Plustek V1.2 Bedienungsanleitung

Scanner User’s Guide V1.2

An easy-to-use guide to

help you get the most from

your scanner

All trademarks and brand names mentioned in this publication are

property of their respective owners.

reproduced.

Introduction

Welcome to the world of ultimate office imaging. Your new

scanner will help improve the professionalism of your documents by

allowing you to input quality images as well as electronic text into

your computer system.

Like all of our products, your new scanner has been thoroughly

tested and is backed by our reputation for unsurpassed

dependability and customer satisfaction.

Please remember to fill out and return the provided registra tion

card. As a registered customer, you will receive customer support,

new product information and software upgrades.

Thank you for choosing us as your scanner supplier. We hope

you will continue to turn to us for additional quality products as

your computing needs and interests grow.

iii

TABLE OF CONTENTS

INTRODUCTION...................................................................................... ii

HOW TO USE THIS GUIDE ........................................................................v

CONVENTIONS OFTHIS GUIDE................................................................vi

A NOTE ABOUTICONS............................................................................vi

SCANNER’S FEATURES...........................................................................vii

COMPUTERREQUIREMENTS...................................................................vii

PACKAGECONTENTS........................................................................... viii

CHAPTER I. HARDWARE INSTALLATION..................................1

HARDWAREREQUIREMENTS....................................................................2

INSTALLING THESCANNER’S HARDWARE.................................................3

CHAPTER II. SOFTWARE SETUP...................................................5

SOFTWAREINSTALLATIONREQUIREMENTS...............................................6

SOFTWAREINSTALLATION.......................................................................6

SOFTWARESETUPTROUBLESHOOTINGGUIDE ..........................................7

INSTALLINGADDITIONALSOFTWARE.......................................................7

CHAPTER III. USAGE AND MAINTENANCE................................9

OPERATING THESCANNER.....................................................................10

TESTING THESCANNER.........................................................................10

SCANNERUTILITY.................................................................................12

MAINTENANCE......................................................................................13

CLEANINGYOURSCANNER....................................................................13

REMOVING THE SCANNER’S LID

................................................................14

CHAPTER IV. USING TWAIN........................................................15

SCANNINGUSING TWAIN.....................................................................16

CHOOSINGTWAIN...............................................................................17

CONTROL PANEL& SCAN MODE ...........................................................17

TWAIN MENUOPTIONS.......................................................................20

SCANNINGHINTS ..................................................................................26

APPENDIX A: TROUBLESHOOTING...........................................27

APPENDIX B: CUSTOMER SERVICE...........................................30

APPENDIX C: INDEX.......................................................................32

CONTACT PLUSTEK......................................................................36

How to Use This Guide

This User’s Guide provides instructions and illustrations on

how to install and operate your scanner. We recommend that you

read through the entire Hardware Installation, Chapter I, before you

begin installing the scanner.

Chapter I describes how to install the scanner to your computer.

Note:The scanner’s interface is through an Enhanced Parallel

Port (EPP). If your computer does not support EPP, you may

need to purchase an additional parallel port.

Chapter II describes how to install the scanner’s software. We

suggest that you do not install the software before installing the

hardware.

After you complete installing the scanner’s software, test the

scanner by following the steps outlined in Chapter III. Chapter III

describes how to test, maintain and clean your scanner. Chapter IV

describes how to use the TWAINinterface. TWAIN is a scanning

standard and one of the most widely used technologies in the

scanner industry today. Please carefully read through Chapter IV to

learn about how to operate the scanner’s TWAIN interface.

Appendices A & B have technical support information that can

help you solve problems. Before calling for help, please read

through Appendix A: Troubleshooting.

Conventions of This Guide

1. Bold— First use of an important term in a chapter.

2. ALLCAPS— Represent commands.

3. Note — Special information about the current subject

A Note about Icons

This guide uses the following icons to point out information that

deserves special attention.

Danger.A procedure that must be followed carefully to prevent

injury, or accidents.

Caution.Information that, if not followed, may result in data loss

or damage to the product.

Pay Special Attention.Instructions that will ease installation and

prevent mistakes.

Caution

Attention

Danger

vii

Scanner’s Features

• Scanning Area: 8.5” x 11.7” (inches) / A4 210 x 297 mm

• Cold CathodeLamp (for long-lasting operation)

• Scan Method: Single-Pass

• 30-BitColour

• 10-BitGreyscale

• 1-Bit Line-art (Black & White)

• Resolution:

1230P/9631P: 600 x 1200 dots per inch (9600 x 9600 software

interpolated).

600P/4831P: 300 x 600 dots per inch (4800 x 4800 softwareinterpolated)

• TWAINCompliance

• Printer Port Pass-Through

• Connection: Enhanced Parallel Port (EPP)

• 1 Year Warranty (from date of purchase)

• Removable Scanning Lid

Computer Requirements

• Windows/Intel Compatible Personal Computer

• Pentium CPU or Later

• CD-ROM Drive

• 16 MB RAM (32 MB Recommended)

• 60 MB Free Hard Disk Space (100 MB Recommended)

• Enhanced Parallel Port (EPP)

• Windows 3.1x, Windows 9x, or Windows NT 4.x

• Graphics Accelerator (Video Card), with at least 16-bitcolour

support

viii

Package Contents

1. Scanner engine

2. Power adapter

3. Scanner cable

4. CD-ROM

a) Scanner SetupProgramme

b) Optical Character Recognition (OCR) software

c) Image editing software

d) This user’s guide

e) Registration forms

f) OCR & image-editing guides

Chapter I. Hardware Installation

Before installing your scanner, verify that you have all of the

proper components. A list of the package contents is provided on

pageviiiat the beginning of this guide.

Hardware Requirements

Your scanner uses an interface called anEnhanced Parallel

Port. The scanner’s EPP interface allows you to scan information

into your computer as quickly as scanners costing hundreds of

dollars more that use interface cards. If your computer’s printer

port does not support EPP, then it is recommended that you

purchase an additional parallel port interface card that supports

EPP technology to maximize the scanner’s performance.
