Philips AZB600 Bedienungsanleitung

User manual

Always there to help you

www.philips.com/support

AZB600

Question?

Contact

Philips

1EN

Contents

1 Important 2

Safety 2

Notice 3

2 Your CD Soundmachine 4

Introduction 4

What's in the box 4

Overview of the main unit 5

3 Get started 7

Connect power 7

Turn on 8

Turn off 8

4 Play 9

Play a CD 9

Play options 9

Play tape 10

Play from an external device 10

5 Listen to FM radio stations 11

Tune to FM radio stations 11

Program FM radio stations automatically 11

Program FM radio stations manually 11

Select a preset radio station 11

Adjust FM settings 12

6 Listen to DAB radio stations 13

Listen to DAB radio stations 13

For the rst time use 13

Program radio stations 13

Display DAB information 13

Use DAB menus 14

7 Use system menus 15

Reset the product 15

Check the current software version 15

8 Product information 16

Specications 16

Maintenance 17

9 Troubleshooting 18

2EN

1 Important

Safety

• Read these instructions.

• Follow all instructions.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliers) that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the unit.

• Only use attachments/accessories specied

by the manufacturer.

• Unplug this unit during lightning storms or

when unused for long periods of time.

• Recording is permissible insofar as

are not infringed upon.

• Refer all servicing to qualied service

personnel. Servicing is required when the

unit has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, the unit has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the unit is not

used for a long time.

• Batteries (battery pack or batteries

installed) shall not be exposed to excessive

heat such as sunshine, re or the like.

• CAUTION: Danger of explosion if battery

is incorrectly replaced. Replace only with

the same or equivalent type.

• The unit shall not be exposed to dripping

or splashing.

• Do not place any sources of danger on

the unit (e.g. liquid lled objects, lighted

candles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Never look into the laser beam inside this apparatus.

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

3EN

Notice

This product complies with the radio

interference requirements of the European

Community.

Any changes or modications made to this

device that are not expressly approved by

WOOX Innovations may void the user’s

authority to operate the equipment.

Disposal of your old product

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU. Inform yourself about the local

separate collection system for electrical and

electronic products. Follow local rules and never

dispose of the product with normal household

waste. Correct disposal of old products

helps prevent negative consequences for the

environment and human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

paper pulp (buffer) and polyethylene (bags,

protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

This apparatus includes these labels:

Class II equipment symbol

This symbol indicates that the apparatus has a

double insulation system.

The making of unauthorized copies of copy-

protected material, including computer

programs, les, broadcasts and sound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

Note

•The type plate is located on the bottom of the

apparatus.

4EN

2 Your CD

Soundmachine

Introduction

With this CD Sound machine, you can:

• Listen to FM radio;

• Listen to DAB radio;

• Enjoy audio from discs, tapes, and other

external audio devices;

• Program the play sequence of tracks.

The CD sound machine offers you Dynamic

Bass Boost (DBB) to enrich sound.

What's in the box

Check and identify the contents of the package:

• Main unit

• Power cord

• Short User Manual

• Safety sheet

•

5EN

Overview of the main unit

a DBB

• Turn dynamic bass boost on/off.

b /MENU

• Stop playing.

• Access FM/DAB menu.

FM DAB

BAND

TAPE/OFF

AUDIO-IN/CD RADIO

c /

• Select a preset radio station.

6EN

d MODE/DISPLAY

• Select a play mode.

• Display the RDS information.

• Display the DAB information.

e OPEN•CLOSE

• Open or close the disc compartment.

f Tape controls

•

Start tape play.

• /

Fast rewind or fast forward the tape.

Stop the tape play or open the tape

door.

•

Pause tape play or pause recording.

g /OK

• Start or pause play.

• Press to wake up the CD sound

machine from standby mode.

• Conrm a selection.

h PROG/PRESET

• Program the play sequence of tracks.

i /

• Skip to the previous or next track.

• Search within a track.

j Display panel

• Display current status.

k FM antenna

• Improve FM reception.

l FM/DAB

• Select FM/DAB band.

m Source selector

• Select a source.

n VOL +/-

• Adjust volume.

o AUDIO-IN

• Connect an external audio device.

p AC MAINS ~

7EN

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of your apparatus.The

model number and serial number are on the

bottom of your apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Connect power

The unit can be powered by either AC power

or batteries.

Option 1:AC power

Warning

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back or the underside of the unit.

•Risk of electric shock! When you disconnect the AC

power, always pull the plug from the socket. Never pull

the cord.

Connect the AC power cord to the wall socket.

Tip

•To save energy, turn the unit off after use.

Option 2: Battery power

Caution

•Batteries contain chemical substances, so they should

be disposed of properly.

Note

•Batteries are not supplied with the accessories.

1 Open the battery compartment.

2 Insert 6 batteries (type: 1.5V R14/UM2/C

CELL) with correct polarity (+/-) as

indicated.

3 Close the battery compartment.

AC~MAINS

8EN

Turn on

Switch the source selector on the product to

CD/RADIO/TAPE.

Switch to standby mode

• The product switches to standby mode

automatically when there is no audio

detected for over 15 minutes.

• Press to wake up the product from

standby mode.

Turn off

Switch the source selector on the main unit to

OFF.
