PCB Piezotronics IMI SENSORS 691B40 Bedienungsanleitung

Model 691B40

Switch Box Module

Installation and Operating Manual

For assistance with the operation of this product,

contact PCB Piezotronics, Inc.

Toll-free: 800-959-4464

24-hour SensorLine: 716-684-0001

Fax: 716-684-3823

E-mail: [email protected]

Web: www.imi-sensors.com

The information contained in this document supersedes all similar information that

may be found elsewhere in this manual.

Total Customer Satisfaction –PCB

Piezotronics guarantees Total Customer

Satisfaction. If, at any time, for any

reason, you are not completely satisfied

with any PCB product, PCB will repair,

replace, or exchange it at no charge.

You may also choose to have your

purchase price refunded in lieu of the

repair, replacement, or exchange of the

product.

Service –Due to the sophisticated

nature of the sensors and associated

instrumentation provided by PCB

Piezotronics, user servicing or repair is

not recommended and, if attempted,

may void the factory warranty. Routine

maintenance, such as the cleaning of

electrical connectors, housings, and

mounting surfaces with solutions and

techniques that will not harm the

physical material of construction, is

acceptable. Caution should be observed

to insure that liquids are not permitted to

migrate into devices that are not

hermetically sealed. Such devices

should only be wiped with a dampened

cloth and never submerged or have

liquids poured upon them.

Repair –In the event that equipment

becomes damaged or ceases to

operate, arrangements should be made

to return the equipment to PCB

Piezotronics for repair. User servicing or

repair is not recommended and, if

attempted, may void the factory

warranty.

Calibration –Routine calibration of

sensors and associated instrumentation

is recommended as this helps build

confidence in measurement accuracy

and acquired data. Equipment

calibration cycles are typically

established by the users own quality

regimen. When in doubt about a

calibration cycle, a good “rule of thumb”

is to recalibrate on an annual basis. It is

also good practice to recalibrate after

exposure to any severe temperature

extreme, shock, load, or other

environmental influence, or prior to any

critical test.

PCB Piezotronics maintains an ISO-

9001 certified metrology laboratory and

offers calibration services, which are

accredited by A2LA to ISO/IEC 17025,

with full traceability to SI through

N.I.S.T. In addition to the normally

supplied calibration, special testing is

also available, such as: sensitivity at

elevated or cryogenic temperatures,

phase response, extended high or low

frequency response, extended range,

leak testing, hydrostatic pressure

testing, and others. For information on

standard recalibration services or

special testing, contact your local PCB

Piezotronics distributor, sales

representative, or factory customer

service representative.

Returning Equipment –Following

these procedures will insure that your

returned materials are handled in the

most expedient manner. Before

Warranty, Service, Repair, and

Return Policies and Instructions

returning any equipment to PCB

Piezotronics, contact your local

distributor, sales representative, or

factory customer service representative

to obtain a Return Warranty, Service,

Repair, and Return Policies and

Instructions Materials Authorization

(RMA) Number. This RMA number

should be clearly marked on the outside

of all package(s) and on the packing

list(s) accompanying the shipment. A

detailed account of the nature of the

problem(s) being experienced with the

equipment should also be included

inside the package(s) containing any

returned materials.

A Purchase Order, included with the

returned materials, will expedite the

turn-around of serviced equipment. It is

recommended to include authorization

on the Purchase Order for PCB to

proceed with any repairs, as long as

they do not exceed 50% of the

replacement cost of the returned

item(s). PCB will provide a price

quotation or replacement

recommendation for any item whose

repair costs would exceed 50% of

replacement cost, or any item that is not

economically feasible to repair. For

routine calibration services, the

Purchase Order should include

authorization to proceed and return at

current pricing, which can be obtained

from a factory customer service

representative.

Warranty –All equipment and repair

services provided by PCB Piezotronics,

Inc. are covered by a limited warranty

against defective material and

workmanship for a period of one year

from date of original purchase. Contact

PCB for a complete statement of our

warranty. Expendable items, such as

batteries and mounting hardware, are

not covered by warranty. Mechanical

damage to equipment due to improper

use is not covered by warranty.

Electronic circuitry failure caused by the

introduction of unregulated or improper

excitation power or electrostatic

discharge is not covered by warranty.

Contact Information –International

customers should direct all inquiries to

their local distributor or sales office. A

complete list of distributors and offices

can be found at www.pcb.com.

Customers within the United States may

contact their local sales representative

or a factory customer service

representative. A complete list of sales

representatives can be found at

www.pcb.com. Toll-free telephone

numbers for a factory customer service

representative, in the division

responsible for this product, can be

found on the title page at the front of this

manual. Our ship to address and

general contact numbers are:

PCB Piezotronics, Inc.

3425 Walden Ave.

Depew, NY14043 USA

Toll-free: (800) 828-8840

24-hour SensorLineSM: (716) 684-0001

Website: www.pcb.com

E-mail: [email protected]

PCB工业监视和测量设备 - 中国RoHS2公布表

PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table

部件名称

有害物质

铅(Pb)

汞

(Hg)

镉

(Cd)

六价铬(Cr(VI))

多溴联苯 (PBB)

多溴二苯醚(PBDE)

住房

PCB板

电气连接器

压电晶体

环氧

铁氟龙

电子

厚膜基板

电线

电缆

塑料

焊接

铜合金/黄铜

本表格依据 SJ/T 11364 的规定编制。

O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。

X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。

铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。

CHINA RoHS COMPLIANCE

DOCUMENT NUMBER: 21354

DOCUMENT REVISION: C

ECN: 45605

Component Name

Hazardous Substances

Lead

(Pb)

Mercury

(Hg)

Cadmium

(Cd)

Chromium VI

Compounds

(Cr(VI))

Polybrominated

Biphenyls

(PBB)

Polybrominated

Diphenyl

Ethers (PBDE)

Housing

PCB Board

Electrical

Connectors

Piezoelectric

Crystals

Epoxy

Teflon

Electronics

Thick Film

Substrate

Wires

Cables

Plastic

Solder

Copper Alloy/Brass

This table is prepared in accordance with the provisions of SJ/T 11364.

O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit

requirement of GB/T 26572.

X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above

the limit requirement of GB/T 26572.

Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.

INDUSTRIAL MONITORIN

G INSTRUMENTATION D

IVISION

SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING

The Model 691B40 Twelve Channel Switch Box Module

Operating Guide with Enclosed Warranty Information

3425 Walden Avenue, Depew, New York 14043-2495

Phone (716) 684-0003

Fax (716) 684-3823

Toll Free Line 1-800-959-4IMI

MANUAL NUMBER: 18419

MANUAL REVISION: NR

INDUSTRIAL MONITORING INSTRUMENTATION DIVISION

PAGE 2

SENSORS AND INSTRUME

NTATION FOR MACHINE

CONDITION MONITORING

table of contents

Description ....................................................................................................................... page 3

Installation........................................................................................................................ page 3

Calibration........................................................................................................................ page 3

Terminal Strip Wiring........................................................................................................ page 4

ESD Warning Information................................................................................................. page 5

warranty/servicing

Warranty, Service & Return Procedure............................................................................ page 6

Customer Service............................................................................................................. page 7

INDUSTRIAL MONITORING INSTRUMENTATION DIVISION

PAGE 3

SENSORS AND INSTRUME

NTATION FOR MACHINE

CONDITION MONITORING

description

The Model 691B40 is a twelve channel switch box module which provides terminal strip input with the

convenience of BNC outputs. They are used in conjunction with commercially available data collectors and

analyzers. They provide inputs and switched outputs for vibration sensors with built-in temperature sensors. This

field installable module may be added to the model 691B43, 691B44, or 691B45 to provide expandability for up to

48 channels. A few specifications are listed below for easy reference:

Number of Channels................................................................... 12

Input Connectors.....................................4-Socket Terminal Strip

Output Connector - Vibration.........................................BNC Jack

Output Connector - Temperature ..................................BNC Jack

Size (H x W x D).................................................... 7.5 x 5.5 x 3.3 in

Weight.................................................................................... 1.7 lb.

installation

The 691B40 module may be added to the 691B43, 691B44, or 691B45 by fastening the captive panel screws

found in each corner of the 691B40 module to the plate found in the bottom of 691B43, 691B44, or 691B45

enclosure.

calibration

The Model 691B40 does not need any calibration since they are only switch box modules. If there are any

questions concerning the products, please contact the factory.

INDUSTRIAL MONITORING INSTRUMENTATION DIVISION

PAGE 4

SENSORS AND INSTRUME

NTATION FOR MACHINE

CONDITION MONITORING

terminal strip wiring

Positive Input

Connect the sensor’s positive input

Negative Input

Connect the sensor’s negative input

Shield

Connect the sensor’s shield; if applicable

TEMP

TEMP –Temperature Sensor Input

If thevibration sensors have a built-in temperature

sensor, connect the wire tothis terminal strip input.

INDUSTRIAL MONITORING INSTRUMENTATION DIVISION

PAGE 5

SENSORS AND INSTRUME

NTATION FOR MACHINE

CONDITION MONITORING

warning 1 –ESD sensitivity

The power supply/signal conditioner should not be opened by anyone other than qualified service

personnel. This product is intended for use by qualified personnel who recognize shock hazards and are familiar

with the safety precautions required to avoid injury.

warning 2 –ESD sensitivity

This equipment is designed with user safety in mind; however, the protection provided by the equipment may be

impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc.

caution 1 –ESD sensitivity

Cables can kill your equipment. High voltage electrostatic discharge (ESD) can damage electrical devices.

Similar to a capacitor, a cable can hold a charge caused by triboelectric transfer, such as that which occurs in the

following:

 Laying on and moving across a rug,

 Any movement through air,

 The action of rolling out a cable, and/or

 Contact with a non-grounded person.

The PCB solution for product safety:

 Connect the cables only with the AC power off.

 Temporarily “short”the end of the cable before attaching it to any signal input or output.

caution 2 –ESD sensitivity

ESD considerations should be made prior to performing any internal adjustments on the equipment. Any

piece of electronic equipment is vulnerable to ESD when opened for adjustments. Internal adjustments should

therefore be done ONLY at an ESD-safe work area. Many products have ESD protection, but the level of

protection may be exceeded by extremely high voltage.

Inhaltsverzeichnis

Andere PCB Piezotronics Schalten Handbücher

PCB Piezotronics

PCB Piezotronics IMI SENSORS 686C01 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI Sensors 685B Series Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 685B0001A10 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS EX686B77 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS Y685B0001A13 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 685B1001A21 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS Y686C01 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI Sensors 686B11 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 685A08 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 685B0001A13 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 685B0001A30 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS EX686B77B Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI Sensors 685B0000A33 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 691C42T Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS EX686B11 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI Sensors 686B1 0012 Series Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 691B44 Series Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS EX686B74 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS Y685B0001C14 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS EX686B01 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 686 Series Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS 686B02 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI Sensors SS691C41 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics IMI SENSORS EX685A09 Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
