Planet POE-161 Bedienungsanleitung

IEEE 802.3at Gigabit

High Power over Ethernet Adapter

POE-161 / POE-161S

User’s Manual

Trademarks

Contents subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp.

All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will

work properly in all environments and applications, and makes

no warranty and representation, either implied or expressed,

with respect to the quality, performance, merchantability, or

tness for a particular purpose.

PLANET has made every effort to ensure that this User’s Manual

is accurate; PLANET disclaims liability for any inaccuracies or

omissions that may have occurred.

Information in this User’s Manual is subject to change without

notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies

that may be contained in this User’s Manual. PLANET makes no

commitment to update or keep current the information in this

User’s Manual, and reserves the right to make improvements to

this User’s Manual and/or to the products described in this User’s

Manual, at any time without notice. If you nd information in

this manual that is incorrect, misleading, or incomplete, we

would appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause

harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct

the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Stand by mode

operation.

For energy saving, please remove the DC-plug or push the

hardware Power Switch to OFF position to disconnect the device

from the power circuit. Without removing the DC-plug or switch

off the device, the device will still consume power from the

power source. In the view of Saving the Energy and reduce the

unnecessary power consuming, it is strongly suggested to power

off or to remove the DC-plug for the device if this device is not

intended to be active.

WEEE Warning

To avoid the potential effects on the environment and

human health as a result of the presence of

hazardous substances in electrical and electronic

equipment, end users of electrical and electronic

equipment should understand the meaning of the crossed-out

wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

PLANET IEEE 802.3at Gigabit High Power over Ethernet Adapter

User’s Manual

For Models:

IEEE 802.3at Gigabit High Power over Ethernet Injector:

POE-161

IEEE 802.3at Gigabit High Power over Ethernet Splitter:

POE-161S

Revision: 1.0 (January, 2010)

Part No.: 2350-AF0280-000

Table Of Contents

1. Package Content............................................................... 6

2. Product Features............................................................... 7

3. Product Specication....................................................... 10

4. Product Outlook.............................................................. 14

5. Hardware Installation ...................................................... 16

5-1 POE-161 ................................................................. 16

5-2 POE-161S ............................................................... 19

Customer Support ............................................................. 23

1. Package Content

Thank you for purchasing PLANET IEEE 802.3at High Power over

Ethernet Adapter, POE-161 and POE-161S. Terms of “802.3at

PoE Injector” in following section of this User’s Manual means

the POE-161, Terms of “802.3at PoE Splitter” in following

section of this User’s Manual means the POE-161S.

Upon open the box of the IEEE 802.3at High Power over

Ethernet Adapter and carefully unpack it. The box should contain

the following items:

POE-161:

The IEEE 802.3at Gigabit High Power over Ethernet Injector

x 1

User’s Manual x 1

DC 56V Power Adapter x 1

Power Cord x 1

POE-161S:

The IEEE 802.3at Gigabit High Power over Ethernet Splitter

x 1

User’s Manual x 1

15cm UTP Straight Network Cable x 1

DC Plug cable x 2

If any of these are missing or damaged, please contact your

dealer immediately, if possible, retain the carton including the

original packing material, and use them against to repack the

product in case there is a need to return it to us for repair.

2. Product Features

POE-161:

Interface

2-Port RJ-45 interfaces

1-Port Data + Power output

1-Port Data input

1 DC 56V input power socket

PoE

Gigabit High Power over Ethernet Mid-Span PSE

Pre-IEEE 802.3at compliant

IEEE 802.3af splitter devices compatible

Support PoE Power up to 30 Watts for PoE port

Up to 1 IEEE 802.3at devices powered

Provides DC 56V power over RJ-45 Ethernet cable to device

with Ethernet port

Auto-detect of POE IEEE 802.3at equipment and devices

from being damaged by incorrect installation

Remote power feeding up to 100m

Hardware

Plastic case

LED indicators for Power LED and PoE In-use

Standard Compliance

IEEE 802.3 10Base-T

IEEE 802.3u 100Base-TX

IEEE 802.3ab 1000Base-T

IEEE 802.3at Power over Ethernet pre-standard

FCC Part 15 Class A, CE

≤

POE-161S:

Interface

2-Port RJ-45 interfaces

1-Port PoE Power+ Data input

1-Port Data output

1 DC out plug connector

PoE

Complies with IEEE 802.3at Power over Ethernet pre-stan-

dard, PD

Splits the 56V DC power over RJ-45 Ethernet cable into DC

5V/12V output

Up to 1 non-IEEE 802.3at devices powered

Auto-detect of PoE IEEE 802.3at equipment, protect devices

from being damaged by incorrect installation

Adjustable two different output voltage options (5V/4.5A,

12V/2A) to t various devices

Distance up to 100 meters

IEEE 802.3af Injector devices compatible

Hardware

Plastic case

5V /12V DIP switch

LED indicators power input indication

Standard Compliance

IEEE 802.3 10Base-T

IEEE 802.3u 100Base-TX

IEEE 802.3ab 1000Base-T

IEEE 802.3at Power over Ethernet pre-standard

FCC Part 15 Class A, CE

≤

Note

PSE (Power Sourcing Equipment) is a device

(switch, or hub for instance) that will provide

power in a PoE setup. Maximum allowed contin-

uous output power per such device in IEEE 802.3af

is 15.4W, 30W in IEEE 802.3at pre-standard.

PD (Powered Device) is a PoE-enabled terminal

by PSE and thus consumes energy, such as IP

Phones, network cameras and Wireless access

points, etc

3. Product Specication

POE-161:

Product POE-161

Hardware Specication

Interface

“Data” Input Port 1 x RJ-45 STP

“PoE (Data+Power)”

Output Port 1 x RJ-45 STP

DC 56V Input power

socket 1

LED Indicator System: Power x 1 (Green)

PoE Port: PoE in Use x 1 (Green)

Network Cable

10Base-T: 2-Pair UTP Cat. 3, 4, 5,

up to 100m (328ft)

100Base-TX: 2-Pair UTP Cat. 3, 4, 5,

up to 100m (328ft)

1000Base-T: 2-Pair UTP Cat. 5, 5e, 6

up to 100m (328ft)

EIA/TIA- 568 100-ohm STP (100m)

Data Rate 10/100/1000Mbps

Dimension (W x D x H) 95 x 70 x 25 mm

Weight 83g

Unit Input Voltage DC 56V, 0.53A

Power Requirement 100-240V AC, 50/60Hz

Power Consumption 30 Watts max.

Number of device can be

powered 1

Operating Temperature 0 ~ 50 Degree C

Storage Temperature -10 ~ 70 Degree C

Humidity 5 ~ 95% (Non-condensing)
