Connections

1Connect the AC adaptor to the power outlet.

Base unit

Connect the AC adaptor to the unit by pressing the plug firmly.

Fasten the cord by hooking it.

Connect the AC adaptor to the power outlet.

Connect the telephone line cord to the unit, then to the single-line telephone jack (RJ11C) until you hear a click.

A DSL/ADSL filter (not supplied) is required if you have a DSL/ADSL service.

Note:

Use only the supplied Panasonic AC adaptor PNLV226.

Charger

Model No. KX-TGF572/KX-TGF573

KX-TGF574/KX-TGF575

KX-TG785SK

Quick Guide

TGF57x_QG(en).fm Page 1 Monday, November 21, 2016 11:54 AM

– 2 –

Battery installation/Battery charging

Charge for about 7 hours.

Note:

LUSE ONLY rechargeable Ni-MH batteries AAA (R03) size

().

LDo NOT use alkaline/manganese/Ni-Cd batteries.

LConfirm correct polarities (S, T).

LFollow the directions on the display to set up the unit.

LConfirm “Charging”is displayed

()

Removing the battery

TGF57x_QG(en).fm Page 2 Monday, November 21, 2016 11:54 AM

– 3 –

Operating tips

Soft keys

By pressing a soft key, you can select the feature shown directly above it on the display. Pay

attention to the display to see what functions the soft keys are assigned during operation.

Navigator key

Handset:

−{^}, {V}, {<}, or {>}: Scroll through various lists and items.

−VOL. (Volume: {^} or {V}): Adjust the receiver or speaker volume while talking.

−{<}k: View the phonebook entry.

−{>}REDIAL: View the redial list.

−{V} CID (Caller ID): View the caller list.

Base unit:

−{^}, {V}, {7}, or {8}: Scroll through various lists and items.

−VOLUME ({^} or {V}): Adjust the speaker volume while talking.

−{7}/{8}: Repeat/skip messages during playback.

Handset Base unit

Date and time (Handset)

1{MENU}(1)1

2Enter the current month, date, and year. s{OK}

3Enter the current hour and minute (12-hour clock format).

4*: Select “AM”or “PM”. s{SAVE}s{OFF}

Recording your greeting message of the answering system for

the landline (Handset)

You can record your own greeting message instead of using a pre-recorded greeting message.

1{MENU}(3)2s{r}: “Yes”s{SELECT}

2After a beep sounds, hold the handset about 20 cm (8 inches) away and speak clearly into

the microphone (2 minutes max.).

3Press {STOP}to stop recording. s{OFF}

{V}

{^}

{<}{>}{V}

{^}

{7}{8}

TGF57x_QG(en).fm Page 3 Monday, November 21, 2016 11:54 AM

– 4 –

Link to cell

You can connect your base unit and cellular phone using Bluetooth®wireless technology, so that

you can make or answer cellular calls using your phone system. For more details, please visit our

Web site: http://shop.panasonic.com/bluetooth-phone

LLocate your cellular phone near the base unit. If the cellular phone is too close to the base unit

during a cellular call, you may hear noise. For best performance, we recommend placing the

cellular phone between 0.6 m to 3 m (2 feet to 10 feet) away from the base unit.

1Cell line

2Cell phone service providers

Pairing a Bluetooth cellular phone

1Base unit:

Press and hold {CELL 1}or {CELL 2}for about 5 seconds.

LAfter the corresponding CELL indicator on the base unit starts flashing, the rest of the

procedure must be completed within 5 minutes.

2Your cellular phone:

While the corresponding CELL indicator is flashing, follow the instructions of your cellular

phone to enter the pairing mode.

LDepending on your cellular phone, it may ask you to enter the Bluetooth PIN (default:

“0000”). If your cellular phone shows PassKey confirmation on its display, follow the

directions to proceed.

3Base unit:

Wait until a long beep sounds.

LIt may take more than 10 seconds to complete pairing.

LWhen the corresponding CELL indicator lights up, the cellular phone is connected to the

base unit. You are ready to make cellular calls.

Note:

LMake sure that your cellular phone is set to connect to this product automatically. Refer to your

cellular phone’s operating instructions.

Trademarks

LThe Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,

and any use of such marks by Panasonic Corporation is under license.

LAll other trademarks identified herein are the property of their respective owners.

TGF57x_QG(en).fm Page 4 Monday, November 21, 2016 11:54 AM

– 5 –

Base unit: CELL indicators

Status Meaning

On A cellular phone is connected. Ready to make/receive cellular

calls.

Flashing −The cellular line is in use.

−Phonebook entries are being copied from a cellular phone.

−The base unit is searching for the paired cellular phone.

−The base unit is pairing a cellular phone.

−A cellular call is on hold.

−The remote voice assist feature is in use.

Flashing rapidly A cellular call is being received.

Light off −A cellular phone is not paired to the base unit.

−A cellular phone is not connected to the base unit.

Handset: Link to cell display items

td−A cellular line is in use.*1

LWhen flashing: The cellular call is on hold.

LWhen flashing rapidly: A cellular call is being received.

−The remote voice assist feature is in use.

*1 Corresponding cellular lines (1, 2: cellular line) are indicated next to the item.

xdA cellular phone is connected.*1 Ready to make/receive cellular calls.

LWhen turned off: A cellular phone is not connected to the base unit.

*1 Corresponding cellular lines (1, 2: cellular line) are indicated next to the item.

uv −A cellular call is in progress on that line.

−The cellular line is selected for the setting.

Base unit: Link to cell display items

uv −A cellular call is in progress on that line.

−The cellular line is selected for the setting.

A Bluetooth headset is connected to the base unit. It is ready for use.

A Bluetooth headset is in use.

Link to cell

TGF57x_QG(en).fm Page 5 Monday, November 21, 2016 11:54 AM

– 6 –

Connecting/disconnecting the cellular phone (Handset)

Auto connection to the Bluetooth devices (cellular phones)

The unit connects to the Bluetooth devices at regular intervals if the connection is lost. To change

the interval (default: “1 min”), see the operating instructions.

LWhen 3 Bluetooth devices (2 cellular phones and 1 headset) are paired to the base unit, only

2 Bluetooth devices can be used with the unit at the same time, and the base unit loses its

connection from other Bluetooth devices. To automatically resume the connection to Bluetooth

devices, leave the auto connection on.

Connecting/disconnecting the cellular phone manually

If you will not be using the paired cellular phone’s link to cell feature temporarily (for example, you

do not want the unit to ring when your cellular line receives a call), you can disconnect your

cellular phone from the base unit. If you want to use it again, reconnect the cellular phone to the

base unit.

LAfter you disconnect a paired cellular phone from the base unit manually, it will automatically

be connected to the base unit in 30 minutes. If you do not use the link to cell feature anymore,

unpair the cellular phone.

LA disconnected cellular phone is not unpaired from the base unit, so pairing it to the base unit

again is unnecessary.

1To connect/disconnect:

For CELL 1: {MENU}(6251

For CELL 2: {MENU}(6252

LA long beep sounds.

2{OFF}

Cellular line only mode (If you do not use the landline) (Handset)

If you do not use the landline, we recommend setting the unit to the cellular line only mode. The

default setting is “Off”.

LIf you turn on the “Cell line only mode”, disconnect the telephone line cord from the base

unit. Otherwise the “Cell line only mode”cannot be activated.

1{MENU}(157

2To turn on:

{r}: “On”s{SELECT}s{r}: “Yes”s{SELECT}

To turn off:

{r}: “Off”s{SELECT}

Link to cell

TGF57x_QG(en).fm Page 6 Monday, November 21, 2016 11:54 AM

– 7 –

Basic operations

Making/Answering calls (Handset)

Making cellular calls 1Dial the phone number. s{CELL}

LWhen the cellular line only mode is set, you can also press

{C}/{s} instead of {CELL}.

LWhen only 1 cellular phone is paired, the unit starts dialing.

2When 2 cellular phones are paired:

{r}: Select the desired cellular phone. s{SELECT}

Making landline calls Dial the phone number. s{C}/{s}

Answering calls {C}/{s}

To hang up {OFF}

To adjust the receiver/

speaker volume

Press {^} or {V} repeatedly while talking.

Making a call using the

redial list

1{>}REDIAL s{r}: Select the desired entry.

2To make a cellular call:

When only 1 cellular phone is paired: {CELL}

When 2 cellular phones are paired:

{CELL}s{r}: Select the desired cellular phone. s

{SELECT}

To make a landline call:

{C}

To adjust the ringer volume

(cellular line/landline)

Press {^} or {V} repeatedly to select the desired volume while

ringing.

Making/Answering calls (Base unit)

Making cellular calls Dial the phone number. s{CELL 1}/{CELL 2}

LWhen the cellular line only mode is set, you can also press

{s} without pressing {CELL 1}/{CELL 2}.

Making landline calls Dial the phone number. s{s}

Answering calls {s}

To hang up {s}

To adjust the speaker

volume

Press {^} or {V} repeatedly while talking.

Making a call using the

redial list

1{REDIAL}s{r}: Select the desired entry.

2To make a cellular call: {CELL 1}/{CELL 2}

To make a landline call: {s}

To adjust the ringer volume

(cellular line/landline)

Press {^} or {V} repeatedly to select the desired volume while

ringing.

TGF57x_QG(en).fm Page 7 Monday, November 21, 2016 11:54 AM

– 8 –

Phonebook (Handset)

Adding entries 1{<}

s{MENU}

2{r}: “Add new entry”s{SELECT}

3Enter the party’s name (16 characters max.). s{OK}

4Enter the party’s phone number (24 digits max.). s{OK}

5{r}: Select the desired group. s{SELECT}2 times s

{OFF}

LIn step 3, you can switch the language for entering characters.

(s{r}: Select the desired language. s{OK}

Making calls 1{<}

s{r}: Select the desired entry.

2To make a cellular call:

When only 1 cellular phone is paired: {CELL}

When 2 cellular phones are paired:

{CELL}s{r}: Select the desired cellular phone. s

{SELECT}

To make a landline call:

{C}

Phonebook (Base unit)

Making calls 1{

}s{r}: Select the desired entry.

2To make a cellular call: {CELL 1}/{CELL 2}

To make a landline call: {s}

Answering system for the landline (Base unit)

Answering on/off Press {ANSWER ON/OFF}to turn on/off the answering system.

Listening to messages {P}(PLAY)

Answering system for the landline (Handset)

Listening to messages To listen to new messages:

{PLAY}or {MENU}(323

To listen to all messages:

{MENU}(324

Basic operations

TGF57x_QG(en).fm Page 8 Monday, November 21, 2016 11:54 AM

– 9 –

Using Bluetooth devices

Copying phonebook entries from a Bluetooth cellular phone (phonebook transfer)

You can copy phonebook entries from the paired cellular phones or other cellular phones (not

paired) to the unit’s phonebook.

1Handset: {MENU}(618

2Handset:

To copy from paired cellular phones:

{r}: Select the desired cellular phone. s{SELECT}

LCopied items are stored to the group (“Cell 1”or “Cell 2”) which the cellular phone is

paired to.

To copy from other cellular phones (not paired):

{r}: “Other cell”s{SELECT}s{r}: Select the group you want to copy to. s

{SELECT}

3Handset:

When “Use the cell to transfer phone book”is displayed: Go to step 4.

When “Select mode”menu is displayed:

{r}: Select “Auto”or “Manual”. s{SELECT}

“Auto”: Download all entries from the cellular phone automatically. Go to step 5.

“Manual”: Copy entries you selected.

L“Select mode”menu is displayed only when the cellular phone supports Phone Book

Access Profile (PBAP) for Bluetooth connection.

4Cellular phone:

Follow the instructions of your cellular phone to copy phonebook entries.

LFor other cellular phones (not paired), you need to search for and select the base unit. The

Bluetooth PIN (default: “0000”) may be required. If your cellular phone shows PassKey

confirmation on its display, follow the directions to proceed.

LThe entries being copied are displayed on the handset.

5Handset:

Wait until “Completed”is displayed. s{OFF}

TGF57x_QG(en).fm Page 9 Monday, November 21, 2016 11:54 AM

– 10 –

Using a Bluetooth headset (optional)

By pairing a Bluetooth headset to the base unit, you can enjoy hands-free conversations when

talking on landline calls.

LOnly 2 Bluetooth devices can be used with the unit at the same time (for example, 2 cellular

lines, or the headset and 1 cellular line*1).

*1 You cannot use a Bluetooth headset to talk on a cellular line.

Pairing a Bluetooth headset to the base unit

1Bluetooth headset:

Set your headset to pairing mode.

LRefer to your headset’s operating instructions.

2Handset:

{MENU}(621

1Pair using the handset.

2Pairing

3If your headset PIN is “0000”, go to step 4.

If your headset PIN is not “0000”, press {CLEAR}, then enter your headset’s PIN.

LTypically, default PIN is “0000”. Refer to your headset’s operating instructions.

4Press {OK}, then wait until a long beep sounds. s{OFF}

LWhen is displayed on the base unit, the headset is available for use.

Operating a Bluetooth headset using a landline

LRefer to your headset’s operating instructions for details.

LSome features described here may not be available depending on Bluetooth headset.

NMaking landline calls with your headset (Base unit)

1Press your headset’s button referring to your headset’s operating instructions.

2Dial the phone number using the base unit after hearing the dial tone on your headset.

3When you finish talking, press your headset’s button referring to your headset’s operating

instructions.

NAnswering landline calls with your headset

To answer a landline call, press your headset’s button.

When you finish talking, press your headset’s button.

LIf you cannot hang up the call using your headset, press {s} on the base unit 2 times.

NSwitching between the base unit and your headset

You can switch between the base unit and your headset:

−during a landline call with the base unit speakerphone.

−during an intercom call between the base unit and handset.

−while listening to messages recorded on the base unit answering system.

To switch to your headset:

Press {}on the base unit.

To switch to the base unit:

Press {s} on the base unit.

Using Bluetooth devices

TGF57x_QG(en).fm Page 10 Monday, November 21, 2016 11:54 AM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Panasonic Telefon Handbücher

Panasonic

Panasonic KXDT321 - DIGITAL PROPRIETARY TELEPHONE Bedienungsanleitung

Panasonic

Panasonic KX TPA 60 Bedienungsanleitung

Panasonic

Panasonic KX TS208W Bedienungsanleitung

Panasonic

Panasonic KX-NS1000 Betriebsanleitung

Panasonic

Panasonic KX-TDA50 Bedienungsanleitung

Panasonic

Panasonic KX-TS2308HGW Bedienungsanleitung

Panasonic

Panasonic KX-T7050E Bedienungsanleitung

Panasonic

Panasonic KX-TGB110E Bedienungsanleitung

Panasonic

Panasonic KX-TC1720B Bedienungsanleitung

Panasonic

Panasonic KX-TG6381LBB Bedienungsanleitung

Panasonic

Panasonic KX-TD7895 - Digital Spread Spedtrum... Bedienungsanleitung

Panasonic

Panasonic KX-TS4300 Bedienungsanleitung

Panasonic

Panasonic KX-NT265 Bedienungsanleitung

Panasonic

Panasonic KX-TC1201BXB Bedienungsanleitung

Panasonic

Panasonic KX-UT670 Handbuch

Panasonic

Panasonic 2LINE KX-TG6700 Bedienungsanleitung

Panasonic

Panasonic KX-TS500MXB Bedienungsanleitung

Panasonic

Panasonic KX-T7565NE Bedienungsanleitung

Panasonic

Panasonic KX-TCD725AXM Bedienungsanleitung

Panasonic

Panasonic DBS 576 Bedienungsanleitung

Panasonic

Panasonic EASA-PHONE KX-T61630 Bedienungsanleitung

Panasonic

Panasonic Link2Cell KX-TGD862 Bedienungsanleitung

Panasonic

Panasonic KX-TG1283BXS Bedienungsanleitung

Panasonic

Panasonic 600 BASE UNIT Bedienungsanleitung

Beliebte Telefon Handbücher anderer Marken

GE 2-9480 Bedienungsanleitung

Geemarc

Geemarc PHOTOPHONE 155 Bedienungsanleitung

D-Link

D-Link DWR-720/PW Bedienungsanleitung

Interquartz

Interquartz Gemini IQ333 Bedienungsanleitung

SSS Siedle

SSS Siedle HT 840-0 Bedienungsanleitung

Motorola

Motorola TITANIUM Bedienungsanleitung

LG H870DS Bedienungsanleitung

Samsung

Samsung GT-I9500 Bedienungsanleitung

AT&T

AT&T Trimline 205 Bedienungsanleitung

Selta

Selta zenyth 600 Bedienungsanleitung

Doro

Doro AFTI 20 Bedienungsanleitung

UNIQCELL

UNIQCELL A1 Bedienungsanleitung

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Bedienungsanleitung

BT Decor 425 Bedienungsanleitung

NEC

NEC SV8500 Bedienungsanleitung

Teledex

Teledex PEARL Bedienungsanleitung

Ericsson

Ericsson Dialog 3213 Bedienungsanleitung

Yealink

Yealink VP530 Bedienungsanleitung
