PREFACE

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subjected to

the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference

that may cause undesired operation.

FCC WARNING

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution:

To comply with the limits for an FCC Class B computing device, always use the

shielded signal cord supplied with this unit.

The Federal Communications Commission warns that changes or modifications

of the unit not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

CE mark for Class B ITE (Following European standard EN55022/1998; EN61000-

3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950/1992+A1+A2+A3+A4+A11)

Radio Frequency Interference Statement

Warning:

This is a Class B product. In a domestic environment, this product may cause

radio interference in which case the user may be required to take adequate

measures.

Canadian Doc Notice

For Class B Computing Devices

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus as set out in the Radio Interference Regulation

of the Canadian Department of Communications.

“Le présent appareil numérique n’èmet pas de bruits radioélectriques dépassant

les limites applicables aux appareils numériques de la class B prescrites dans le

Règlement sur le brouillage radioélectrique édicté par le ministère des

Communications du Canada”

iii

Important Safety Instructions

Please read the following instructions carefully. This manual should be retained

for future use.

1. To clean the LCD Monitor screen, first, make sure the Monitor is in the

power off mode. Unplug the Monitor from its power source before cleaning

it. Do not spray liquid cleaners directly onto the unit. Stand away from the

LCD Monitor and spray cleaning solution onto a rag. Without applying

excessive pressure, clean the screen with the slightly dampened rag.

2. Do not place your LCD Monitor near a window. Exposing the Monitor to

rain, water, moisture or sunlight can severely damage it.

3. Do not place anything on top of the Monitor-to-PC signal cord. Make sure

the cord is placed in an area where it will not be stepped on.

4. Do not apply pressure to the LCD screen. Excessive pressure may cause

permanent damage to the display.

5. Do not remove the cover or attempt to service this unit by yourself. You

may void the warranty. Servicing of any nature should be performed only

by an authorized technician.

6. Safe storage of the LCD Monitor is in a range of -20°C to +60°C (-4°F ~

140°F). Storing your LCD Monitor outside this range could result in

permanent damage.

7. If any of the following occurs, immediately unplug your Monitor and call an

authorized technician.

• The power or Monitor-to-PC signal cord is frayed or damaged.

• Liquid has been spilled onto the Monitor, or it has been exposed to rain.

• The Monitor has been dropped or the case has been damaged.

8. Only with use of supplied adaptor, in case of loss or replacement contact the

retailer or service center.

9. If you lost the power cord that we given, you must to purchase a same

configuration/type of power cord (with ground-connection)

 Japan：VCTF type, 3 wires or with ground-wire, T-mark approval is

required.

 U.S.：VW-1; 18AWG X 3C; SVT with national approval as UL and/or

CSA approval/number(s)

 Europe：VDE/ÖVE and/or KEMA approval; H05VV-F, 3G, 0.75mm2,

or equivalent.

Above power cord should bear with the type and manufacturer name on.

TABLE OF CONTENTS

PREFACE..................................................................................................................... I

TABLE OF CONTENTS............................................................................................ V

CHAPTER 1 ................................................................................................................. 1

Unpacking 1

Identifying Components 2

Hot-Key Buttons for Quick Adjustment of Monitor Settings 2

The LCD Monitor — Rear View 3

Adjusting the Viewing Angle 4

Connecting AC Power, Video, Audio and USB Cable (Optional) 7

Power Management System 7

CHAPTER 2 ................................................................................................................. 8

The LCD Monitor’s Display Controls 8

Adjusting the Monitor’s Display 9

OSD Main Menu (Please refer to Chapter 1 for details on functions) 9

APPENDIX A ............................................................................................................. 16

LCD Monitor Specifications 16

APPENDIX B ............................................................................................................. 18

APPENDIX C ............................................................................................................. 19

Troubleshooting Procedures 19

CHAPTER 1

The LCD Monitor

Unpacking

After you unpack your LCD Monitor; make sure the following items are

included in the box and in good condition:

• LCD Monitor

• Monitor-to-PC Analog signal cable (15-pin)

• Monitor-to-PC Digital signal cable (24-pin) (optional)

• Stereo Jack Audio Cable (optional)

• USB Cable (optional)

• Power cord

• Landing Strip

• User’s manual

• CD Manual

If you find that any of these items are missing or appear damaged, contact

your dealer immediately. Do not throw away the packing material or

shipping carton in case you need to ship or store the LCD Monitor in the

future.

Identifying Components

Hot-Key Buttons for Quick Adjustment of Monitor Settings

Figure 1-1: Hot-Key buttons

1.”Auto-adjust” short-cut button:

Press button 2 to apply the monitor setting

automatically. A small “AUTO ADJUST” OSD is

also displayed.

2.” Adjust-volume” short-cut button:

Press button 3 to allow you to adjust the audio

volume directly.

3.” Contrast-adjust” short-cut button:

Press button 4 to allow you to adjust the contrast

of the display directly.

** To close the small OSD windows, press the power button (button 5).

The LCD Monitor — Rear View

Figure 1-2: LCD Monitor’s Rear Ports

1. Audio Line-in (optional)

2. AC Power Jack

3. Upstream USB Port (optional)

4. Downstream USB Ports (optional)

5. Digital VGA Cable Connect (optional)

6. VGA Cable Connector

7. VESA interface: It can be mounted to VESA arm. (75mm pitch)
