Planet NVR-1600 Bedienungsanleitung
H.265+ 16-ch 4K Network Video Recorder
NVR-1600
Quick Installation Guide
Table of Contents
1. Package Contents................................................................................. 3
2. Hard Disk Installation ........................................................................... 4
3. Requirements....................................................................................... 5
4. Starting Web Management .................................................................... 6
4.1 Logging in to the NVR-1600............................................................ 7
5. Customer Support ................................................................................ 9
3
1. Package Contents
Thank you for purchasing PLANET H.265+ 16-ch 4K Network Video Recorder,
NVR-1600. Open the box of the NVR-1600 and carefully unpack it. The box
should contain the following items:
zThe NVR-1600 x 1
zQR Code Sheet x 1
zHDD Screw Package x 1
zPower Adapter x 1
If any item is found missing or damaged, please contact your local reseller for
replacement.
4
2. Hard Disk Installation
The hard disk is installed as shown in Figure 2-1.
(1) Unscrew the cover to open the cover.
(2) Connect one end of the hard disk data cable and power cable to the moth-
erboard, and connect the other end to the hard disk.
(3) Turn over the chassis, mount the hard disk in the indicated position and
screw it tightly.
(4) Now turn over the chassis again and cover it with screws.
1. Before installation, make sure the power is disconnected.
2. Use the NVR dedicated hard drive for monitoring recom-
mended by the device manufacturer.
(1) (2)
Figure 2-1: Hard Disk Installation
5
3. Requirements
zWorkstations running Windows XP/2003/2008/Vista/7/8/10/11, or later,
Linux, UNIX, or other platforms are compatible with TCP/IP protocols.
zWorkstations are installed with Ethernet NIC (Network Interface Card)
zEthernet Port Connection
Network cables -- Use standard network (UTP) cables with RJ45
connectors.
The above PC is installed with Web browser.
It is recommended to use Internet Chrome 98.0.xxx or above to
access the NVR-1600. If the Web interface of the NVR-1600 is
not accessible, please turn off the anti-virus software or firewall
and then try it again.
6
4. Starting Web Management
The following shows how to start up the Web Management of the NVR-1600.
Note the NVR-1600 is congured through an Ethernet connection. Please make
sure the manager PC must be set to the same IP subnet address.
IP cam
User PC
(192.168.0.X)
PoE Ethernet Switch NVR
Figure 4-1: IP Management Diagram
1. Make sure the input voltage matches the NVR consumption.
Connect the device to the monitor and the power adapter (if
available). Plug in the power and switch on the power button
(if available) for the device to boot up.
2. It is recommended that you refer to international standards
for power supply input with stable voltage values and low
ripple interference.
For example, the NVR-1600 default network type is DHCP Client; to search the
current IP address of the NVR-1600, follow the procedure below:
1. Download the “PLANET Search Tools” utility from the following PLANET
website link: http://www.planet.com.tw/en/support/downloads?method=key
word&keyword=PLANET+Search+Tools&view=6#list
2. Install the “PLANET Search Tools” utility.
3. After the utility is launched, all NVRs found in your local area network will
be displayed.
4. The existing NVR-1600 in the local network.
5. Search the NVR-1600 in the network.
6. Modify the IP parameters of the selected NVR-1600.
7. Select the NVR-1600 you want to congure and double-click on it.
8. You will be connected to the NVR-1600 series via web browser automati-
cally.
7
Figure 4-2: PLANET Search Tools Utility Screen
9. Without DHCP server, the NVR-1600 default IP address is 192.168.0.20.
Then the manager PC should be set to 192.168.0.x (where x is a
number between 1 and 254, except 20), and the default subnet mask is
255.255.255.0.
4.1 Logging in to the NVR-1600
1. When the following dialog box appears, enter the default user name and
password “admin”. The login screen in Figure 4-3 appears.
Default Username: admin
Default Password: admin
Figure 4-3: NVR-1600 Web Login Screen
8
When the browser fails to enter the device login interface, select
“Control Panel of PC > Network & Sharing > Internet Options >
Security > Custom Level > ActiveX controls and plug-ins” and
enable all of them.
2. After entering the username and password, the main screen appears as
Figure 4-4 shows.
Figure 4-4: Web Main Screen of NVR-1600
Now, you can use the Web management interface to continue the NVR-1600
management.
Please refer to the user’s manual for more.
9
5. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resource and User’s Manual on PLANET Web site rst to check if it could solve
your issue. If you need more support information, please contact PLANET
support team.
PLANET online FAQs:
http://www.planet.com.tw/en/support/faq?method=category&c1=8
Support team mail address:
NVR-1600 User’s Manual:
https://www.planet.com.tw/en/support/downloads?&method=keyword&keyword
=NVR-16&view=3#list
(Please select your switch model name from the Product Model drop-down
menu.)
Android APP IOS APP
Copyright © PLANET Technology Corp. 2023.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
