Philips HS890/01 Bedienungsanleitung

890

English page 3

Français page 14

Deutsch Seite 25

Nederlands pagina 36

Italiano pagina 47

Español página 58

Português página 69

1Do not allow the shaver to become wet.

2Do not leave the appliance in a position

where it can become damaged by direct

sunlight or other heat source.

- Before first use or

- if the shaver has not been used for a

month or longer

it should be charged for a period of at

least 8 hours (irrespective of the reading

on the display).

If the batteries are completely empty, it may

take some time (3-5 minutes) before

information appears in the display.

• Please bear in mind that your skin may

need two to four weeks to become fully

accustomed to the Philishave shaving

system.

885

■■■ Important English

■■■ Switching on/off

3 The slider switch has a locking

knob which prevents the shaver

from being switched on

accidentally.

Keeping the small knob on the

switch pressed-in slide the switch

upwards/downwards.

■■■ Charging

•Ensure that the shaver is switched off.

•It is advisable to charge the shaver at tempera-

tures between 5°and 35°C (41°and 95°F). This

guarantees maximum life from the rechargeable

batteries.

•If you keep the shaver in the case when

charging ensure that the lid is left open to

prevent overheating.

•Before first use (or if the shaver has not been

used for a long time) it should be charged for a

period of at least 8 hours.

To protect the environment, this

rechargeable Philishave appliance is

equipped with nickel-hydride batteries.

These contain less than 0.01% cadmium.

Yet we advise you to ensure that the batteries

are separated from the normal household

refuse and that they are disposed of at an

officially assigned place when discarding your

appliance in due course. Please refer to section

“Protecting the environment”.

•Recharging: 60 minutes.

The shaver can also be charged from a 12 - 24 Volts

(DC) supply using cord connector type HP 1957.

(Available from Philips retailers or Authorised Service

Dealers.) Charging from a 12 - 24 Volts (DC) supply

requires approx. 24 hours.

• Regular cleaning of the shaver means that less

battery energy is consumed, so that more shaving

time becomes available.

• The shaver will not be damaged by leaving it

connected to the mains supply after it is fully

charged.

However, it is not advisable to charge the shaver

permanently as this would shorten the life of the

rechargeable batteries.

4Insert the small plug into the

shaver. Ensure that the plug is

pushed fully home. (Note the

indication mark.)

Mains voltages: 100 - 240

Volts. (The shaver adjusts

automatically.)

5The green pilot light comes on.

If the batteries are almost empty, the

red pilot light will come on as well.

When this light goes out, there is

enough energy in the rechargeable

batteries for one cordless shave

(3 minutes).

6After 60 minutes the green pilot light

starts to flash. This means that the

shaver is fully charged.

890

■■■ Cordless shaving

7When the red pilot light comes on,

the reserve energy has been reached.

(You will be able to complete the

shave.)

As the shaver is switched off the red

pilot light will start flashing and

you will hear a sound signal for

4 seconds.

This indicates that it is time to recharge the

shaver.

■■■ Have you missed out charging?

When the batteries are completely empty and the

shaver stops, you can give the shaver a quick

charge (sufficient for one cordless shave):

- Charge the shaver until the red pilot light goes out.

■■■ Shaving directly from the mains supply (wall

socket)

- If you wish you can connect the shaver to a wall

socket using the mains cord and shave directly from

the mains supply.

890

■■■ Shaving

8Switch on.

9Move the shaving unit quickly over the skin and

especially against the direction of the hair growth,

stretching the skin with your free hand to bring the

hairs into an upright position.

• Best results are obtained if the skin is dry.

Preferably shave before or some time after

washing.

• If required apply a pre-shave lotion. This can be

particularly helpful if the climate is warm and humid.

■■■ Trimmer

The trimmer can be engaged whilst the motor is

running.

10 To engage the trimmer push the slide

upwards.

To disengage move the slide downwards.

Brush the trimmer clean after each use.

11 The trimmer has been especially designed for

grooming sideburns, moustache and beard.

The trimmer is not required for long hairs in the

neck area; these hairs can easily be shaved off

with the shaving unit.

12 Maintenance (every six months)

Apply two drops of light machine oil to the teeth of

the trimmer.

10 12

OIL

■■■ Cleaning

• Always ensure that the mains cord is disconnected

and the shaver is switched off before carrying out

maintenance or cleaning.

• Handle the shaving heads carefully to avoid

causing damage.

•Advice: Clean the shaver regularly.

13-16 Every week:

shaving head slots and hair chamber

- (Fig. 13) Use the short bristled brush to clean the

shaving head slots.

- (Fig. 14) To remove the shaving unit depress the

retaining button (1) and lift the shaving unit from

the shaver (2).

- (Fig. 15/16) Remove hairs from the chamber and

shaving unit using the long bristled brush.

13-28 Every 3 months:

shaving head slots, the hair chamber and

shaving unit (guards and cutters)

(If your skin is of an oily type or if you have been

using a pre-shave lotion: 1x per month.)

- First clean the shaver head slots and hair chamber

as previously described. (See figs. 13-16.) Then

proceed with figs. 17-28 for cleaning the shaving

unit.

- (Fig. 17-18) Release and remove the retaining plate.

The shaving heads remain in the shaving unit.

- (Fig. 19) Remove only one shaving head (guard

and cutter) at a time for cleaning to ensure that the

cutters and guards do not become mixed.

Each cutter has been ground together with the

guard. If the guards and cutters are mixed, it may

take some weeks before optimal shaving

performance is restored.

- (Fig. 21) Clean the cutter by brushing only in the

direction of the arrow using the short bristled brush.

18 19

20 21 22
