Planet KVM-800 Bedienungsanleitung

Trademarks

Contents subject to revise without prior notice.

PLANET is a registered trademark of PLANET Technology

Corp. All other trademarks belong to their respective own-

ers.

Disclaimer

PLANET Technology does not warrant that the hardware will

work properly in all environments and applications, and

makes no warranty and representation, either implied or ex-

pressed, with respect to the quality, performance, mer-

chantability, or fitness for a particular purpose.

PLANET has made every effort to ensure that this User’s

Manual is accurate; PLANET disclaims liability for any in-

accuracies or omissions that may have occurred.

Information in this User’s Manual is subject to change with-

out notice and does not represent a commitment on the part

of PLANET. PLANET assumes no responsibility for any in-

accuracies that may be contained in this User’s Manual.

PLANET makes no commitment to update or keep current

the information in this User’s Manual, and reserves the right

to make improvements to this User’s Manual and/or to the

products described in this User’s Manual, at any time without

notice.

If you find information in this manual that is incorrect, mis-

leading, or incomplete, we would appreciate your comments

and suggestions.

FCC Warning

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference when the

equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

Instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own

expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference, in which case the

user may be required to take adequate measures.

Revision

PLANET 8/16-port KVM Switch User's Manual

FOR MODEL: KVM-800, KVM-1600

REVISION: 2.0

Part No.: EM-KVM8V2

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION .............................................. 1

1.1 FEATURES ........................................................................ 1

1.2 PACKAGE CONTENTS ........................................................ 2

1.3 TECHNICAL SPECIFICATIONS ............................................. 3

CHAPTER 2 INSTALLATION................................................ 4

2.1 SYSTEM REQUIREMENTS................................................... 4

2.2 CABLE DIAGRAMS............................................................. 5

2.3 PRODUCT DETAILS............................................................ 5

2.4 HARDWARE INSTALLATION ................................................. 7

2.5 DAISY CHAIN CONNECTION DIAGRAM .............................. 10

2.6 HOT PLUG.......................................................................11

CHAPTER 3 OPERATION................................................... 13

3.1 PASSWORD PROTECTION ................................................ 13

3.2 SELECTING PC THROUGH PUSH BUTTONS....................... 13

3.3 SELECTING PC THROUGH HOT KEY................................. 14

3.4 ON SCREEN DISPLAY OPERATION.................................... 17

CHAPTER 4 TROUBLESHOOTING ................................... 21

- 1 -

CHAPTER 1 INTRODUCTION

Thank you for purchasing PLANET KVM switch. KVM

switch can save your MONEY, TIME, SPACE, EQUIPMENT

and POWER.

The KVM-800 and KVM-1600 allows you to control 8 and 16

different PCs using just one keyboard, monitor and mouse.

Eight KVM-800 and KVM-1600 switches (banks) can be

daisy-chained together to control up to 128 PCs by single

console. Two buttons on the front panel allow you to select

the switch(bank)and port. The on-screen display (OSD)

feature provides a friendly interface for naming and select-

ing a specific PC. Furthermore, not only support computer

with PS/2 interface. iMAC, Power MAC and Sun Microsys-

tems with only USB port can also be connected through

PLANET's USB-PS2 adapter and control by PS/2 keyboard

and mouse. It's the perfect choice for server room, Internet

or testing site where need to manage multiple computers

efficiently and easily.

1.1 Features

 Rack mount size design

 Support Microsoft Intellimouse, Microsoft Intellimouse

Explorer, Logitech Net Mouse or the other fully compati-

ble MS mouse

 Daisy Chain up to 7 additional units to control up to 128

computers from single console

 Support DOS, Win3.X, Win95/98/98SE/2000/ME/XP,

WinNT, Netware, SCO Unix, HP Unix, Linux

 On Screen Display (OSD) supported – provides the user

- 2 -

a visual interface to name and select computers

 Hot Plug - Add PCs or Remove Connected PCs for

Maintenance without Powering Down the KVM switch or

PCs

 Very High Video Quality - Up To 1920X1440, Bandwidth:

200MHz

 No Software Required - easy PC selection via On Screen

Display Manual, Push Buttons, Hot Keys

 Support eight characters password protection and search

PC server name

 Auto Scan Mode for monitoring PCs and flexible Scan

time from 5~99 seconds

 Keyboard status restored when switching PCs

 LED Display for easy status monitoring

 Buzzer sound for switching port confirmation.

 Using Standard Keyboard, VGA, Mouse cable.

 Built-in one extra daisy chain port and no waste any PC

port

 No DIP switch setting needed and auto detect daisy

chain bank

1.2 Package Contents

KVM Switch 1 PCS

User’s Manual 1 PCS

AC to DC Power Adapter 1 PCS

Rack Mount Kit 1 SET

Daisy Chain Cable 1 SET

- 3 -

1.3 Technical Specifications

Model No. KVM-800 KVM-1600

PC Port 8 16

Console Port 1

Daisy Chain Port 1

PC Port Connector

(All Female Type)

PS/2 Keyboard mini Din 6 pin

PS/2 Mouse Mini Din 6 pin

VGA HDDB 15pin

Console Port Con-

nector

(All Female Type)

PS/2 Keyboard mini Din 6 pin

PS/2 Mouse Mini Din 6 pin

VGA HDDB 15pin

Daisy Chain Port

Connector

(All Female Type)

PS/2 Keyboard mini Din 6 pin

PS/2 Mouse Mini Din 6 pin

VGA HDDB 15pin

PC selection On Screen Display Menu, Hot Key, Push Button

7 segment LED One Bank LED, Two PC Port LEDs

On Screen Display

Control

Yes

Scan Intervals 5~99 Sec.

Keyboard Emula-

tion

PS2

Mouse Emulation PS2

VGA Resolution Up to 1920X1440

Bandwidth 200MHz

MAX PC Connec-

tion

120 128

Housing Metal

Power Adapter DC 12V 1A or DC 9V 1A

Operation Temp. 0 ~ 40 degree C (32 ~ 104degree F)

Storage Temp. -20 ~ 60 degree C (-4 ~ 140 degree F)

Humidity 0~80% RH, Non-Condensing

Size 19” Rack Mount / 1RU 19” Rack Mount / 2RU

Weight (kg) 2.3 4.1

Dimension (mm) 410(L) x 172(W) x 44(H) 410(L) x 172(W) x 88(H)

- 4 -

CHAPTER 2 INSTALLATION

2.1 System Requirements

KVM-800

Model No. 8 port KVM Switch

Console side One VGA Monitor

One PS/2 Keyboard

One PS/2 Mouse

Computer side 8 HDDB 15 pin male to male VGA cables

8 PS/2 cables male to male for Keyboard

8 PS/2 cables male to male for Mouse

Optional USB-PS/2 adapter for multi-platform PC /

iMAC / Sun

KVM-1600

Model No. 16 port KVM Switch

Console side One VGA Monitor

One PS/2 Keyboard

One PS/2 Mouse

Computer side 16 HDDB 15 pin male to male VGA cables

16 PS/2 cables male to male for Keyboard

16 PS/2 cables male to male for Mouse

Optional USB-PS/2 adapter for multi-platform PC /

iMAC / Sun

- 5 -

2.2 Cable Diagrams

PS/2 Cable:

Mini Din 6 pin Male to Male

VGA Cable:

HDB15 pin Male to Male

AT to PS/2 keyboard

adapter: (Optional)

Din 5 pin Male to Mini Din

6 pin Female

PS2 to DB9 adapter (Op-

tional)

Mini Din 6 pin Female to

DB 9 pin Female

2.3 Product Details

Front Panel of 8-port KVM Switch:

PC Port Select

BankSelect

Current Active Bank Display

CurrentActivePortDisplay

PowerOn/Off

- 6 -

Front Panel of 16-port KVM Switch:

PC Port Select

BankSelect

KVM-1600

16-Port KVM Switch

Bank Select Reset

Bank No. Port No.

Port Select

Power

Current Active Bank Display

CurrentActivePortDisplay

PowerOn/Off

Rear Panel of 8-port KVM Switch:

Daisy Chain Port

Console Port Connector

KVMPortConnector

DC 12V

876543 2 1

Console port

Daisy-chain in

PS/2 Mouse(Console)

VGA Monitor (Console) PS/2 Mouse (computer)

PS/2 Keyboard(Console) VGA Monitor (computer)

Power Adapter PS/2 Keyboard (computer)

Rear Panel of 16-port KVM Switch:

Daisy Chain Port

Console Port Connector

KVMPortConnector

DC 12V

Made in Taiwan

Daisy-chain in Console port 8

16 7

15 6

14 5

13 4

12 3

11 2

10 1

PS/2 Mouse(Console)

VGA Monitor (Console) PS/2 Mouse (computer)

PS/2 Keyboard(Console) VGA Monitor (computer)

Power Adapter PS/2 Keyboard (computer)
