Philips ACT210 Bedienungsanleitung

digital audio player

psa[128max

Portable Sport Audio by Philips

product manual

controls and connections, accessories ––––––––––––––––––––––––– 4

minimum computer system requirements –––––––––––––––––––––––– 6

general information ––––––––––––––––––––––––––––––––––––––––––– 7

power supply ––––––––––––––––––––––––––––––––––––––––––––––– 8-9

power on/off, playback and pause 2;

power saving mode –––––––––––––––––––––––––––––––––––––––––– 10

adjusting volume -/ + and eq settings ––––––––––––––––––––––––– 11

selecting a different track

fast searching 5 , 6––––––––––––––––––––––––––––––––––––––––– 12

button lock ––––––––––––––––––––––––––––––––––––––––––––––– 12

remote control, clip magnets, armband –––––––––––––––––––– 13-15

psa audio management

installing musicmatch jukebox ––––––––––––––––––––––– 15-17

installing the psa drivers –––––––––––––––––––––––––––––––– 18

connecting the psa to your computer –––––––––––––––––––– 19

creating mp3 & windows media audio

files from cds ––––––––––––––––––––––––––––––––––––––––––– 20

playlist –––––––––––––––––––––––––––––––––––––––––––––––––– 21

download music to the psa from your computer –––––– 22-23

updating MUSICMATCH software,

upgrading your audio player ––––––––––––––––––––––––––––– 24

recovery –––––––––––––––––––––––––––––––––––––––––––––––– 25-26

helpful tips –––––––––––––––––––––––––––––––––––––––––––––– 27-28

technical data ––––––––––––––––––––––––––––––––––––––––––– 29-30

2 contents

contents 3

in the U.K and certain countries, the copying of material protected by copyright

may require the permission of the copyright holders.

this product complies with the radio interference requirements

of the European Union.

CAUTION

use this device according to the instructions that follow failure

to do so could be hazardous to your health.

users of pacemakers or other implanted devices should consult

their physician before using magnets or devices that may

generate electro-magnetic interference.

environmental information

we have reduced the packaging to its minimum and made it easy to separate into

mono materials: PET, PS, PE.

your set consists of material which can be recycled if disassembled by a specialized

company. please observe the local regulations to dispose of packaging, exhausted

batteries and old equipment.

12;

switches the set on /off;

starts / pauses playback

25 / 6

skips to the beginning of a previous /

next track

3- / +

adjusts the volume

4display

with backlight. lights up briefly

orange when you press any button on

the psa

5eq

enhance your listening experience.

select from 4 equalizer settings:

Hiphop, Funk, Rock, Techno or create

your own adjustable Custom setting.

3.5 mm line out to connect

7locks buttons to prevent them

from being activated

8battery compartment

uses 1 x AAA alkaline or Ni-MH

battery

9usb in

(found in the battery compartment)

connect the supplied usb cable from

here to the usb port of your computer

supplied accessories

make sure these items are in the

package. if any item is missing,

please contact your dealer.

one usb cable

one psa software & user guide cd-rom

one set of headphones

one remote control

one set of clip magnets

one armband

one AAA rechargeable Ni-MH

battery*

one Ni-MH battery charger*

* not supplied with Asia-Pacific

versions

4 controls and connections

the model & serial numbers are located inside the battery compartment.

controls 5

front view

rear view

Windows system requirements

you need to have a usb port. computers that were upgraded from Win 95 to Win 98

may not have usb compatibility! check out the other requirements:

– Pentium® MMX 166MHz processor or better

– usb port with Windows 98 / Me / 2000 / XP

– 96MB ram

– 50MB ram drive space

– cd rom drive

– video display card

– sound card

– Microsoft Internet Explorer 5.0 or better, Netscape 4.0 or better, and internet

access

Mac system requirements

– G3 or better

– MacOS 8.6-9.X

6 minium computer system requirements

psa[128 is a solid-state, portable, digital audio player:

– plays mp3 & windows media audio files e.g. digitized and compressed cd tracks,

tape tracks, audio books, newspapers, sound effects, etc., that are encoded into

mp3 & windows media audio format.

– software upgradeable and will support future playback formats and sofware

extensions that will be made available on www.nike-philips.com.

– will support for future digital rights management technology, including the Secure

Digital Music Initiative (SDMI).

take care when using headphones

hearing safety: listen at a moderate volume. using headphones at high volume can

impair your hearing.

traffic safety: do not use headphones while driving or cycling as you may cause an

accident.

general maintenance

to avoid damage or malfunction:

– do not expose to excessive heat caused by heating equipment or direct sunlight.

– do not drop the psa or allow objects to fall on the psa.

– do not allow the psa to be submersed in water. do not expose earphone socket or

battery compartment to water as water entering the set may cause major damage.

– do not use any cleaning agents containing alcohol, ammonia, benzene, or

abrasives as these may harm the set.

– active mobile phones in the vicinity may cause interference.

general information 7

battery

1press 4to open the battery cover latch and insert

one AAA battery preferably alkaline, or Ni-MH as

indicated.

2insert the lower edge of door as shown to close the

battery cover latch.

IMPORTANT!

– remove the battery if: battery drained or the psa

will not be used for more than two weeks.

– batteries contain chemical substances, so they

should be disposed of properly.

indication of empty battery

the number of blocks inside the battery icon

indicates the battery power remaining. when the

battery is low, the battery icon flashes. if no action

is taken to renew the battery, the display shows

BAT LOW! 5 seconds later the psa automatically

switches off.

8 power supply

battery charger*

1open the battery compartment. insert the batteries

as indicated.

2plug charger to wall outlet. the battery charger

indicator lights up red when charging. a green light

indicates charging has finished. maximum charging

time: approx. 4 hours.

note: always disconnect the battery charger from

the power outlet if you do not need to use it.

batteries cannot be charged onboard the

psa[128 max.

* not supplied with Asia-Pacific versions

power supply 9

power on and playback, 2;

press and hold 2; for 2 seconds to turn on.

playback starts automatically and display shows

track details.

*No file* will be shown if no content has been

stored in the psa.

power off, 2;

during playback, press and hold 2; for 2 seconds to turn off.

display message: OFF before turning off.

pause, 2;

during playback, press 2; to pause. press 2; again

to resume playback.

display: during pause mode, the elapsed

playtime flashes and track details freeze.

power-saving standby mode

the psa automatically switches off when playback is paused longer than 30 seconds

and no buttons are pressed.

10 power on / off, playback 2;

* No file *
