Philips 17PF9220 Bedienungsanleitung

The art of living

This stylish Philips LCD TV features Crystal Clear III technology and delivers astounding

theatre-like sound to give you a truly great audio-visual experience.

Vivid, natural and razor sharp images

• High definition LCD WXGA display, resolution 1280 x 768p

• HD ready for the highest quality display of HDTV signals

• Crystal Clear III for natural images with enhanced quality

• Active Control optimises picture quality whatever the source

Superb sound reproduction

• Virtual Dolby Surround for a cinema-like audio experience

True beauty lies in the details

• Ultra-slim design

My personal entertainment centre

• Built-in FM radio to enjoy your favourite radio stations.

• PC input lets you also use your TV as a PC monitor

Leading interface for digital quality audio/video

• DVI-I provides the best picture and flexible connectivity

Philips

flat TV with Crystal Clear

III

17"

LCD HD Ready

17PF9220

17PF9220/01

Flat TV with Crystal Clear III

17" LCD HD Ready

Specifications

Picture/Display

•Aspect ratio: Widescreen

•Brightness: 450 cd/m²

•Contrast ratio (typical): 600:1

•Diagonal screen size: 17 inch / 43 cm

•Display screen type: LCD WXGA Active Matrix

TFT

•Picture enhancement: Crystal Clear III,

Progressive Scan, Active Control, Sharpness

Adjustment, 2D Combfilter, Color Temperature

Adjustment

•Screen enhancement: Anti-Reflection coated

screen

•Viewing Angle (H / V): 176 / 176 degree

•Panel resolution: 1280 x 768p

•Response time (typical): 25 ms

Supported Display Resolution

Sound

•Sound Enhancement: Dynamic Bass Enhancement

•Sound System: Nicam Stereo, Virtual Dolby

Surround, Mono

•Output power (RMS): 2 x 2W

•Equaliser: 5-bands

Convenience

•Ease of Installation: Automatic Channel

Install(ACI), Automatic Tuning System (ATS),

Autostore, Fine Tuning, PLL Digital Tuning, Plug &

Play, Program Name, Auto Program Naming,

Sorting

•Ease of Use: Auto Volume Leveller (AVL), FM

Radio, Menu Control, On Screen Display,

Program List, Smart Picture Control, Smart Sound

Control

•Remote control type: RCFE05SMS00

•Teletext: 10 page Smart Text

•Picture in Picture: Twin page text

•Screen Format Adjustments: 4:3, Widescreen,

Subtitle Zoom, Super Zoom, Movie expand 14:9,

Movie expand 16:9, Full screen

•Clock: Sleep Timer

•VESA Mount: 75 x 75 mm

•Remote Control: TV

Tuner/Reception/Transmission

•Tuner bands: FM, Hyperband, S-Channel, UHF,

VHF

•TV system: PAL, PAL B/G, PAL D/K, PAL I,

SECAM, SECAM B/G, SECAM D/K, SECAM L/L'

•Video Playback: NTSC, PAL, SECAM

•Aerial Input: 75 ohm coaxial (IEC75)

•Tuner Display: PLL

•Number of Preset Channels: 100

Connectivity

•Number of Scarts: 1

•Ext 1 Scart: Audio L/R, CVBS in/out, RGB

•Other connections: Antenna IEC75, DVI-I, FM

Antenna, PC Audio in

•Front / Side connections: Audio in, CVBS in,

Headphone out, S-video in

Power

•Power consumption: 53 W

•Standby power consumption: < 3 W

•Ambient temperature: +5°C/+45°C

•Power supply: AC 90-240

Dimensions

•Product weight: 6 kg

Accessories

•Included Accessories: Mini jack to cinch (Female),

Power cord, Registration card, Remote Control,

Table top stand, User Manual, Quick start guide

•FM antenna: FM antenna

•Cables: DVI-I to YPbPr cable

•

•Computer formats

Resolution Refresh rate

640 x 480 60, 67, 72, 75Hz

720 x 400 70Hz

800 x 600 56, 60, 72, 75Hz

832 x 624 75Hz

1024 x 768 60, 70, 75Hz

1280 x 768 60Hz

•Video Formats

Resolution Refresh rate

640 x 480i 1Fh

640 x 480p 2Fh

720 x 576i 1Fh

720 x 576p 2Fh

1920 x 1080i 2Fh

1280 x 720p 3Fh

17PF9220/01

Flat TV with Crystal Clear III

17" LCD HD Ready

Product highlights

Issue date 2007-11-09

Version: 3.0

12 NC: 8670 000 22252

EAN: 87 10895 87545 5

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

HD Ready

Enjoy the exceptional picture quality of a true High

Definition TV signal and be fully prepared for HD sources

like HDTV broadcast, Blu-ray DVD or HD-DVD. HD

ready is a protected label that offers picture quality

beyond that of progressive scan. It conforms to strict

standards laid out by EICTA to offer a HD screen that

displays the benefits of resolution and picture quality of a

High Definition TV signal. It has a universal connection for

both analogue YPbPr and uncompressed Digital

connection of DVI or HDMI, supporting HDCP. It can

display 720p and 1080i signals at 50 and 60Hz.

Crystal Clear III

Crystal Clear III combines a whole range of

enhancements to provide a better picture. They include a

2D Comb filter, Dynamic contrast, Blue stretch and

Green enhancement so that you always get the most

natural looking colors.

Active Control

Active Control ensure that noise and sharpness

improvements are continuously made at a rate of 60

times per second. By continually adjusting picture setting

over 3,000 times per minute, Active Control Plus ensures

that the viewing experience is optimised.

Virtual Dolby Surround

Virtual Dolby Surround is a processing technology for

enhancing surround sound effects. It will create the

sensation of Dolby Pro Logic without the necessity of

additional rear speakers. You become totally immersed in

your television experience.

FM Radio

An FM radio capable of storing 40 preset stations in built

in. On-screen station naming makes navigation simple,

and a handy Clock Screensaver is also included for use

while listening.

PC input

With PC input you can connect your TV to a computer

and use the TV as a PC monitor.

DVI-I Input

A DVI-I input connects the non-compressed high-

bandwidth digital RGB signal from source to screen. By

eliminating the conversion of the digital signals to

analogue, it delivers an unblemished and noise free

image, that is clear and flicker free. The DVI input

supports HDCP copy protection that allows viewing of

copy protected programs from Digital Set top boxes,

DVD players and HD recorders. DVI-I is future proof as

it can be connected to all HDMI devices (a converter

cable is required). The DVI-I input also supports analogue

PC-VGA signals.
