Philips HQ6445/33 Bedienungsanleitung
ENGLISH 4
FRANÇAIS 12
ESPAÑOL 20
PORTUGUÊS 28
42
50
HQ6445, HQ6415, HQ6405
á«Hô©dGá«Hô©dG
Warning
Please read these instructions before using the
appliance.
◗Only use the cord supplied.
C◗Make sure the appliance and the cord do not
get wet.
Connecting
Store and use the appliance at a temperature
between 5cC and 35cC.
The appliance is suitable for mains voltages
ranging from 100 to 240V.
C1Put the appliance plug in the shaver.
2Put the cord in the wall socket.
Shaving
1Switch the shaver on by sliding the on/off
button upwards (1).
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips system.
3Switch the shaver off (0).
ENGLISH4
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
Replace the shaving heads (type HQ55) every
2 years for optimal shaving results.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning
Regular cleaning guarantees better shaving
performance.
C◗For easy and optimal cleaning, the Philips
Action Clean (shaving head cleaner, type
HQ100) is available.Ask your Philips dealer
for information.
You can also clean the shaver in the following way:
Every week: shaving unit
1Switch the shaver off (0), remove the cord
from the wall socket and pull the appliance
plug out of the shaver.
ENGLISH 5
C2Clean the top of the appliance first, using
the brush supplied.
C3Press the release button and remove the
shaving unit.
C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
Every two months: shaving heads
Replace the shaving heads (type HQ55) every
2 years for optimal shaving results.
1Switch the shaver off (0), remove the cord
from the wall socket and pull the appliance
plug out of the shaver.
ENGLISH6
2
1
C2Press the release button and remove the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove and clean the shaving heads
(cutters and guards) one by one.
Do not mix up the cutters and the guards.
This is essential since each cutter has been
ground with its corresponding guard for optimal
performance. If you accidentally mix the sets up, it
could take several weeks before optimal shaving
performance is restored.
C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
You can also clean the shaving unit with a
degreasing liquid (e.g. alcohol). If you do, lubricate
the central point of the guards with a drop of
sewing machine oil after cleaning.This prevents
wear of the shaving heads.
ENGLISH 7
2
1
1
2
C7Reassemble the shaving unit: turn the
wheel clockwise.
8Put the shaving unit back onto the shaver.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off (0), remove the cord
from the wall socket and pull the appliance
plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Replacing the shaving heads
Replace the shaving heads every two years for
optimal shaving results.
1Switch the shaver off (1), remove the cord
from the wall socket and pull the appliance
plug out of the shaver.
C2Press the release button and remove the
shaving unit.
ENGLISH8
1
2
2
1
C3Turn the wheel anti-clockwise and remove
the retaining frame.
C4Remove the shaving heads and place the
new ones in the shaving unit.
C5Reassemble the shaving unit: turn the
wheel clockwise.
Replace damaged or worn shaving heads with
Philips HQ55 shaving heads only.
Storing
C◗Put the protection cap on the shaver to
prevent damage.
◗The appliance can be stored in the pouch
supplied.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been cleaned well enough or
has not been cleaned for a longer period.
ENGLISH 9
1
2
1
2
◗Clean the shaver thoroughly before you
continue shaving (see 'Cleaning').
BCause 2: long hairs are obstructing the shaving
heads.
C◗Remove the retaining frame.
C◗Clean the cutters and guards.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
◗Remove the hairs with the brush supplied.
◗Put the retaining plate back onto the shaving
unit.
BCause 3: shaving heads are damaged or worn. See
'Replacing the shaving heads'.
Replacing the shaving heads every 2 years
prevents wear of the shaving heads.
2The shaver does not work when the
ON/OFF button is pushed upwards (1).
BCause: the shaver is not connected to the mains.
ENGLISH10
1
2
Accessories
The following accessories are available for your
shaver:
- HQ55 Philips Shaving Heads.
- HQ100 Philips Action Clean (shaving head
cleaner).
- HQ101 Philips Action Refill (shaving head
cleaning liquid).
- HQ110 Philips Head Cleaner (shaving head
cleaning spray).
Information & service
If you need information or if you have a problem,
please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
◗Keep these instructions for use for future
reference.
ENGLISH 11
Avertissement
Avant d'utiliser l'appareil, veuillez lire ces
instructions.
◗Utilisez exclusivement le cordon
d'alimentation fourni avec l'appareil.
C◗Veillez à ce que l'appareil et le cordon
d'alimentation ne soient pas exposés à
l'humidité.
Raccordement
Chargez et utilisez l'appareil à une température
comprise entre 5cC et 35cC.
Ce rasoir fonctionne sur une tension secteur de
100 à 240~volts.
C1Enfoncez la fiche dans le rasoir.
2Branchez l'appareil.
Rasage
1Mettez l'appareil en marche en faisant
glisser le bouton marche/arrêt vers le haut
(1).
C2Déplacez rapidement les têtes de rasage
sur la peau en effectuant des mouvements
rectilignes et circulaires.
Les meilleurs résultats de rasage sont obtenus sur
peau sèche.
Votre peau peut avoir besoin de 2-3 semaines
pour s'habituer au système Philips.
FRANÇAIS12
