Omron ZW Series Benutzerhandbuch
Confidential C
AST*-******
ZW Series
For EtherCAT
BECKHOFF PLC
＋
Vision Sensor
Start-up Guide
Rev.A
OMRON Corporation
Application Sensors Division
Development Department
Confidential C
AST*-******
目次
Contents
1. Introduction..........................................................................1
1.1. Outline ............................................................................1
1.2. Object reader..................................................................2
2. Target product......................................................................3
2.1. Target product.................................................................3
2.2. Equipment configuration.................................................5
3. Start-up procedure...............................................................7
3.1. Start-up procedure..........................................................7
3.2. Prerequisite ....................................................................8
4. Configuration of EtherCAT .................................................9
4.1. Hardware configuration of ZW......................................10
4.2. Setting of TwinCAT....................................................... 11
4.3. Confirmation of communication status.........................42
5. Reference............................................................................44
6. Caution................................................................................45
6.1. Explanation about the indications ................................45
7. Revison history..................................................................46
Confidential C
AST*-******
Refusal
（1）Apart of the factors of this, start-up guide or everything is copied, reproduced without
permission, and it is prohibited to reprint.
（2）Because the specifications etc. might be changed without a previous notice for the factors of this,
start-up guide for the improvement. Please acknowledge it beforehand.
About the copyright and the trademark
・EtherCAT is registered trademark and patented technology, licensed by BeckhoffAutomation
GmbH, Germany.
・
The system name and the description of product published in the other and the text are the
trademarks or registered trademarks of each company respectively.
Confidential C
AST*-******
Error! Reference source not found. Error! Reference source not found.
1
1. Introduction
1.1. Outline
This material explains the configuration steps required for the launch of ZW series and
BECKHOFF TwinCAT that you connected to in EtherCAT.
The man-hour of the start-up can be greatly reduced by using this material when starting up.
Detailed setup steps are not described for the following items. It describes to “5. Reference
information”. Please refer to the information.
•Setting method of FQ-M measurement items.
•Setting method and manner of operation ladder program with Twin CAT PLC Control.
•Communication command using EtherCAT.
Reference
What is EtherCAT?
EtherCAT is a super-high-speed fieldbus of the Ethernet base.
The communications zone of 100Mbps full duplex is used to its maximum, and it controls at
high speed of the motor driver such as the servo drivers and inverters.
In addition, not only the driver control but also a real-time control of various I/O like the sensor
and analog I/O, etc. : 1 It achieves it by the horn communication.
Moreover, an accurate synchronous control of accuracy 1μs or less is possible by sharing
time information among connected slaves.
Confidential C
AST*-******
Error! Reference source not found. Error! Reference source not found.
2
1.2. Object reader
This material connects displacement sensor ZW with positional control NC unit with EtherCAT,
and targets wanting do the measurement processing control by the memory driving.
Confidential C
AST*-******
Error! Reference source not found. Error! Reference source not found.
3
2. Target product
2.1. Target product
Confocal Fiber Type displacement sensor
Name Model Version
ZW Controller for Displacement Sensor ZW-CE10
ZW-CE10T
ZW-CE15
ZW-CE15T
ZW Sensor Head for Fiber Coaxial
displacement sensor ZW-S07
ZW-S20
ZW-S30
ZW-S40
Cable Name Model Version
EtherCAT Communication cable *1
(RJ45/RJ45) XS6W-6LSZH8SS□□□CM-Y
XS5W-T421-□MD-K
EtherCAT Communication cable *1
(M12/RJ45, M12 L/RJ45) XS5W-T421-□MC-K
XS5W-T422-□MC-K
*1：EtherCAT Communication cable specification
•Ethernet twisted-pair cable：STP of CAT5 or more.
•Wiring is straight.
•The shielded is a double cover of the aluminum tape and the braid.
•The shielded of the cable is connected with the shielded of both ends and the connector. (both
ends grounding)
Moreover, please use the cable length between TwinCAT and ZW, between ZW and ZW within
100m.
Confidential C
AST*-******
Error! Reference source not found. Error! Reference source not found.
4
Peripheral Name Model Version
TwinCAT －
2.11 R3, Build
2238
PLC unit (Beckhoff)
Name Model Version
Basic CPU Module CX1030-0123 -
DVI/USB CX1030-N010 -
Ethernet×2 CX1030-N000 -
Power Supply CX1100-0014 -
EtherCAT Master unit EK1110 -
Confidential C
AST*-******
Error! Reference source not found. Error! Reference source not found.
5
2.2. Equipment configuration
2.2.1. Equipment configuration
This material has described the start-up procedure when the following equipment
configuration is assumed to be an example.
①PC(TwinCAT) - ZW
Precautions for correct use
There are times when it does not work by the network adapter and the PC is going to be used
for the TwinCAT.
Please use it after confirming that the TwinCAT to operate on the network adapter and your
PC.
Confidential C
AST*-******
Error! Reference source not found. Error! Reference source not found.
6
②PC(TwinCAT) – PLC – ZW
BECKHOFF PLC: Power input method
* When using the TwinCAT, ESI file for ZW will be required separately.
Please download from the following website.
http://www.fa.omron.co.jp/member/product/tool/23/esi/index.htm
＜
FQ-M Sensor (EtherCAT Slave)
＞
It corresponds to the slave of EtherCAT network.
＜
PC
＞
EtherCAT network and the EtherCAT master are set.
Confidential C
AST*-******
3Start-up procedure
7
3. Start-up procedure
3.1. Start-up procedure
This article describes the steps for using Fieldbus of the ZW "EtherCAT", connecting the ZW
and TwinCAT (BECKHOFF).
＜What can be identified using this material＞
(1) How to set up confirmation to use the EtherCAT function
Confirmation of ZW and TwinCAT System Manager
Reference
This document is described for instructions on how to connect to establish communication. It
is not described
how to wire the operation of procedures other than connection, and
installation. This document is not also described with respect to the operation and function of
the device. Please refer to the instruction manual, please contact OMRON.
