Panasonic ES-SA40-K Bedienungsanleitung
Operating Instructions
Manuel d’utilisation
Rechargeable Shaver
Rasoir rechargeable
Model No.
N° de modèle ES‑SA40
Before operating this unit, please read these instructions completely.
Il est recommandé de lire attentivement ce manuel avant d’utiliser l’appareil.
English 2
Français 11
Español 20
2
English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions
should always be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for an appliance that has fallen into
water. Unplug immediately.
2. Charger unit is not for immersion or for use in shower.
3. Do not place or store appliance where it can fall or be
pulled into a tub or sink. Do not place in or drop into
water or other liquid.
4. Except when charging, always unplug this appliance
from the electrical outlet immediately after using.
5. Unplug this appliance before cleaning.
6. Do not use an extension cord with this appliance.
WARNING
To reduce the risk of burns, fire,
electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is
used by, on, or near children or invalids.
2. Use this appliance only for its intended use as
described in this manual. Do not use attachments not
recommended by the manufacturer.
3. Never operate this appliance if it has a damaged plug,
if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return the appliance
to a service center for examination and repair.
4. Never drop or insert any object into any opening.
3
English
5. Do not use outdoors or operate where aerosol (spray)
products are being used or where oxygen is being
administered.
6. Do not use this appliance with damaged shaving blade
and/or foil, as facial injury may occur.
7. Always attach plug to appliance first, then to outlet. To
disconnect, turn all controls to “off” then remove plug
from outlet.
8. Plug charger directory into receptacle ‑ do not use an
extention cord.
9. Unplug charger before plugging or unplugging
appliance.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Power source: See the name plate on the product.
Motor voltage: 1.2 V DC
Charging time: 8 hours
This product is intended for household use only.
4
English
Important
Before use
This WET/DRY shaver can be used for wet shaving with shaving lather or
for dry shaving.You can use this watertight shaver in the shower and
clean it in water. The following is the symbol of Wet shaver. The symbol
means that the hand‑held part may be used in a bath or shower.
Treat yourself to wet lather shaves for at least three weeks and notice the
difference. Your Panasonic WET/DRY shaver requires a little time to get
used to because your skin and beard need about a month to adjust to
any new shaving method.
Using the shaver
Caution ‑ The outer foil is very thin and can be damaged if not used
correctly. Check that the foil is not damaged before using the shaver. Do
not use the shaver if the foil etc. is damaged as you will cut your skin.
Charging the shaver
Do not use any charging adaptor other than one specifically designed for
this model (RE7‑53). Plug in the adaptor into a household outlet where
there is no moisture and handle it with dry hands. The shaver may
become warm during use and charging. However, this is not a
malfunction. Do not charge the shaver where it will be exposed to direct
sunlight or other heat sources.
Adequate ambient temperature for charging is 0‑40 °C (32‑104 °F).
The charging adaptor is intended to be correctly oriented in a vertical or
floor mount position.
Cleaning the shaver
Warning ‑ Remove the shaver from the charging adaptor before cleaning
it to prevent electric shock.
If you clean the shaver with water, do not use salt water or hot water. Do
not soak the shaver in water for a long period of time. Wipe it with a cloth
dampened with soapy water. Do not use thinner, benzine or alcohol.
Storing the shaver
Remove the shaver from the charging adaptor when storing it. This
appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
5
English
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance. Keep these operating instructions in a safe place.
Parts identification
AProtective cap
BOuter foil section
1Outer foil
2Foil frame
CInner blade
DMain body
3Foil frame release buttons
4Switch lock button
5OFF/ON switch
6Appliance socket
7Trimmer
8Trimmer handle
ECharging adaptor (RE7‑53)
9Charging plug
Charge indicator lamp
6
English
Charging
Charge
Perform the following steps to charge the shaver if it seems to lose the
speed.
You can fully charge the shaver in 8 hours.
A full charge will supply enough power for approx. 7 shaves of 3 minutes
each.
1
1Turn off the shaver and insert it in the
charging adaptor as illustrated.
2
2Plug in the adaptor into a household
outlet.
The charge indicator lamp glows and stays on until the shaver is removed
from the charging adaptor.
•
•
7
English
Using the shaver
Shave
90˚
1
1Depress the switch lock
button and slide the OFF/
ON switch upwards.
2
2Hold the shaver as
illustrated above and
shave.
Start out shaving by applying gentle pressure to your face. Stretch your
skin with your free hand and move the shaver back and forth in the
direction of your beard. You may gently increase the amount of pressure
as your skin becomes accustomed to this shaver. Applying excessive
pressure does not provide a closer shave.
•
Using the trimmer
Slide the trimmer handle up. Place at a right
angle to your skin and move downwards to
trim your sideburns.
8
English
Cleaning
Clean
1. Remove the shaver from the charging
adaptor.
2. Apply some hand soap and some water
to the outer foil.
3. Turn the shaver on.
4. Turn the shaver off after 10‑20 seconds.
5. Remove the outer foil section and turn
the shaver on.
6. Clean the shaver and the outer foil
section with running water.
7. Wipe off any drops of water with a dry
cloth.
8. Dry the outer foil section and the shaver
completely.
9. Attach the outer foil section to the
shaver.
9
English
Replacing the outer foil and the inner blade
outer foil once every year
inner blade once every two years
Replacing the outer foil
1. Press the foil frame release buttons and
lift the outer foil section upwards as
illustrated.
2. Gently push the outer foil in the way as
illustrated. Then it will pop up from the
foil frame.
3. The new outer foil should be slightly
bent and pushed in until it is hooked in
the foil frame.
Replacing the inner blade
1. Press the foil frame release buttons and
lift the outer foil section upwards as
illustrated.
2. Remove the inner blade as illustrated.
Do not touch the edges (metal parts)
of the inner blade to prevent injury to
your hand.
3. Insert the inner blade until it clicks as
illustrated.
•
2 3
10
English
Removing the built-in rechargeable battery
ATTENTION:
A nickel metal hydride battery that is recyclable powers the product you
have purchased. Please call 1‑800‑8‑BATTERY for information on how to
recycle this battery.
RBRC
Ni-MH
T M
Remove the built‑in rechargeable battery before disposing of the shaver.
Do not dismantle or replace the battery so that you can use the shaver
again. This could cause fire or an electric shock. Replace it at an
authorized service center.
Remove the shaver from the charging adaptor when removing the battery.
Perform steps 1to and lift the battery, and then remove it.
•
•
FOR YOUR CONVENIENCE, WE HAVE ESTABLISHED A TOLL-FREE (IN
USA ONLY) NATIONAL ACCESSORY PURCHASE HOT LINE AT 1-800-
332-5368.
IN CANADA, CONTACT PANASONIC CANADA INC. AT THE
ADDRESS OR TELEPHONE NUMBER ON THE BACK PAGE.
