PNI IP240 Bedienungsanleitung
PNI IP240
Video surveillance IP camera/IP камера за видеонаблюдение/
Videoüberwachung IP-Kamera/Cámara IP de videovigilancia/Caméra
IP de vidéosurveillance/Videó megfigyelő IP kamera/Telecamera IP di
videosorveglianza/Videobewaking IP-camera/Kamera IP nadzoru wideo/
Camera supraveghere video cu IP
EN User manual ......................................................... 3
BG Ръководство за употреб а .............................. 14
DE Benutzerhandbuch .............................................. 25
ES Manual de usuario ............................................... 36
FR Manuel utilisateur ............................................... 47
HU Használati utasítás .............................................. 58
IT Manuale utente .................................................. 69
NL Handleiding ........................................................ 80
PL Instrukcja obsługi ............................................... 91
RO Manual de utilizare ............................................. 102
3User manual
English
Main features
• Connection modes: WiFi, LAN and AP
• Supports recording on micro SD card, max. 128GB (card not included)
• Two-way audio communication (built-in microphone and speaker)
• Outdoor mounting, protection class IP66, ABS housing
• 8 IR LEDs for night viewing up to 20 m and 8 white LEDs
• Supports P2P connection for remote monitoring
• The camera can be controlled remotely through the CamHi application
(Android/iOS) and through the HiP2P application (Windows PC)
• PTZ control from the dedicated application
What’s in the box
• Surveillance camera
• WiFi antennas
• 230V - 12V/2A power adapter
• Ethernet cable (1 m)
• CD software
Connectors
• 12V power connector - insert the power adapter included in the package
(230V - 12V/2A)
• RJ45 connector - insert the Ethernet cable included in the package to
connect the camera to the router
User manual 4
English
Camera installation and connection
1. Install the WiFi antennas on the camera
2. Install the micro SD card (max. 128GB) in the camera. Note: The micro
SD card is not included in the package.
3. Connect the power adapter to the camera and to a 230V outlet.
Note: Use the power adapter included in the package (12V/2A).
Note:To resetthecamera,holddowntheResetbuttonuntilyouhearaconfirmation
sound.
Quick setup - Add the camera to the application
The camera will start in AP mode when connected to the power supply. You
can connect directly to the camera via AP mode (Acces Point).
On your smartphone, search for the WiFi network created by the camera:
“IPCAM-121221” (example of network).
• Connect to this WiFi network. WiFi password is: “01234567”
• You must keep connected to this WiFi network to continue.
• From the CamHi application, click on “+ Add camera”
• In the next menu click on “Search camera from LAN”
• As a result of the search, the UID and IP of your camera will appear on
5User manual
English
the screen
• Click on the result (change the name of the camera, if you wish) and
confirm from the top right corner.
• The camera will appear online in the application.
• Continue setting up the camera, the procedure described on page 7
“Connect the camera to the WiFi network”.
Configure and view the camera on the mobile phone
Note:
To add and configure the camera through the application, the
camera and the mobile phone must be connected to the same
router (the phone via WiFi to the 2.4 GHz network, and the
camera through the cable LAN cable, as described above).
The default username and password of the camera are admin.
Connect the network cable to the router and to the RJ45 connector of the
camera.
Warnings:
The router must be connected to the internet.
Check if the LAN port in the router where you will connect the camera has internet
access. Use a laptop or PC connected to this port. Green network indicator means
that the transmission of network data is normal.
User manual 6
English
Add the camera to the application
1. Download and install the CamHi app.
Android iOS
2. Open the application, create an account and log in.
3. Click Add Camera
4. In the following interface, you have several options for adding the camera:
• Manually enter the camera UID, username and password (you can find
this data on the label pasted to the camera)
• Scan the QR code from the label pasted on the camera (Scan QR code,
add UID)
• Search the network for the camera (Search Camera from LAN)
Note: If the procedure Search camera from LAN fails, make sure you have
internet access on the LAN port where the camera is connected.
• After successfully adding the camera, tap the camera to view the images
taken by it in real time. Note: the status of the camera must be Online.
7User manual
English
Connect the camera to the WiFi network
1. Click on next to the camera you want to configure. Note: the status
of the camera must be Online.
2. From the settings menu, select Wi-Fi Setting.
3. Select the WiFi network to which you want to connect the camera and
enter its password.
Warning: Make sure this is a 2.4 GHz wireless network. If you also have a 5 GHz
network, contact your network administrator to check and separate the 2.4 GHz
wireless network from the 5 GHz wireless network.
User manual 8
English
Setup recording on micro SD card
1. Install in the camera a micro SD card (max. 128GB). The card installation
location is shown on page 4.
2. Open the mobile application, click on the icon next to the camera
you want to configure. Note: the status of the camera must be Online.
3. From the settings menu, select Action with alarm.
4. Activate the option Alarm SD REC.
5. Return to the main menu and select the option SD Card setting to check
the space available on the card.
6. Make sure that in the menu Recording Schedule the option Enable
Record is checked.
Note: When you use a small capacity micro SD card, we recommend activating
the recording at motion detection. To do this, access the menu Alarm Setting -
Motion Detection.
9User manual
English
7. To view the recordings on the micro SD card installed in the camera, press
the video option from the bottom of the main application interface.
Select the camera and the file you want to play or download.
Note: Detailed instructions about the CamHi application can be found on the CD
included in the package and on the camera’s website.
Configure and view the camera on your computer
Your camera can be accessed from your computer in two ways: through the
Internet Explorer browser or through the HiP2P application.
Access the camera via Internet Explorer
1. Install the Search Tool application (the installation file can be found on
the CD included in the package)
2. Connect your computer and camera to the same router.
User manual 10
English
3. Open the Search Tool application and click on the Refresh button to find
all the cameras on the network.
4. From the displayed list, identify your camera by UID .
5. Click the Next button to configure the network parameters. You can
enter the network parameters manually or check the DHCP option.
Click Next.
6. Open Internet Explorer and add your camera’s IP address to the address
bar or return to the camera list in the Serach Tool application and
double-click the camera you want to view. Internet Explorer will open
automatically.
