extra hardware (switches) to interconnect devices.

Omron’s SmartSlice PROFINET-IO Unit gives the option

of linking devices in the conventional line topology used with

most field buses. No additional hardware is needed.

Making use of field devices with an integrated switching

function is a very efficient and cost-saving method that

minimizes the bill of materials and saves on installation costs.

It also facilitates easy system extension in the accustomed

manner when the time arises.

No need to install an industrial

ethernet switch in every control

cabinet.

up to 100 metres between stations

Making Industrial Ethernet easy

PROFINET-IO offers many advantages for both system

integrators and equipment/machinery manufacturers.

Combining the ease of use of PROFIBUS-DP with

a standard Ethernet physical layer, PROFINET-IO offers

the increased speed, easier management of ever-

increasing amounts of device data, and openness for

integrating standard Ethernet data communication.

PROFINET-IO has standardized functions for

parameterization, diagnostics and alarms which are

far more extensive than in conventional bus systems.

To manage this high functionality, OMRON provides

FDT-based software tools, which make PROFINET-IO

as easy to use as a conventional fieldbus system.

PROFINET

TCP/IP

TCP/IP + PROFINET

Plant Management

High availability by ring redundancy

Naturally, PROFINET is inherently reliable in its own right,

but increased reliability of the network connection can

be achieved by closing the line structure to form a ring.

The advantage of a ring structure is that any single cable

failure or malfunction in one device will not lead to

a disruption in communication between other connected

devices. This highly secure method requires one device in

the ring to be a redundancy manager supporting the MRP

(Media Redundancy Protocol) as prescribed in the PROFINET

specification, to assure operation of all devices supporting

ring redundancy.

MRP included

Omron’s SmartSlice remote I/O stations support the MRP

protocol as redundancy clients. They report the status of their

communication connections to the MRP manager. In case

of a connection failure, the MRP manager will activate the

alternative communication path, so that all stations remain

accessible. By including the SmartSlice stations as active

members of the ring, the number of dedicated switches

needed to build a redundancy ring is greatly reduced.

PROFINET-IO – benefit from tomorrow’s

advantages today

One switch as MRP manager

controls the PROFINET-compliant

redundant ring.

Built-in switch with MRP

client function.

MRP clients report interruptions

to the MRP manager, which

activates the stand-by connection

in milliseconds.

Case study: Marine applications

Control system design for ships is going through a rapid

change towards fully integrated automation systems.

Monitoring and control of e.g. power generation, HVAC, pumps

and winches are made fully transparent, and remotely

accessible. Controller- and network redundancy, and toolless

unit replacement are key features of Omron’s PROFINET

solution to ensure maximum system availability.

MRP manager

MRP client MRP client

MRP client

HMI

PLC

Conventional ring structure

MRP manager

SmartSlice with built-in

MRP client

SmartSlice with built-in

MRP client

SmartSlice with built-in

MRP client

HMI

PLC

Ring redundancy with SmartSlice

SmartSLice stations with built in MRP client; greatly reduce

the installation costs.

PROFINET – easy to set up,

with open software tools

Omron products support PROFINET-IO for cyclic master-slave

communication with ‘soft’ real-time characteristics, as

required in general-purpose industrial automation. The most

universal PROFINET variant, PROFINET-IO is similar to fieldbus

communication and offers added flexibility while remaining

easy to use.

One tool for all networks

Ease of use is the key to PROFINET’s success. And if you

currently use Omron’s highly popular CX-One software, you

already own the configuration tools. The network-independent

FDT technology Omron already uses for its PROFIBUS

configuration tool also supports PROFINET.

With PROFIBUS-DP interface units for all main product series

Omron has already integrated PROFIBUS in its ‘Smart

Platform’ solutions. Moreover, Omron’s FDT-based

configuration software, which is open to third-party devices,

offers full access to any parameter in any device,

at any time.

FDT is Open Technology

An FDT program (Field Device Tool) is a network-independent

framework that accepts product-specific plugins from any

vendor provided it is FDT compliant. Called DTMs (Device Type

Managers), these plugins provide a user interface for setting

up and maintaining a device, and handle the communication

over the network. This technology eliminates the need to learn

how to use a new tool when changing bus systems and allows

access to the device-specific features of each vendor’s device

via its own dedicated interface.

Any device that is not provided with a DTM can be configured

using conventional text-based GSDML (XML) files.

GSDML text file

DTM plugin

FDT Group

The FDT Group is an open, independent collaboration

of international companies dedicated to establishing FDT

technology as an international standard within the

automation industry. FDT technology standardizes the

software interface between field devices and engineering

systems. The key feature is its independence from the

communication protocol and the software environment

of either the device or the host system. FDT allows any

device to be accessed from any host through any protocol.

www.fdtgroup.org

PROFINET-IO controller CJ1W-PNT21

This module is designed for use with any CPU unit belonging

to Omron’s highly successful CJ series of programmable logic

controllers. It uses a separate communication processor to

guarantee reliable, high-level performance independent of the

PLC program or its CPU speed. As it is transparent to Omron’s

own FINS communication protocol, the PROFINET IO controller

also provides a communication channel so that legacy devices

or existing software tools can be used to exchange data with

the PLC CPU through the PROFINET controller.

PROFINET-IO device GRT1-PNT

This communication interface for Omron’s SmartSlice remote

I/O system allows up to  SmartSlice units to be mounted per

station. SmartSlice has built-in intelligence that helps users

to reduce engineering time by autonomously monitoring

machine status and performance to help schedule preventive

maintenance. The PROFINET-IO device has two external

network connections to allow direct linking of multiple devices

in a line structure. Built-in support for MRP (Medium

Redundancy Protocol) allows these units to be installed as

an integral part of a redundant ring topology. An optional

dedicated memory end plate allows on-site unit replacement

without the need to reconfigure settings. For more

information: www.smartslice.info

PROFIBUS & PROFINET International (PI)

PI is the international industrial communications

community responsible for PROFINET and PROFIBUS,

two of the most important technologies used

in factory- and process automation today. Sales of

PROFIBUS nodes has passed the  million mark and

currently more than  PI member companies

around the world develop and supply products,

services and solutions for industrial automation

applications. The PI commitment to openness and

standardization guarantees a wide choice of

interchangeable products and stimulates innovation,

ensuring best-in-class performance. And with

 regional PI associations backed up by  PI

Competence Centers and  PI Test Laboratories

providing comprehensive assistance,

a wide range of support is available, including

local training. www.profinet.com
