Philips HQT502/00 Bedienungsanleitung

ENGLISH 4

HQT502

Important

◗Make sure that the appliance does not get

wet.

◗This appliance is only designed for trimming

the human beard.

◗Keep the appliance out of the reach of

children.

ENGLISH4

Preparing for use

C1Open the battery holder.Place two

batteries (make sure the + and - poles are

pointing in the right direction).Close the

battery holder again.

Use R6/1.5Volt batteries.We recommend Philips

Powerlife batteries because of their long life.

When the batteries are empty,do not throw

them away with the normal household waste,but

hand them in at an official collection point.

ENGLISH 5

Trimming

Always comb the beard and/or moustache with a

fine comb before you start trimming.

Do not move the trimmer too fast.Make smooth

and gentle movements.

Trimming with comb attachment

C1Slide the adjustment comb to the desired

trimming length setting (see table).

The setting will appear in the window in the

centre of the comb attachment.

ENGLISH6

BIf you are trimming for the first time,start by using

the maximum trimming length setting:setting 4.

2Switch the appliance on.

C3To trim in the most effective way,move

the trimmer against the direction of hair

growth.Make sure the flat surface of the

comb always stays in contact with the skin.

C4If a lot of hair has accumulated in the

comb,remove the comb attachment by

adjusting it to setting 4 and then pulling it

off the appliance.

ENGLISH 7

resulting beard length

1.5 mm

3.0 mm

5.0 mm

7.0 mm

setting

ENGLISH8

C5Blow and/or shake the hair out of the

comb.Readjust the comb to the seleted

setting.

Trimming length setting table

◗Using setting 1 will result in a unique 'stubble

look'.

ENGLISH 9

Trimming without comb attachment

Full beards and single hairs

C1Remove the comb attachment by adjusting

it to setting 4 and then pulling it off the

appliance.

Never pull at the flexible top of the comb

attachment.Always pull at the bottom part.

2Switch the appliance on.

C3Make well-controlled movements.Touch

the hair lightly with the trimmer.

Cleaning

Do not use abrasives,scourers or liquids such as

alcohol,petrol or acetone to clean the appliance.

1Make sure the appliance is switched off.

2Remove the comb attachment.

C3Open the cutting unit by pushing it

backwards (1).

4Clean the cutting unit and the inside of the

appliance with the brush supplied (2).

ENGLISH10

ENGLISH 11

C5Close the cutting unit by pushing it back

onto the appliance until you hear a click.

Replacing the cutting unit

A worn or damaged cutting unit should only be

replaced with an original Philishave cutting unit,

available from authorised Philips service centres.

1Open the cutting unit.

CLICK

ENGLISH12

2Remove the old cutting unit by pulling it

upwards.

C3Place the two lugs of the new cutting unit

into the guiding slots.

4Push the cutting unit back onto the

appliance until you hear a click.
