Planet GSD-805 Bedienungsanleitung

8-Port 10/100/1000Mbps Gigabit Ethernet Switch

GSD-805 / GSD-805F

User's Manual

Trademarks

Contents subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks

belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all

environments and applications, and makes no warranty and representation, either

implied or expressed, with respect to the quality, performance, merchantability, or

tness for a particular purpose.

PLANET has made every effort to ensure that this User’s Manual is accurate;

PLANET disclaims liability for any inaccuracies or omissions that may have

occurred.

Information in this User’s Manual is subject to change without notice and does not

represent a commitment on the part of PLANET. PLANET assumes no responsibility

for any inaccuracies that may be contained in this User’s Manual. PLANET makes

no commitment to update or keep current the information in this User’s Manual,

and reserves the right to make improvements to this User’s Manual and/or to the

products described in this User’s Manual, at any time without notice.

If you nd information in this manual that is incorrect, misleading, or incomplete,

we would appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the Instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation.

For energy saving, please remove the power cable to disconnect the device from

the power circuit.

Without removing power cable, the device will still consuming power from the

power source. In the view of Saving the Energy and reduce the unnecessary power

consuming, it is strongly suggested to remove the power connection for the device

if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a

result of the presence of hazardous substances in electrical and electronic

equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not

dispose of WEEE as unsorted municipal waste and have to collect such WEEE

separately.

Revision

PLANET 8-Port 10/100/1000Mbps Gigabit Ethernet Switch User's Manual

For Models: GSD-805 (v2) / GSD-805F

Revision: 2.0 (DEC, 2010)

Part No: EM-GSD-805_805F_v2.0 (2350-A33230-001)

Table Of Contents

1. Introduction ............................................................................................... 5

1.1 Package Contents ............................................................................... 5

1.2 How to Use This Manual...................................................................... 5

1.3 Product Features................................................................................. 6

1.4 Product Specications ......................................................................... 7

2. Installation................................................................................................. 8

2.1 Product Description ............................................................................. 8

2.1.1 Product Overview ....................................................................... 8

2.1.2 Switch Front Panel ..................................................................... 9

2.1.3 LED Indicators ........................................................................... 9

2.1.4 Switch Rear Panel .....................................................................10

2.2 Installing the Switch ..........................................................................11

2.2.1 Desktop Installation...................................................................11

2.3 Installing SFP Module (GSD-805F Only) ...............................................12

3. Switch Operation ........................................................................................13

3.1 Address Table ....................................................................................13

3.2 Learning ...........................................................................................13

3.3 Forwarding & Filtering ........................................................................13

3.4 Store-and-Forward .............................................................................14

3.5 Auto-Negotiation................................................................................14

4. Troubleshooting ..........................................................................................15

APPENDIX A: Networking Connection................................................................16

A.1 Switch's RJ-45 Pin Assignments ............................................................16

A.2 RJ-45 cable Pin Assignments ................................................................17

1. Introduction

1.1 Package Contents

Check the contents of your package for following parts:

Gigabit Ethernet Switch x 1

User's Manual x 1

Power Cord x 1

Rubber Feet x 4

If any of these are missing or damaged, please contact your dealer immediately,

if possible, retain the carton including the original packing material, and use them

against to repack the product in case there is a need to return it to us for repair.

In the following section, the term “Gigabit Ethernet Switch” means the GSD-

805 and GSD-805F.

1.2 How to Use This Manual

This Gigabit Ethernet Switch User Manual is structured as follows:

Chapter 2 Installation

The chapter explains the feature, functionality and the physical installation of the

Gigabit Ethernet Switch.

Chapter 3 Switch operation

The chapter explains the Gigabit Ethernet Switch transmit operation.

Chapter 4 Troubleshooting

The chapter explains the troubleshooting of the Gigabit Ethernet Switch.

Appendix A

This chapter contains cable information of the Gigabit Ethernet Switch.

1.3 Product Features

Comply with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3abl

1000Base-T and IEEE 802.3z 1000Base-SX / LX (GSD-805F) Ethernet standard

GSD-805: 8-Port 10/100/1000Mbps Gigabit Ethernetl

GSD-805F: 8-Port 10/100/1000Mbps with 1 SFP Port (Shared with Port 1)l

Features Store-and-Forward mode with wire-speed ltering and forwarding ratesl

Hardware based 10/100Mbps, Half / Full Duplex and 1000Mbps Full Duplexl

mode, Flow Control and Auto-negotiation

IEEE 802.3x Flow Control for Full Duplex and Back-pressure for Half Duplexl

operation

Integrated address look-up engine, support 8K absolute MAC addressesl

1Mbit on-chip frame bufferl

9K Jumbo packet Featurel

Automatic address learning and address agingl

Supports Auto MDI/MDI-X functionl

Support CSMA/CD protocoll

Internal power adapter 100-240V AC, 50/60Hz, 0.2Al

FCC, CE class A compliantl

1.4 Product Specications

Product GSD-805 GSD-805F

Hardware Specication

Hardware Version 2 1

10/100/1000Base-T Ports 8

SFP/mini-GBIC Slot NA 1 SFP Shared with Port 1

Dimensions (W x D x H) 191 mm x 85.7 mm x 26.3 mm

Weight 430g 440g

Power Requirement Internal power 100-240V AC, 50/60Hz, 0.2A

Power Consumption /

Dissipation 8.6Watts / 29BTU 9.2Watts / 31BTU

Switch Specication

Switch Processing Scheme Store-and-Forward

Address Table 8K entries

Share Data Buffer 1Mbit on-chip frame buffer

Flow Control Back pressure for Half Duplex

IEEE 802.3x Pause Frame for Full Duplex

Switch Fabric 16Gbps / non-blocking

Throughput

(packet per second) 11.9Mpps@64Bytes

Network

Cables

UTP Cat. 3, 4, 5, 5e, 6 UTP cable (100 meters, max.)

EIA/TIA-568 100-ohm STP (100 meters, max.)

Fiber

(GSD-805F)

50/125μm or 62.5/125μm multi-mode ber cable, up

to 220/550m.

9/125μm single-mode cable, up to

10/15/20/30/40/50/60/70/120km (Vary on ber

transceiver or SFP module)

Standards Conformance

Standards Compliance

IEEE 802.3 Ethernet

IEEE 802.3u Fast Ethernet

IEEE 802.3ab Gigabit Ethernet

IEEE 802.3x Full-duplex Flow Control

IEEE 802.3z Gigabit Fiber Ethernet (GSD-805F)

Temperature Operating: 0 ~ 45 Degree C

Storage: -40 ~ 70 Degree C

Humidity Operating Operating: 5% to 90%, Storage: 5% to 90%

(Non-condensing)

Regulation Compliance FCC Part 15 Class A, CE

2. Installation

This section describes the functionalities of the Gigabit Ethernet Switch’s

components and guides how to install it on the desktop. Basic knowledge of

networking is assumed. Please read this chapter completely before continuing.

2.1 Product Description

The PLANET GSD-805 and GSD-805F are Gigabit Ethernet Switch with non-blocking

wire-speed performance and new metal shape for easily desktop deployment in

compact housing or SOHO application.

With 16Gbps internal switching fabric and 9K Jumbo frame, the Gigabit Ethernet

Switch can handle extremely large amounts of data in a secure topology linking

to a backbone or high capacity servers. The high data throughput of the device

makes it ideal for most Gigabit environments, especially network upgrades to a

Gigabit environment.

All RJ-45 copper interfaces support 10/100/1000Mbps Auto-Negotiation for optimal

speed detection through RJ-45 Category 5, 5e or 6 cables. Support standard of

Auto-MDI/MDI-X feature which can detect the type of connection to any Ethernet

device without requiring special straight or crossover cables.

The Flow Control function allows Gigabit Ethernet Switch supported routers and

Servers to directly connect to this device for fast, reliable data transfer.

2.1.1 Product Overview

The PLANET Gigabit Ethernet Switch can also automatically identify and determine

the correct transmission speed of Half / Full Duplex mode. The Gigabit Ethernet

Switch also supports Store-and-Forward forwarding scheme to ensure low latency

and high data integrity, eliminates unnecessary trafc and relieves congestion on

critical network paths. With an intelligent address recognition algorithm, the Gigabit

Ethernet Switch could recognize up to 8K different MAC address and enables

ltering and forwarding at full wire speed.

2.1.2 Switch Front Panel

Figure 2-1 and 2-2 show front panel of GSD-805 and GSD-805F.

Figure 2-1: GSD-805 Front Panel

PWR 1

3572468

ACTLNK

1000

GSD-805F

8-Port Gigabit Ethernet Switch with 1 SFP Slot

Figure 2-2: GSD-805F Front Panel

Note

1. TP Port 1 and SFP Slot 1 are shared combo interface.

2. Please connects either SFP Slot 1 or TP Port 1 at a time. Not allow

to connect both at the same time.

2.1.3 LED Indicators

GSD-805 / GSD-805F

System

LED Color Function

PWR Green Light: Indicate that the Switch has power.

Per 10/100/1000Base-T RJ-45 Port

LED Color Function

1000 Green

Light: Indicate that the Switch is successfully

connecting to the network at 1000Mbps.

OFF: Indicate that the Switch is successfully connecting

to the network at 10Mbps or 100Mbps.

LNK/ACT Green

Light: Indicate the link through that port is

successfully established.

Blink: Indicate that the Switch is actively sending or

receiving data over that port.

Per 1000Base-X SFP Port (GSD-805F)

LED Color Function

LNK/ACT Green

Light: Indicate that the Switch is successfully

connecting to the network at 1000Mbps.

Blink: Indicate that the Switch is actively sending or

receiving data over that port.

2.1.4 Switch Rear Panel

Figure 2-3 shows a rear panel of GSD-805 and GSD-805F.

12345678

100~240V AC

50/60Hz

OFF

Figure 2-3: GSD-805 / GSD-805F Rear Panel

Power

Notice

1. The device is a power-required device, it means, it will not work

till it is powered. If your networks should active all the time,

please consider using UPS (Uninterrupted Power Supply) for your

device. It will prevent you from network data loss or network

downtime.

2. In some area, installing a surge suppression device may also

help to protect your Switch from being damaged by unregulated

surge or current to the Switch or the power adapter.

Andere Handbücher für GSD-805

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Planet Schalten Handbücher

Planet

Planet GSW-1601 Bedienungsanleitung

Planet

Planet FSP-804P Bedienungsanleitung

Planet

Planet KVM-1600 Bedienungsanleitung

Planet

Planet POE-2400G Bedienungsanleitung

Planet

Planet MGSW SERIES Bedienungsanleitung

Planet

Planet FSD-504HP Bedienungsanleitung

Planet

Planet WGs-4215-8HP2S Bedienungsanleitung

Planet

Planet SGS-6341 Series Montageanleitung

Planet

Planet POE-400 Bedienungsanleitung

Planet

Planet IGS-10020HPT-U Bedienungsanleitung

Planet

Planet LRP-422CST Bedienungsanleitung

Planet

Planet FSD-503 Bedienungsanleitung

Planet

Planet KVM-210 M Series Bedienungsanleitung

Planet

Planet GSD-1020 Bedienungsanleitung

Planet

Planet IGSW-24040T Bedienungsanleitung

Planet

Planet GS-5220-16S8C Bedienungsanleitung

Planet

Planet IGS-5227X-4P2T Bedienungsanleitung

Planet

Planet KVM-810 Bedienungsanleitung

Planet

Planet FGSW-2402RS Bedienungsanleitung

Planet

Planet GSW-1820HP Bedienungsanleitung

Planet

Planet XGS3-24042 Bedienungsanleitung

Planet

Planet IFGS-1022HPT Bedienungsanleitung

Planet

Planet USB 2.0 External Hub UH-421 Bedienungsanleitung

Planet

Planet GSD-1222VHP Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
