User’s Manual
1067/1090/1021+ CCD Scanner
Document Number : 6790-0116
Release Date : Nov06, 1998
1998, SYNTECH INFORMATION Co., Ltd..
All rights reserved. CipherLab is a registered
trademark of SYNTECH INFORMATION Co., Ltd.

WARNING
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV
technician for help.

Table of Contents
1. Introduction................................................................1
2. General Features........................................................2
2.1 Buzzer ................................................................2
2.2 Indicator...............................................................2
2.3 Scan Modes.........................................................2
2.4 Inhibit Time .........................................................4
2.5 Scanner Time-out Duration................................4
2.6 Reading Redundancy...........................................4
2.7 Supported Symbologies......................................4
2.8 Negative Barcodes..............................................5
3. Output Interface.........................................................6
3.1 Keyboard Wedge Interface................................6
3.1.1 Keyboard Type.............................................6
3.1.2 Keyboard Style -Alphabets........................ 6
3.1.3 Keyboard Style –Digits.............................. 7
3.1.4 Capital Lock Status......................................7
3.1.5 Alphabets Transmission..............................8
3.1.6 Digits Transmission....................................8
3.1.7 Inter-Character Delay..................................8
3.2 RS232 Interface..................................................9
3.2.1 Transmission Mode.....................................9
3.2.2 Baud Rate / Parity / DataBits.....................9
3.2.3 Flow Control................................................9
3.2.4 Inter-Character Delay................................10
3.3 Wand Emulation................................................10
3.3.1 Normal Status ............................................10
3.3.2 Bar Status ...................................................10
3.4 PC Term Mode..................................................10
4. Symbology Parameters...........................................12
4.1 Code39 ..............................................................12
4.2 Italy / French Pharmacode................................12
4.3 Industrial / Interleave / Matrix 25....................12
4.4 Codabar................................................................... 13
4.5 UPCE ..............................................................14
4.6 EAN8 ..............................................................14
4.7 UPCA ..............................................................14
4.8 EAN13 ..............................................................15
4.9 MSI ..............................................................15
4.10 Plessey.............................................................16
5. Data Output Format.................................................17

5.1 Character Substitution......................................17
5.2 Prefix / Postfix Code........................................17
5.3 Code ID................................................................... 17
5.4 Length Code ......................................................18
6. Data Editing..............................................................19
6.1 Select Editing Format.......................................19
6.2 Restore Default Format....................................19
6.3 Applicable Conditions......................................20
6.4 Total Number of Fields ....................................20
6.5 Dividing Data into Fields..................................21
6.6 Additional Fields...............................................21
6.7 Field Transmission Sequence..........................21
6.8 End of Format Programming...........................22
6.9 Activate Data Editing Formats.........................22
6.10 Exclusive Data Editing...................................22
6.11 Programming Examples.................................22
7. Configuring 1067/1090/1021+.............................24
7.1 Enter Configuration Mode...............................24
7.2 Default ..............................................................24
7.3 List Setting........................................................24
7.4 Setting Parameter Values.................................25
7.4.1 Numeric Parameters.................................25
7.4.2 Character String Parameters.....................26
7.4.3 Key Type/Status Setting............................26
7.5 Exit Configuration Mode .................................28

1
1. Introduction
This User’s Manual contains all the information
needed to operate and configure the
1067/1090/1021+ CCD Barcode Scanner. It is
divided into two parts. The first part of this manual
describes the operation and programmable features of
the scanner. And the second part of this manual is
used for configuration, it contains the setup barcodes
used to configure the scanner.
The 1067/1090/1021+ is one of the most versatile
and flexible CCD barcode scanner in the world. All
the features and functions required for up to date
barcode reading are included. Owing to the compact
design and extremely low power consumption, this
scanner provides for easy installation and high product
durability. The scanner can not only fulfill the
requirements needed today, but also can suffice for
long term usage. The main functions and features
provided on 1067/1090/1021+ are listed below.
•Barcode Readability : Most popular barcode
symbologies are supported.
•Support negative barcodes.
•Support eight scan modes.
•Programmable Buzzer Volume and Beeping Tone
•Dual Color Indicator
•Multi-Interface Support : KBD Wedge, RS232
(Single/Dual Port), and Wand Emulation
•Programmable Code ID : Code ID can be
individually configured for each symbology.
•Programmable Length Code
•Programmable Prefix Code
•Programmable Postfix Code
•Character Substitution
•Data Editing : Data can be reorganized according to
user programmable formats. Up to three data editing
formats are supported.
•Extremely Low Power Consumption

2
2. General Features
2.1 Buzzer
The buzzer of the scanner beeps differently to indicate
various operating conditions.
•Power On Beep : The CCD scanner will issue a
long beep to indicate a successful power on.
•Good Read Beep : There are four volume levels
and four beeping tones (frequencies) that user can
select from when there is a good read. The available
options are listed below.
Volume : Maximum/Loud/Medium/Minimum
Frequency : 8 / 4 / 2 / 1 kHz
•Error Beep : The scanner will issue a long beep
with a low tone to indicate errors.
•Enter / Exit Configuration Beep : The scanner
will issue 6 beeps upon entering / exiting the
configuration mode.
•Setup Beep : In configuration mode, the scanner
will normally beep twice when a setup barcode is
read. If the particular setup parameter needs more
than one read, the scanner will only issue a short
beep to indicate that there are more setup barcodes
needed to complete the current parameter setting.
2.2 Indicator
There is a dual color indicator on top of the scanner.
Normally it is off, and it will turn red when there is a
good read. The indicator will be green when the
scanner is in configuration mode.
2.3 Scan Modes
There are eight scan modes supported by the CCD
scanner. User can choose the desired scan mode
depending on the application requirements. But, if the
scanner is a switch-less scanner, only Continuous
mode or Testing mode can be selected (other scan
modes involve trigger switch interaction). The
supported scan modes are described below.

3
•Auto Off Mode :The scanner will start
scanning once the switch is triggered. The
scanning continues until either a barcode is
read or a preset scanning period (Scanner
Time-Out Duration) is expired.
•Continuous Mode :The scanner is always
scanning.
•Auto Power Off Mode : The scanner will start
scanning once the switch is triggered. The
scanning continues until a preset scanning
period (Scanner Time-Out Duration) is
expired. Unlike the Auto Off mode, the scanner
will continue to scan and the scanning period is
re-counted each time there is a successful
read.
•Alternate Mode :The scanner will start
scanning once the switch is triggered. The
scanner will continue scanning until the switch
is triggered again.
•Momentary Mode :The scanner will be
scanning as long as the switch is depressed.
•Repeat Mode : The scanner is always scanning
just like Continuous Mode. But now the switch
acts like a “re-transmit button”. If the switch is
triggered within 1 second after a good read, the
same data will be transmit again without
actually reading the barcode. This “re-transmit
button” can be triggered as many times as user
desired, as long as the time between each
triggering does not exceed 1 second. This scan
mode is most useful when the same barcode is
to be read many times.
•Laser Mode :This is the scan mode most
often used on laser scanners. The scanner will
start scanning once the switch is pressed. The
scanning continues until either a barcode is
read,the switch is releasedor a preset scanning
period (Scanner Time-Out Duration) is
expired.

4
•Test Mode : The scanner is always scanning.
The scanner will decode repeatedly even with
the same barcode.
By default, the scan mode is Auto Off mode for
scanners with trigger switch, and is Continuous mode
for switch-less scanners.
2.4 Inhibit Time
If the scanner mode is set to Continuous, Auto Power
Off, Alternate, or Momentary mode, the scanner will
prevent accidentally reading the same barcode twice
by using an Inhibit Time (Blocking Time). The barcode
must be taken away from the scanning line longer than
the Inhibit Time to allow second reading of the same
barcode. This Inhibit Time can be long or short.
2.5 Scanner Time-out Duration
This parameter is used to limit the maximum scanning
period when the scan mode is either Auto Off Mode
or Auto Power Off Mode. This time-out duration is
specified in units of second. The default time-out
duration is ten seconds.
2.6 Reading Redundancy
This parameter is used to specify the levels of reading
(decoding) security. If No Redundancy is selected,
only one successful decoding can make the reading
valid. If Three Times Redundancy is selected, it will
take 3 successful decodes to make the reading valid. It
is obvious that the more redundancy the user selects,
the higher the reading security and thus the slower the
reading speed. The user must compromise between
decoding security and decoding speed if the security
feature is needed.
2.7 Supported Symbologies
Most of the popular barcode symbologies are
supported. Each symbology can be individually
enabled or disabled. The scanner will automatically
discriminate and recognize all the symbologies that
are enabled. The supported barcode symbologies are
listed below.

5
•Code 39 (Standard / Full ASCII)
•Italy Pharmacode
•French Pharmacode
•Industrial 25
•Interleave 25
•Matrix 25
•Codabar (NW-7)
•UPCA (with or without Addon)
•UPCE (with or without Addon)
•EAN8 (with or without Addon)
•EAN13 (with or without Addon)
•Code 93
•Code 128
•EAN 128
•MSI
•Plessey
2.8 Negative Barcodes
The CCD scanner can be configured to read negative
barcodes. Normally, barcodes are printed with the
color of the bars darker than that of the spaces. But
for negative barcodes, they are printed in the opposite
sense just like negative films. The spaces of the
negative barcodes are printed with a color darker than
that of the bars.

6
3. Output Interface
The 1067/1090/1021+ is a multi-interface CCD
scanner. It can be configured as a keyboard wedge
scanner, an RS-232 scanner, or a Wand emulation
scanner. The output interface can be easily changed
simply by replacing appropriate interface cable and
configuring the desired interface type.
3.1 Keyboard Wedge Interface
3.1.1 Keyboard Type
The keyboard wedge interface is enabled by
configuring/selecting keyboard type. The supported
keyboard types are listed below.
•PCAT -US, French German, Italian, Swedish,
Norwegian, UK, Belgium, Spanish, and
Portuguese KBD
•PCXT
•PS2-30
•PS-55
•IBM 5550
•IBM 3477 TYPE (Japanese KBD)
•IBM 34XX,319X & Memorex Telex
(122Keys)
•Wyse Enhance KBD (US, French)
•DEC VT220,320,420
•Macintosh (ADB)
•Hitachi Elles
•NEC 5200
•NEC 9800
•NEC Astra
•Unisys TO-300
•Televideo 965
•ADDS 1010
3.1.2 Keyboard Style -Alphabets
Keyboard layout style can be selected. There are three
options to this setting : default layout (US or English
style), AZERTY layout, and QWERTZ layout. This
setting only works when the keyboard type selected is
for US keyboard. The scanner will make necessary
Andere Handbücher für CCD-1021PLUS
1
Dieses Handbuch passt für folgende Modelle
5
Inhaltsverzeichnis
Andere Output Solutions Scanner Handbücher
