Philips BT5275 Bedienungsanleitung

Always here to help you

User manual

www.philips.com/welcome

BT5275

BT5270

BT5260

BT5275, BT5270, BT5260

ENGLISH 6

 14

 23

EESTI 31

 39

 47

 56

 65

 73

 81

 90

 98

 107

 116

 124

 133

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet

from the support that Philips offers, register your product at

www.philips.com/welcome.

General description (Fig. 1)

1 Turnable trimming head

2 Length setting

3 Zoom wheel

4 On/off button

5 Battery light

6 Socket for small plug

7 Guiding groove for trimming comb

8 Trimming comb

9 Adapter

10 Small plug

11 Cleaning brush

Important

Read this user manual carefully before you use the appliance and save it for

future reference.

Danger

- Keep the adapter dry.

Warning

- Check if the voltage indicated on the adapter corresponds to the local

mains voltage before you connect the appliance.

- The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

- This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

- Keep the appliance and its cord out of the reach of children.

- Do not use the appliance in the bath or in the shower.

Caution

- Always check the appliance before you use it. Do not use the appliance

if any of its parts is damaged or broken, as this may cause injury.

- Only use this appliance for its intended purpose as shown in the user

manual.

- Use, charge and store the appliance at a temperature between 5°C

and 35°C.

- Only use the adapter supplied to charge the appliance.

- Make sure the appliance is switched off and disconnected from the

mains before you clean it under the tap.

- If the appliance is subjected to a major change in temperature, pressure

or humidity, let the appliance acclimatise for 30 minutes before you use it.

- If the adapter is damaged, always have it replaced with one of the

original type in order to avoid a hazard.

ENGLISH

- Never use compressed air, scouring pads, abrasive cleaning agents or

aggressive liquids such as petrol or acetone to clean the appliance.

- Noise level: Lc= 65dB(A)

Compliance with standards

- The appliance complies with the internationally approved IEC safety

regulations and can be safely cleaned under the tap.

- This Philips appliance complies with all applicable standards and

regulations regarding exposure to electromagnetic elds.

Preparing for use

Charging

Charge the appliance fully before you use it for the rst time and after a

long period of disuse.

Charging takes about 60 minutes if the appliance is completely empty.

1 Make sure the appliance is switched off.

2 Insert the small plug into the appliance and put the adapter in the

wall socket.

,The battery light ashes orange and white alternately.

,After about 3 minutes, the battery light ashes white only. At this

point, the battery contains enough energy for one cordless trimming

session.

,The battery light continues to ash white and when the appliance is

fully charged, it lights up solid white.

,If the fully charged appliance is still connected to the mains after

1 hour, the battery light goes out after 30 minutes.

ENGLISH 7

Battery low and battery empty signals

,When the battery is almost empty, the battery light starts ashing

orange.When you switch off the appliance, the battery light

continues to ash orange for a few seconds.

,The battery light ashes orange at a higher frequency if the battery is

empty and if you press the on/off button.

Corded trimming

You can also operate the appliance from the mains.

1 Insert the small plug into the appliance.

2 Put the adapter in a wall socket.

3 Press the on/off button to switch on the appliance.

Using the appliance

You can use the appliance to trim facial hair (beard, moustache and

sideburns).This appliance is not intended for trimming lower body parts or

scalp hair.

Trimming with comb

The appliance comes with a comb that keeps the trimming head at a

certain distance from your skin.This distance determines the remaining hair

length and can be adjusted by turning the zoom wheel.

1 Slide the comb into the guiding grooves on both sides of the

appliance (‘click’).

ENGLISH8

Note: The comb does not t on the trimming head when the 15mm (0.6in)

side is pointing towards the front of the appliance. If this is the case, turn the

trimming head before you slide the comb onto the trimming head.

2 Turn the zoom wheel to select a length setting.

- The length setting selected is the one right below the indicator on the

front of the appliance.

- You can select a length from 0.4mm to 10mm (see table in section

‘Length settings’ below).

3 Press the on/off button to switch on the appliance.

4 To trim your beard, move the comb through the hair slowly.

5 When you are nished, press the on/off button to switch off the

appliance.

Tips

- Always make sure that the tips of the comb point in the direction in

which you move the appliance.

- Make sure that the at part of the comb is always in full contact with

the skin to obtain an even hair length result.

- Since hair grows in different directions, you need to move the appliance

in different directions (upward, downward or across).

- Trimming is easier when skin and hair are dry.

ENGLISH 9

Length settings

0.4 0.6 0.8 1 1.5

2 2.5 3 3.5 4

4.5 5 6 7 8

9 10

Trimming without comb

If you trim without the comb, your hair is cut off close to the skin.The

trimming head has a 32mm(1.25in) side and a 15mm (0.6in) side.

- The 32mm (1.25in) side is for regular trimming and contouring.

- The 15mm (0.6in) side of the trimming head allows more precise

styling and contouring than the 32mm(1.25in) side.

1 If the comb is still on the trimming head, pull it off.

Never pull at the exible top of the comb. Always pull at the sides.

2 Turn the trimming head until the side you want to use points to the

front of the appliance.

ENGLISH10
