Planet UE-9500 Bedienungsanleitung

USB

10/100Mbps

Fast Ethernet Adapter

UE-9500

User s Manual

FCC COMPLIANCESTATEMENT

This equipment has been tested and found to complywith the limits ofaClass B

computing devices, pursuant to Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in aresidential in-

stallation. Thisequipment generates, usesandcan radiate radio frequency energy

and, if not installed and used in accordance with the instructions, maycause harmful

interference toradio communications.

If you suspect thisproduct is causing interference, turnyourcomputer on andoff

while yourradioor TVisshowinginterference. If theinterference disappears then

when you turn the computer off and reappears then you turn the computer on,

something in the computer is causing interference.

Youcan try tocorrect the interference by one or more of the following measures:

1. Reorient/Relocate thereceiving antenna.

2. 2.Increase the separation between the equipmentand receiver.

3. Connect the equipment into an outlet ona circuitdifference from that to

which the receiveris connected.

4. Ensure thatall expansion slots (on the back or side of the computer) are covered. Also

ensure that all metal retaining brackets are tightly attached to the computer.

1. Introduction

Thanks you forpurchasing our UE-9500. This guide is to provide the installation

and usage of this adapter for network installers and users.

The UE-9500 provides aconvenient and cost-effective wayof connect the

notebook or desktop PCto an IEEE802.3/802.3ustandard FastEthernetnet-

work based on the Universal Serial Bus (USB).This is designed for both the

Notebook and Desktop PC thathas USBconnector and operatingsystem sup-

ported. Using UE-9500 you can simplifyyour Network connections at home,

office and even on theroad.

Full/Half Duplexoperationmode is auto-detected.In Full-Duplexmode, theUSB

adapter is connected to aswitch on adedicated segment. With transmission and

reception taking place simultaneously, data transfer is double.

This adapter has support Windows95(OSR2.1)/98/Me/2000/XP. Whateveryour

requirements areeaseof installation, superior performance or responsive

support backed upbyunlimited technical support, thisadapter is thesuperior

choice.

2. Features & Specifications

(1)Features &Benefits

q USB specification1.0 and 1.1 compliant and Plug & PlaySupport

q Support Full-Speed USBdatatransfer bandwidth, all USB standard

commands and Suspend/Resume detection function.

q Complies withIEEE 802.310BaseTand802.3u 100BaseTXstandards.

q Automatically negotiates10 or 100Mbpsconnection rate, depending

on speed of the network.

(2)Technical Specification

q USB Standards: USB Specification 1.1

q Ethernet Standards: IEEE802.3 and 802.3u

q Connectors: RJ45 x 1, USB TypeB x 1

q LEDs: 2; 100M, LNK/ACT

q Driver Support:NDIS driver - MicrosoftWindows 95OSR2.1/98/Me/XP/2000

q Dimensions: 78mm x45mm x23mm (Lx WxH)

q Weight: 50g

q Temperature: 0 to 50oC

q Humidity: 10% to 90%

q Certification: FCC, CE Mark

3. Installation

The diskette that comes with the package contains the device drivers of this

USB Fast EthernetAdapter. The hardware andsoftwaredriversinstallation are

described as following,

(1)Hardware Installation

Step1. Connect the RJ-45 connector of UE-9500 to the 10/100Mbps

Hub/Switch ofyourLAN by using atwisted-paircable. (maximum

length 100meters). UseCategory3,4or 5cable for10 Mbps

Ethernet and Category 5cable for 100 Mbps Fast Ethernet.

Step2. Connect the USB Type Bconnector of theUSBAdapterand your

PC sor USB Hub sUSB Type Aconnectorbyusingthe standard

USB Cable(max length5m)

(2)SoftwareInstallation

The driversand utilitiesare supplied by the diskette included in this

package.

Before Installing the DeviceDriver

Before you goon installing this USBdevice driver, you must first make

sure that the USB controller of your computer has been properlydetected

and configured under Windows. Also make sure that the USB port is en-

abled. Check the user smanual of yourcomputer for more information on

howto use the USB port.

Driver Installationof Win95OSR2.1/98/Me

1. Connect the UE-9500 to your PC

2. Windowswilldetect thisdevice andthe NewHardware Wizard will

appear.

3. Installation will ask youto select which driveryou want to install,

please select "Driver from disk provided by hardware manufacturer".

4. Insert the driver disk into drive Aand specifythesetup file path name

A:\.

5. If Windowsappears amessage that it cannot found NET8511.INF or

NET8511.SYS, please specify thedriver path name A:\

6. Windowswill appear some messages to ask Windowssystem disk,

please insert the Windowssystem CDto yourCD-ROM tocomplete

setup step.

7. Windowswill finish the installation procedure automatically, then ask

you restart the system. Please click “Yes”torestart.

Driver Installationof Win2000/XP

1. Connect the UE-9500 to your PC

2. Windowswilldetect thisdevice andthe NewHardware Wizard will

appear.

3. Install Hardware DeviceDriverWizard will askyouhowto install,

please select "Search for a suitable driver formy device".

4. Locate DriverFiles Wizard willask you where isthe driverlocation,

please select "Floppy disk driver".

5. When adialog boxappears to prompt you the Digital Signature not

found, please press "Yes" button to continue.

6. If Win2000/XPappear amessage that it cannot found NET8511.INF or

NET8511.SYS, please specify thedriver path name A:\.

7. Win2000/XP willappear some messages to ask you the Windows2000

/XPsystem disk,pleaseinsert the Windowssystem CDto your

CD-ROM and click “OK”to continue.

8. After finishedthe installation, please restart your PC.

4. Trouble-Shooting

If you experience anyproblems with this Adapter, please make sure the ap-

propriate driver isloadedfirstly, the proper cableis connected totheadapter

and the hub complies with the adapter specification, then check the LED.

This adapterprovides two LEDstoindicate networkstatus.

(1)100

This LEDindicates theconnection speed of theUSBEthernetAdapter.

When the Light is OFF, it indicates that the 10Mbps UTPconnection is

established. When the Light is ON, it indicates that the100MbpsFast

Ethernet connection is established.

(2)LNK/ACT

The LNk/ACTLED indicates that the 10/100Mbps UTP connection has been

LINK OKor not. When the light is OFF,it indicates that the10/100Mbps

port has not been connected or LINK not OK. When the light is ON, it in-

dicates that the 10/10Mbps port connect OK. When the light is Blinking,it

indicates that there is traffic flowon the network that the adapter is con-

nected to.
