PEUGEOT Expert Tepee Bedienungsanleitung
HANDBOOK
WELCOME
The new Expert Tepee has been designed to satisfy all your
requirements in terms of practicality, comfort, safety and
aesthetics. In order to get the most out of your vehicle, we
suggest that you take a tour, from the cab to the seating area,
with the "Handbook" in front of you.
The handbook presents the operation of the equipment
available on board in detail.
Your vehicle is fitted with only some of the equipment described
in this document, depending on its trim level, version and the
specification for the country in which it was sold.
Please note the following point: the fitting of electrical equipment
or accessories which are not recommended by PEUGEOT
may result in a failure of your vehicle's electronic system.
Please note this specific warning. It is advisable to contact a
PEUGEOT dealer to be shown the recommended equipment and
accessories.
1
PEUGEOT thanks you for your confidence and wishes you
very happy motoring.
For any work on your vehicle, use a qualified workshop that has
the technical information, competence and equipment required,
which a PEUGEOT dealer is able to provide.
4
PRESENTATION
Within the chapters, symbols draw your attention to specific
information:
This handbook has been designed to familiarise you with your
new vehicle from the moment you get behind the wheel and to
describe the operating features.
Reading the handbook is made easy with the content consisting
of 10 identified chapters, which can be located by means of a
colour code specific to each one. Its sections cover, by subject, all
of the functions of the vehicle in its most complete specification.
Chapter 8 gives all of the technical data relating to your vehicle.
At the end of the document, diagrams of the outside and inside of
the vehicle will assist you in locating equipment or functions and
page numbers refer you to the relevant section of the handbook.
directs you to the chapter and section which contains detailed
information concerning a function,
indicates important information relating to use of the equipment,
alerts you to the safety of individuals and equipment on board.
5
2a
2b
8
2
3
4
7
Exterior
6
6
7
6
6
Exterior
8
Opening the bonnet
123
Diesel engines Petrol engine
124
153
Towing eye
122
Partially open the bonnet, lift the safety
catch and raise the bonnet.
Secure the stay in one of the two notches,
according to the height required, to hold the
bonnet open.
Lift the cover at the foot of the left-hand
seat and pull the release lever upwards.
At the front, unclip the cover by pressing it
at the bottom.
At the rear, unclip the cover using a coin or
the flat part of the towing eye.
Take care when working under the bonnet.
Refer to "Levels" in section 6 for advice on use of the fluids.
9
Interior
FAMILIARISATION
1
INSTRUMENTS AND CONTROLS
1. Lighting and direction indicator
control stalk.
2. Instrument panel with screen.
3. Wipers, screenwash, trip computer
control stalk.
4. Gear lever.
5. Ignition.
6. Audio system controls.
7. Driver's airbag, horn.
8. Steering wheel height and reach
adjustment.
9. Headlamp beam adjustment.
10. Cruise control, speed limiter
switches.
11. 12 volt accessory socket
(120 W max) of the cigarette
lighter type.
12. Ashtray.
13. Glove box, auxiliary socket,
passenger's airbag deactivation
switch.
14. "Grip control".
Interior
10
CENTRE CONSOLE AND OVERHEAD STORAGE UNIT
1. Location of controls:
- electric child lock,
- central locking/unlocking.
2. Heating and/or air conditioning
controls.
3. Location of the ticket/card storage or
controls:
- deactivation of the DSC,
- deactivation of the interior
protection alarm, alarm LED,
- deactivation of the parking
sensors.
4. Storage compartment.
5. Audio equipment or storage
compartment.
6. Central adjustable vents.
7. Hazard warning lamps switch.
8. Screen or storage compartment.
9. Courtesy lamp.
10. Passenger's airbag deactivated
warning lamp.
11. Location of the ticket/card storage,
rear ventilation deactivation switch,
heated seat controls.
ADJUSTING THE TIME
- a centre console with screen: refer to
"Adjusting the date and time" in section 9,
- a centre console without screen: refer to
"Instruments and controls" in section 2.
Depending on the configuration of your
vehicle, you have either:
3
11
Interior
FAMILIARISATION
1
Driver's seat
SITTING COMFORTABLY
1. Forwards-backwards adjustment.
2. Backrest angle.
3. Cushion height.
4. Lumbar.
5. Head restraint height. 69
2
4
3
3
Interior
12
Steering wheel Electric windowsMirrors
44
Seat belts
100
93
91
Adjust the steering wheel for height and
reach.
Manual adjustments.
Electric adjustments, electric folding /
unfolding.
Height adjustment.
Fastening.
