Panasonic KX-PW55CL Bedienungsanleitung

Facsimile with Cordless Phone

Quick Reference Guide

KX-PW55CL

億

人

の

フ

ァ

ク

ス

Model No.

Finding the Controls ………………………………2

Set up ………………………………………………4

Connections ……………………………………4

Recording paper ………………………………6

Setting date and time …………………………8

Setting your facsimile telephone number……8

Setting your logo ………………………………9

Telephone Operations ……………………………10

Facsimile Operations ……………………………11

Setting the Answer Mode…………………………12

Answering Device Functions ……………………13

Using E-mail ………………………………………14

Using Hand Scanner………………………………18

Speciﬁcations ……………………………Back cover

Table of Contents

Finding the Controls

Main unit

Reset key

Function button initiates programming.

Indicates to rotate the search dial.

Select button selects feature settings.

Record button records greeting

message.

Erase button erases a recorded

message.

α-ALPHA5 button accesses α5 services.

Store/Edit button for search dial.

Convert button converts “Hiragana” to

“Kanji” characters.

Resolution button selects the resolution

when faxing or copying.

Enter button enters “Hiragana” and

“Kanji” characters.

Call Memory button & indicator store the

caller ID of an incoming call.

E-Mail button

Replay button listens to recorded

messages.

Auto Answer button

—light on: answering device activated.

—light off: used as a telephone.

Volume buttons adjust ringer, speaker

and handset volume.

Intercom button/Character Input Mode

button

Hold button

Redial/Pause button

Microphone

Speakerphone button

Flash/Clear button

Tone button switches to tone dialing.

Operation Guide/Mute button

Stop button

Search Dial searches in the directory or

displays programming features.

Start/Copy button starts faxing or

copying.

Hand Scanner button

1 2 3 4 56789

10 11

2423

1817

確定

Portable Handset

To make/answer calls.

To change from pulse to tone

dialing.

Search dial, for telephone numbers

stored in memory.

For referring to telephone numbers

when using Number Display Service.

To adjust the volume.

To radial the last number dialed.

To insert a pause.

To make the handset ring first.

To operate the answering device.

To use the private message and

fax features.

Display

displays battery strength,

telephone numbers etc.

In use/charge indicator

To receive faxes.

To page the main unit.

To change the enter mode.

To end call.

To end storing and other

operations.

Used when installing additional

handsets.

When receiving a call

When charging

When charging complete

flashes red

lights red

lights green

くるくる

電話帳

再ダイヤル

To put a call on hold.

To start the search for telephone

numbers, when using Number

Display Service.

To use the speakerphone.

For Call Waiting Service users.

To clear letters/numbers.

To change Hiragana into Kanji.

To store names and telephone

numbers in the search dial.

To edit/delete names and

telephone numbers in the search

dial.

To set quick call.

着信メモリー

音量

変換

機能

登録/修正・確定 スピーカーホン

かな/英

プライベート

増設

キャッチ

/クリア

ファクス

登録/修正

・

確定

プライベートかな



子機1

子機1

(Handset 1)



プライベート



(Private)



英

(English)

Handset number



Displayed when receiving

private massage or fax.

Displayed when entering

characters for the telephone

directory.

(ex)

Displays battery

strength

Battery indicator

(Shows the amount of

battery power left)

To start or stop scanning

Scanning width switchResolution switch

Delete button

(To delete the scanning contents)

Operation indicator

(Shows the condition of the scanner)

Memory indicator

(To show the amount of memory being used)

Hand Scanner

Setup ( Connections )

1Connect AC adaptor to the Charger.

2Connect the battery to the Handset.

3Charge the Handset Battery.

Charge the Handset Battery Insert the Recording paper sub-

tray and Recording paper arm-

spring in the main unit

1Insert the Recording paper sub-tray.

2Insert the Recording paper arm-spring.

Throw down the Recording paper arm-spring.

AC adaptor

Charger

Plug

Set the AC adaptor cord

in the cord guide

Connector

cord

(Black) cord

(Red)

Battery

Put the cord away near the battery

Click

Recording paper

sub-tray

Recording paper tray

Recording paper

arm-spring

Charge indicator

Power outlet

Charging terminals

Connect the main unit Charge the Hand scanner battery

1Pull out the Hand scanner.

2Slide open the battery cover

by slightly pushing part.

3Connect the battery to the Hand scanner.

4Insert the Hand scanner.

Click

(電話回線へ)

回線

電話機



停電用

(電話回線へ)

回線

電話機

停電用

Click

Connect to

回線(line)

Telephone line cord

Pull the antenna take up

Wall jack

Power outlet

Power cord AC 100V

Battery cover

Imaging sensor

Cord (Red)

Cord (Black)

Connector

Battery

Bottom side

Display

読取枚数

枚

ｽｷｬﾅｰ設定中

Telephone line selection (pulse or tone) will start

automatically.

Setup ( Recording paper )

1Open the Control panel by pressing

down the Control panel open button.

2Open the Inner cover by sliding

down the Inner cover open lever.

5Make sure that mark point on the

Release gear is correct, and then close

the Inner cover.

6Close the Control panel and open the

Recording paper cover.

7Fan the stack of paper to prevent a

paper jam, and then insert the paper.

8Throw down the Recording paper cover

and Recording paper arm-spring.

3Prepare the Film cassette.

4Put the Film cassette in the Main unit.

Installing the Plain paper

Control panel

Press down

Inner cover

lnner cover

open lever

Sag Ink film

Correct the ink film sag

by turning the gear

Turn inside out

Film cassette

Red label Red gear Spindles of gears

Bearing Bearing

Mark on the lnner cover

Mark on the release gear

lnner cover

Click

Recording paper cover

Printed on the back of paper

Recording

paper tray

Recording paper cover

Recording paper arm-spring

1Open the Control panel by pressing

down the Control panel open button.

2Open the Inner cover by sliding

down the Inner cover open lever.

3Put the Thermal paper to the Paper

holder by spreading the Paper holder.

4Put the Paper holder in the set position

of the Main unit.

5Insert the Thermal paper to the slit of

Inner cover.

7Close the Control panel

6Make sure that mark point on the

Release gear is correct, and then close

the Inner cover and pull out the Thermal

paper (approx. 5cm) through the outlet

for recording paper.

Installing the Thermal paper

Control panel

Press down

Inner cover

lnner cover

open lever

Paper holder

Correct

Slack

Incorrect

Right sideLeft side

Thermal paper

If the thermal paper has a slack, tighten it by

winding.

Left side

Paper holder

Set position

Right side

Slit

Thermal paper

Outlet

Inner cover

Mark on the lnner cover

Mark on the

release gear

Click

Setup

( Setting date and time, your facsimile telephone number and logo )

You can program the date and time, your facsimile telephone number and logo.

This information will be printed on each page transmitted from your unit.

発信元Micah

Your logo

電話番号：

0987654321 1999.9.1015:45P.1

Date and timeYour facsimile telephone number

1Press .

機能

1Press .

機能

2Press , then .

001

3Enter the correct year/month/day using the dial

keypad.

Example: Sept. 10, 1999

Press

1 9 9 9 0 9 1 0

Setting date and time

Setting your facsimile telephone number

キャッチ／クリア

ストップ

登録

機能

キャッチ／クリア

ストップ

登録

機能

Display : 機能登録

モート゛

Display : 機能登録

モート゛

Cursor

1999

年

月

日

[登録]

2Press , then .

004

Cursor

TEL

............

1999

年

月

日

[登録]

3Enter your facsimile telephone number, up to

20 digits, using the dial keypad.

Example :

TEL

98 765 4321 .

4Press .

登録

5Enter the correct hour/minute by selecting

2 digits for each, using the dial keypad.

Example: 15:45

1. Press

1 5 4 5

時刻

00：00

[登録]

4Press .

登録

TEL

098 765 4321

登録

しました

時刻

15：45

[登録]

6Press .

登録

登録

しました

7Press .

ストップ

月

日

15：45

用件録音

件

5Press .

ストップ

Setting your logo

1Press .

機能

2Press , then .

002

3Press repeatedly to choose

the「英」(English) character.

子機

かな/英

Display : 機能登録

モート゛

名前（印字用）

＞＿

キャッチ／クリア

ストップ

登録

機能

くるくる電話帳

子機

かな／英

「かな」(Hiragana)

↓

「カナ」(Katakana)

↓

「英」 (English)

↓(Numbers)

4Enter your logo, up to 30 characters, using the dial

keypad. See the table below for details.

Example: Micah

1 Press once

2 Press six times.

3 Press six times.

4 Press to move the cursor to the next space

and press four times.

5 Press ﬁve times

Cursor

Mic

Mica

Micah

5Press .

登録

Micah

登録

しました

6Press .

ストップ

Characters that you can enter (Character List)

、。! ？ー#, ; :/｜・

（）［］｛｝〈〉「」

Character

Dial key

「かな」(Hiragana)

ワヲン゛°、。ー

「英」(English)「カナ」(Katakana)

あいうえおぁぃぅぇぉ

かきくけこ

さしすせそ

たちつてとっ

なにぬねの

はひふへほ

まみむめも

やゆよゃゅょ

らりるれろ

わをん゛°、。ー

アイウエオァィゥェォ @ . ｰ  & ＄ ¥ %＋= 〜^

DEFde f

GHI gh i

JKL j kl

MNOmn o

PQRSpqrs

TUVtuv

WX Y Z wx y z

カキクケコ

サシスセソ

タチツテトッ

ナニヌネノ

ハヒフヘホ

マミムメモ

ヤユヨャュョ

ラリルレロ

(Numbers)

︵

濁

点

︶

︵

半

濁

点

︶

︵

濁

点

︶

︵

半

濁

点

︶

ABCabc

Each time a dial key is pressed, the character set to that dial key will be shown in order.

1Making/Answering voice calls

Telephone Operations

Making calls

1. Lift the handset or press

(speakerphone).

2. Dial the telephone number.

3. Talk to the other party.

4. When ﬁnished, replace the handset or press

Answering calls

1. When the phone rings, lift the handset or

press .

2. Talk to the other party.

3. When ﬁnished, replace the handset or press

Note:

When a slow beep or no sound is heard, press

(start/copy) and replace the handset.

The unit will start fax reception.

ファクス

／コピー

スタート

スピーカーホン

Handset

Microphone

操作案内

／ミュート

スピーカーホン

2Automatic dialing

くるくる

電話帳

スピーカーホン

Handset

スピーカーホン

ファクス

／コピー

スタート

くるくる電話帳

ストップ

Main unit Portable handset

Automatic dialing with the main unit

1. Rotate (search dial) until the name you

want to dial appears on the display.

2. Lift the handset or press

(speakerphone).

3. Talk to the other party.

4. When ﬁnished, replace the handset or press

スピーカーホン

くるくる電話帳

Storing a phone number in the main unit

1. Press (telephone directory

store/edit).

2. Enter the station name, up to 12 characters,

using the dialing buttons.

3. Press .

4. Enter the phone number up to 30 digits.

5. Press .

– To program other stations, repeat from

step 2.

6. Press .

7. Enter the group number (1-9).

8. Press .

登録/修正



登録/修正



登録/修正



登録/修正



登録/修正



登録/修正



Automatic dialing with the portable handset

1. Rotate (search dial) until the name you

want to dial appears on the display.

●If the name has not been stored, press

(end) and store the name, or dial the

number manually.

2. Press (outside line) or

(speakerphone).

➡The number will be dialed.

●The last 12 digits (including spaces) will be

displayed.

3. Talk to the other party.

4. When ﬁnished, press .

スピーカーホン

くるくる

電話帳

Storing a phone number in the portable

handset

1. Press (store/edit/decide).

●xx will show how many items can still be

stored.

2. Use the dial buttons to enter the desired

name, up to 12 characters.

●If you do not want to store a name, go to

step 3.

3. Press .

4. Use the dial buttons to enter the phone

number, up to 30 digits.

Press (volume) to insert a space.

●If you enter a wrong number, press

(clear).

●If you enter 12 or more digits (including

spaces), numbers will disappear from the

screen from the left.

5. Press (store/edit/decide).

●To enter a 2nd or 3rd number, repeat from

step 4.

登録/修正・確定

音量

登録/修正・確定

キャッチ

/クリア

Inhaltsverzeichnis

Andere Panasonic Faxgerät Handbücher

Panasonic

Panasonic Panafax UF-585 Bedienungsanleitung

Panasonic

Panasonic Panafax UF-755 Bedienungsanleitung

Panasonic

Panasonic KX-F80 Bedienungsanleitung

Panasonic

Panasonic UF 885 - Panafax B/W Laser Bedienungsanleitung

Panasonic

Panasonic KX-FC962FX Bedienungsanleitung

Panasonic

Panasonic KX-FLM652CX Bedienungsanleitung

Panasonic

Panasonic KX-FB421 Bedienungsanleitung

Panasonic

Panasonic KX-FP105BX Bedienungsanleitung

Panasonic

Panasonic KX-FLM551E Bedienungsanleitung

Panasonic

Panasonic Panafax UF-490 Bedienungsanleitung

Panasonic

Panasonic Panafax UF-4000 Bedienungsanleitung

Panasonic

Panasonic UF-6950 - Panafax - Multifunction Handbuch

Panasonic

Panasonic KX-PD502DL Bedienungsanleitung

Panasonic

Panasonic KX-FLB881E Bedienungsanleitung

Panasonic

Panasonic KX-F800 Bedienungsanleitung

Panasonic

Panasonic KX-F750 Bedienungsanleitung

Panasonic

Panasonic KX-FP373FX Bedienungsanleitung

Panasonic

Panasonic KX-FHD351 Bedienungs- und Montageanleitung

Panasonic

Panasonic KX-FLB758HK Bedienungsanleitung

Panasonic

Panasonic KX-FP81AL Bedienungsanleitung

Panasonic

Panasonic KX-PW110CL Bedienungsanleitung

Panasonic

Panasonic DX 1000 - PanaFax B/W Laser Printer Bedienungsanleitung

Panasonic

Panasonic KX-FLB852CX Bedienungsanleitung

Panasonic

Panasonic UF 890 - Panafax B/W Laser Bedienungsanleitung

Beliebte Faxgerät Handbücher anderer Marken

Samsung

Samsung SF-515 Bedienungsanleitung

Radio Shack

Radio Shack TFX-1031 Bedienungsanleitung

imagistics

imagistics 2030 Handbuch

Furuno

Furuno FAX-30 Bedienungsanleitung

Savin

Savin 3740 Handbuch

Sharp

Sharp FO-51 Bedienungsanleitung

Muratec

Muratec MFX-C3035 Bedienungsanleitung

Canon

Canon FAX-L400 Bedienungsanleitung

Ricoh

Ricoh 1000L Kurzanleitung

Sharp

Sharp FO-3150 Bedienungsanleitung

Kyocera

Kyocera KM-F1060 Bedienungsanleitung

Sharp

Sharp FO-2970M Bedienungsanleitung

Canon

Canon JX510P Bedienungsanleitung

Mita

Mita LDC-870 Handbuch

Brother

Brother MFC 640CW - Color Inkjet - All-in-One Bedienungsanleitung

Samsung

Samsung FX100 Handbuch

Sharp

Sharp MX-FXX1 Bedienungsanleitung

Develop

Develop ineo 25e Bedienungsanleitung
