Pacific ScrubMaster 32B Bedienungsanleitung

ScrubMaster 32B/33B

The contents of this manual are based on the latest product information available

at the time of publication. Pacific Steamex reserves the right to make changes or

improvements to its machines without notice.

For new books write to:

Pacific

2259 S. Sheridan

Muskegon, MI 49442-6252

FOR YOUR CONVENIENCE, RECORD THE FOLLOWING IMPORTANT

INFORMATION:

MODEL_________________________________________

SERIAL NUMBER_________________________________

PART NUMBER___________________________________

DATE PURCHASED_______________________________

Parts List & Service Manual

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

MACHINE DRAWINGS & PARTS LISTS

ELECTRICAL SCHEMATICS & PARTS LISTS

CHOPPER CARD & ALARM DESCRIPTIONS

INSPECTIONS & ADJUSTMENTS

WARRANTY

PAGES 2 - 27

PAGES 28 - 31

PAGES 32 - 33

PAGES 34 - 38

PAGE 40

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

TABLE OF CONTENTS

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

BRUSH BASE ASSEMBLY 01

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

DRAWING 01

Item Part Number Description Qt

27 40346270 Cover: Base 1

28 72901002 Carbon Brush Holder 1

29 880952 Carbon Brush Motor 4

30 72901001 Spring 4

31 73501105 Clamp 1

32 73501106 Hook Assembly 1

50 980045 Lock Washer

51 980042 Washer: 6x12

52 980065 Washer: 6x24

53 980053 Lock Washer

54 980069 Washer

55 980039 Washer: 8x17

56 980044 Washer: 9x24

57 924046 Nut: M5

58 924032 Lock Nut: M5

59 924026 Lock Nut: M6

60 924035 Nut: M8

61 924033 Lock Nut: M8

62 964133 Screw: M5x10

63 964107 Screw: M6x16

64 964087 Screw: M6x18

65 70940603 Screw: M6x35

66 964095 Screw: M6x35

67 70980802 Screw: M8x22

68 964090 Screw: M8x25

69 70920501 Screw: M5x30

70 964085 Screw: M8x30

71 964106 Screw: M8x45

Item Part Number Description Qt

1 69816010 Base: Brush Drive 1

2 41601100 Plate 1

3 40301010 Support 2

4 40303310 Support 1

5 40228500 Plate 2

6 41601010 Pipe 2

7 41601070 Blade 1

8 41601080 Blade 1

9 41601060 Coupling 2

10 67616010 Splash Guard 1

11 67020030 Wheel 2

12 69102110 Bushing 2

13 40304110 Support 1

14 69102020 Bushing 1

15 40704030 Support 1

16 69102050 Bushing 2

17 68230300 Motor: 36VDC, Starting w/SN#8671 1

17A A0304001 Brush Mtr Kit to replace 68230900

Mtr used prior to SN#8671.

18 70406064 Key 2

19 69401250 Motor Pulley 2

20 70110012 Belt 1

21 70110013 Belt 1

22 40304040 Support 1

23 67404070 Sheath 1

24 67404210 Pipe 2

25 72913008 Cap 2

26 72913002 Cap 1

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

REDUCTION GEARS ASSEMBLY 02

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

DRAWING 02

Item Part Number Description Qt

1 880980 Brush, Poly

885980 Pad Driver

2 41601110 Flexible Coupling 2

3 69009040 Spacer 6

4 41201040 Flange 2

5 69109040 Bushing 6

6 70800007 O-Ring 2

7 69410150 Pulley 2

8 69011010 Spacer 2

9 70730471 Oil Seal 2

10 70511702 Bearing 4

11 69230010 Spring 2

12 69350100 Bevel Gear Pair Right Red. 1

13 69001120 Spacer 2

14 40205120 Holdfast 4

15 41205020 Support 2

16 70405053 Key 2

17 67400410 Gasket 2

18 74550002 Breather 2

19 883451 Gasket 2

20 40205130 Cover 2

21 67400420 Gasket 2

22 70512501 Bearing 4

23 69001130 Spacer 2

24 41605010 Reduction Gear Box Left 1

25 74550006 Level Plug 2

Item Part Number Description Qt

26 67400180 Gasket 2

27 70738521 Oil Seal 2

28 70800006 O-Ring 2

29 69001100 Spacer 2

30 41201050 Plate 2

31 40205080 Special Washer 2

50 71308004 Washer: 8x18

51 964085 Screw: M8x30

52 980053 Lock Washer

53 980044 Washer: 9x24

54 71308002 Split Washer

55 980069 Washer: 8x3

56 70930801 Screw: M8x18

57 70910602 Screw: M6x10

58 980045 Lock Washer

59 980065 Washer: 6x24

60 980039 Washer: 8x17

61 924030 Washer

62 71021601 Lock Nut

63 964086 Screw: M8x20

64 71110001 Washer: 10x16

65 70911001 Screw: M10x12

A2050013 Reduction Gear Assembly - Right 2

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FRAME ASSEMBLY 03

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

DRAWING 03

Item Part Number Description Qt

1 69903100 Frame 1

2 69903200 Rear Frame 1

3 67050060 Castor Wheel 2

4 69102040 Bushing 2

5 40303280 Shaft 1

6 40303300 Left Lever 1

7 40303260 Lever 1

8 40303270 Blade 1

9 40312270 Pin 4

10 40703260 Bracket 1

11 40303340 Right Arm 1

12 40205080 Special Washer: 8x32x4 1

13 69220190 Spring 2

14 40303040 Pipe 2

15 69210200 Spring 2

16 40303030 Screw: M8x130 2

17 74620001 Pin 2

18 74610001 Fork 2

19 40303350 Left Arm 1

20 40703370 Arm 1

21 40303320 Bar 1

22 40303330 Support 1

23 68816010 Blade 1

24 67616020 Splash Guard 1

25 40618060 Stop Ring 1

26 40703380 Joint 1

27 69106010 Bushing 2

28 888350 Spring 1

29 69102070 Bushing 2

30 40312220 Shaft 1

31 69102270 Bushing 1

32 69102050 Bushing 2

33 69102260 Bushing 1

Item Part Number Description Qt

34 40312280 Rod 1

35 40312240 Lever 1

36 69102250 Bushing 1

37 69220160 Spring 1

38 40312250 Lever 1

39 40312260 Blade 1

40 74100007 Knob 2

41 70230008 Ring - Snap 2

42 887341 Ring - Snap 1

50 980062 Washer: 6x12

51 980069 Lock Washer: 8x3

52 980039 Washer: 8x17

53 980044 Washer: 9x24

54 71110007 Lock Washer

55 980064 Washer: 10x21

56 71114002 Washer: 15x28

57 924063 Nut: M6

58 924050 Lock Nut: M6

59 924035 Nut: M8

60 924033 Loock Nut: M8

61 924053 Nut: M10

62 924055 Lock Nut: M10

63 964064 Screw: M6x16

64 70910623 Screw: M6x60

65 70910806 Screw: M8x22

66 964085 Screw: M8x30

67 964103 Screw: M8x35

68 964106 Screw: M8x45

69 70911001 Screw: M10x12

70 70911004 Screw: M10x22

71 70911025 Screw: M10x55

72 964086 Screw: M8x20

73 964133 Screw: M5x10

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

TRACTION ASSEMBLY

https://harrissupplyind.com-ToOrderPartsCall608-268-8080
