Peak SOLICE Bedienungsanleitung
EXPERIENCE ULTIMATE FREEDOM
MANUAL
MODULAR WIRELESS
MACHINE
WITH PEAK’S FIRST-EVER MODULAR MACHINE
Switch effortlessly between a wireless or wired setup
TABLE OF CONTENTS
PEAK SOLICE DIAGRAM
TECHNICAL SPECIFICATIONS
KEY FEATURES
GET STARTED WITH SOLICE
PEAK WARRANTY INFORMATION
PAGE 1
2
3
3
4
5
PEAK SOLICE DIAGRAM
PAGE 2
TEXTURED GRIP
& NEEDLE DEPTH
ADJUSTMENT
RCA CONNECTION
8.0V
PEAK
BATTERY CAPACITY
CURRENT VOLTAGE WHEN CHARGING
IS DISPLAYED
VOLTAGE ADJUSTMENT BUTTONS +/-
POWER BUTTON
START/PAUSE
JUMPSTART ON/OFF
USB-C INPUT
BATTERY PACK
BATTERY BUILT
INTO HOUSING
Net Weight: 158g (~5.6oz)
Machine Length: 4.5”
Stroke Length: 3.5mm; 4mm cam available
separately
Machine Body: Constructed from durable aluminum
featuring the Peak logo on machine body
Battery: USB-C chargeable; offers 10+ hours of
tattooing power; Microchip battery controller
prevents short-circuit, overcharge, and drain
Motor: 6v 6800rpm motor
Maximum voltage: 10v
Jumpstart voltage: 9v in 0.3 seconds
Connection: Removable 1800 mAh battery and
magnetic RCA module
Package Includes: 2 O-rings, 2 Allen keys, 1 USB-C
charging cable, and 1 RCA cord
Ultra-lightweight pen-style modular machine
Can be used wirelessly or with a standard RCA connection
Let's you plug into power and continue tattooing even if your battery is close to dying
Offers a close grip and interchangeable design
Can be used for all tattooing styles
Comes in Black, Pink, or Red
TECHNICAL SPECIFICATIONS & KEY FEATURES
TECHNICAL SPECIFICATIONS
KEY FEATURES
PAGE 3
GET STARTED WITH SOLICE
FOR WIRELESS TATTOOING
FOR TATTOOING WITH AN RCA CONNECTION
PAGE 4
To turn on the Solice without the jumpstart feature, long-press the power button on the attached
PowerPack battery. Your machine will start with previously adjusted voltage.
1
2
3
4When you’re ready to recharge, connect your PowerPack to a USB-C charging cable. You will also see your
battery capacity.
To start or pause your machine, press the power button whenever you want.
A pedal icon will appear on your display when your machine is working.
Tattoo for 10+ hours on a single charge; the PowerPack battery will automatically shut off after
5 minutes of inactivity.
To turn on the Solice with the jumpstart feature, quickly double press the power button .
A lightning bolt icon will appear on your display.
Remove the PowerPack battery.
1
2
3Plug your Solice Pen into your favorite power supply with the included RCA cable.
Attach the magnetic RCA module (included with your Solice machine).
If you experience any technical issues or your Solice Modular Machine requires repairs, please contact our
customer service team at 410-712-0145. After our customer service team provides you with a return authorization,
you can download and fill out our Peak Repair Order Form:
Mail your completed repair order form, machine, and invoice as proof of purchase to 7410 Coca Cola Dr STE 108,
Hanover, MD 21076. You can also direct any questions or concerns regarding issues with your Solice Modular
If you purchased your Solice Modular Machine less than a year ago, we will replace it with a brand new model. If
your machine is older than a year, it is unfortunately no longer protected under our one-year warranty.
WARRANTY INFORMATION
WARRANTY INFORMATION
PAGE 5
