Single-Stage

Oilfree

Compressor

Instruction

manual

The Model and Serial No. plate is located on the main

housing of the tool. Record these numbers in the

spaces below and retain for future reference.

Model No.______________________________________

Type ___________________________________________

Serial No. ______________________________________

IMPORTANT

Please make certain that the person who

is to use this equipment carefully reads

and understands these instructions before

starting operations.

Part No. N032607 JUL09

FRANÇAIS : PAGE 25

ESPAÑOL: PÁGINA 51

To learn more

about PORTER-CABLE

visit our website at:

www.deltaportercable.com

MODEL

C5101

PORTER-CABLE Corporation

2- ENG

SAFETY GUIDELINES - DEFINITIONS

This manual contains information that is important for you to know and understand.

This information relates to protecting YOUR SAFETY and PREVENTING

EQUIPMENT PROBLEMS. To help you recognize this information, we use the

symbols below. Please read the manual and pay attention to these symbols.

Indicates an imminently

hazardous situation which, if not

avoided, will result in death or serious

injury.

Indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

Indicates a potentially

hazardous situation which, if not

avoided, could result in death or

serious injury.

Indicates a practice

not related to personal injury which,

if not avoided, may result in property

damage.

IMPORTANT SAFETY INSTRUCTIONS

Este producto contiene sustancias químicas, incluido el

plomo, reconocidas por el Estado de California como causantes de cáncer,

defectos de nacimiento u otros problemas reproductivos. Lávese las manos

después de utilizarlo.

Algunos tipos de polvo contienen sustancias químicas,

como el amianto y el plomo de las pinturas de base plomo, reconocidas por el

Estado de California como causantes de cáncer, defectos de nacimiento u otros

problemas

Para reducir el riesgo de lesiones, lea el manual

de instrucciones.

SAVE THESE INSTRUCTIONS

HAZARD

RISK OF EXPLOSION OR FIRE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Itisnormalforelectrical

contacts within the motor and

pressure switch to spark.

• Alwaysoperatethecompressor

in a well ventilated area free

of combustible materials,

gasoline, or solvent vapors.

• Ifelectricalsparksfrom

compressor come into contact

with flammable vapors, they may

ignite, causing fire or explosion.

• Ifsprayingflammablematerials,

locate compressor at least

20' (6.1 m) away from spray

area. An additional length of

air hose may be required.

• Storeflammablematerials

in a secure location away

from compressor.

3- ENG

• Restrictinganyofthecompressor

ventilation openings will

cause serious overheating

and could cause fire.

• Neverplaceobjectsagainst

or on top of compressor.

• Operatecompressorinanopen

area at least 12" (30.5 cm) away

from any wall or obstruction that

would restrict the flow of fresh

air to the ventilation openings.

• Operatecompressorina

clean, dry well ventilated area.

Do not operate unit in any

confined area. Store indoors.

• Unattendedoperationofthis

product could result in personal

injuryorpropertydamage.

To reduce the risk of fire, do

not allow the compressor

to operate unattended.

• Alwaysremaininattendancewith

the product when it is operating.

• Alwaysturnoffandunplug

unit when not in use.

HAZARD

RISK TO BREATHING (ASPHYXIATION)

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairdirectlyfrom

your compressor is not safe for

breathing. The air stream may

contain carbon monoxide, toxic

vapors, or solid particles from the air

tank. Breathing these contaminants

cancauseseriousinjuryordeath.

• Neveruseairobtaineddirectly

from the compressor to supply

air for human consumption. The

compressor is not equipped with

suitable filters and in-line safety

equipment for human consumption.

• Exposuretochemicalsindust

created by power sanding,

sawing, grinding, drilling,

and other construction

activities may be harmful.

• Sprayedmaterialssuchaspaint,

paint solvents, paint remover,

insecticides, weed killers, may

contain harmful vapors and poisons.

• Workinanareawithgoodcross

ventilation. Read and follow

the safety instructions provided

on the label or safety data

sheets for the materials you are

spraying. Always use certified

safety equipment: NIOSH/OSHA

respiratory protection or properly

fitting face mask designed for use

with your specific application.

4- ENG

HAZARD

RISK OF BURSTING

Air Tank: On February 26, 2002, the U. S. Consumer Products Safety Commission

published Release # 02-108 concerning air compressor tank safety:

Air compressor receiver tanks do not have an infinite life. Tank life is dependent

upon several factors, some of which include operating conditions, ambient condi-

tions, proper installations, field modifications, and the level of maintenance. The

exact effect of these factors on air receiver life is difficult to predict.

If proper maintenance procedures are not followed, Internal corrosion to the

inner wall of the air receiver tank can cause the air tank to unexpectedly rupture

allowingpressurizedairtosuddenlyandforcefullyescape,posingriskofinjuryto

consumers.

Your compressor air tank must be removed from service by the end of the year

shown on your tank warning label.

The following conditions could lead to a weakening of the air tank, and result in a

violent air tank explosion:

WHAT CAN HAPPEN HOW TO PREVENT IT

• Failuretoproperlydraincondensed

water from air tank, causing rust

and thinning of the steel air tank.

• Drainairtankdailyoraftereachuse.

If air tank develops a leak, replace

it immediately with a new air tank

or replace the entire compressor.

• Modificationsorattempted

repairs to the air tank. • Neverdrillinto,weld,ormakeany

modifications to the air tank or its

attachments. Never attempt to

repair a damaged or leaking air

tank. Replace with a new air tank.

• Unauthorizedmodifications

to the safety valve or any

other components which

control air tank pressure.

• Theairtankisdesignedtowithstand

specific operating pressures.

Nevermakeadjustmentsor

parts substitutions to alter the

factory set operating pressures.

Attachments & accessories:

• Exceedingthepressurerat-

ing of air tools, spray guns, air

operated accessories, tires,

and other inflatables can cause

them to explode or fly apart, and

couldresultinseriousinjury.

• Followtheequipmentmanufacturers

recommendation and never exceed

the maximum allowable pressure

rating of attachments. Never use

compressor to inflate small low

pressureobjectssuchaschildren’s

toys, footballs, basketballs, etc.

5- ENG

Tires:

• Over inflation of tires could

result in serious injury

and property damage.

• Useatirepressuregaugetocheck

the tires pressure before each use

and while inflating tires; see the tire

sidewall for the correct tire pressure.

NOTE: Air tanks, compressors and

similar equipment used to inflate

tires can fill small tires very rapidly.

Adjustpressureregulatoronair

supply to no more than the rating

of the tire pressure. Add air in small

increments and frequently use the

tire gauge to prevent over inflation.

HAZARD

RISK OF ELECTRICAL SHOCK

WHAT CAN HAPPEN HOW TO PREVENT IT

• Yourcompressorispoweredby

electricity. Like any other electrically

powered device, if it is not used

properly it may cause electric shock.

• Neveroperatethecompressor

outdoors when it is raining

or in wet conditions.

• Neveroperatecompressor

with protective covers

removed or damaged.

• Repairsattemptedbyunqualified

personnel can result in serious

injuryordeathbyelectrocution.

• Anyelectricalwiringorrepairs

required on this product should be

performed by authorized service

center personnel in accordance with

national and local electrical codes.

• Electrical Grounding: Failure to

provide adequate grounding to

this product could result in serious

injuryordeathfromelectrocution.

Refer to Grounding Instructions

paragraph in the Installation section.

• Makecertainthattheelectrical

circuit to which the compressor

is connected provides proper

electrical grounding, correct voltage

and adequate fuse protection.

6- ENG

HAZARD

RISK FROM FLYING OBJECTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairstreamcan

cause soft tissue damage to

exposed skin and can propel dirt,

chips, loose particles, and small

objectsathighspeed,resultingin

propertydamageorpersonalinjury.

• Alwayswearcertifiedsafety

equipment: ANSI Z87.1 eye

protection (CAN/CSA Z94.3)

with side shields when

using the compressor.

• Neverpointanynozzleorsprayer

toward any part of the body or

at other people or animals.

• Alwaysturnthecompressor

off and bleed pressure from

the air hose and air tank before

attempting maintenance,

attaching tools or accessories.

HAZARD

RISK OF HOT SURFACES

WHAT CAN HAPPEN HOW TO PREVENT IT

• Touchingexposedmetalsuch

as the compressor head, engine

head, engine exhaust or outlet

tubes, can result in serious burns.

• Nevertouchanyexposedmetal

parts on compressor during or

immediately after operation.

Compressor will remain hot for

several minutes after operation.

• Donotreacharoundprotective

shrouds or attempt maintenance

until unit has been allowed to cool.

HAZARD

RISK FROM MOVING PARTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Movingpartssuchasthepulley,

flywheel, and belt can cause

seriousinjuryiftheycomeinto

contact with you or your clothing.

• Neveroperatethecompressor

with guards or covers which

are damaged or removed.

• Keepyourhair,clothing,and

gloves away from moving parts.

Looseclothes,jewelry,orlonghair

can be caught in moving parts.

• Airventsmaycovermovingparts

and should be avoided as well.

• Attemptingtooperatecompressor

with damaged or missing parts or

attempting to repair compressor

with protective shrouds removed

can expose you to moving parts

andcanresultinseriousinjury.

• Anyrepairsrequiredonthisproduct

should be performed by authorized

service center personnel.

7- ENG

HAZARD

RISK OF UNSAFE OPERATION

WHAT CAN HAPPEN HOW TO PREVENT IT

• Unsafeoperationofyour

compressor could lead to serious

injuryordeathtoyouorothers.

• Reviewandunderstandall

instructions and warnings

in this manual.

• Becomefamiliarwiththeoperation

and controls of the air compressor.

• Keepoperatingareaclearofall

persons, pets, and obstacles.

• Keepchildrenawayfromthe

air compressor at all times.

• Donotoperatetheproduct

when fatigued or under the

influence of alcohol or drugs.

Stay alert at all times.

• Neverdefeatthesafetyfea

tures of this product.

• Equipareaofoperation

with a fire extinguisher.

• Donotoperatemachine

with missing, broken, or

unauthorized parts.

HAZARD

RISK OF FALLING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Aportablecompressorcanfall

from a table, workbench, or roof

causing damage to the compressor

andcouldresultinseriousinjury

or death to the operator.

• Alwaysoperatecompressorina

stable secure position to prevent

accidental movement of the unit.

Never operate compressor on a

roof or other elevated position. Use

additional air hose to reach high

locations.

HAZARD

RISK OF INJURY FROM LIFTING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Seriousinjurycanresult

from attempting to lift

tooheavyanobject.

• Thecompressoristooheavytobe

lifted by one person. Obtain assis-

tance from others before lifting.

8- ENG

HAZARD

RISK FROM NOISE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Undersomeconditionsandduration

of use, noise from this product

may contribute to hearing loss.

• Alwayswearcertifiedsafety

equipment: ANSI S12.6

(S3.19) hearing protection.

SAVE THESE INSTRUCTIONS

FOR FUTURE USE

SPECIFICATION CHART

Model No. C5101

Running Horsepower 1.7 *

Bore 2.375" (60.3 mm)

Stroke 1.35" (34.3 mm)

Voltage/Hz-Single Phase 120/60

Minimum Branch Circuit Requirement 15 amps

Fuse Type Time Delay

Air Tank Capacity 20 Gallon (75.7 liters)

Approximate Cut-in Pressure 120 psig

Approximate Cut-out Pressure 150 psig

SCFM @ 40 psig 7.2

SCFM @ 90 psig 5.3

* Tested per ISO 1217

Refer to Glossary for abbreviations.

GLOSSARY

Become familiar with these terms before operating the unit.

CFM: Cubic feet per minute.

SCFM: Standard cubic feet per minute; a unit of measure of air delivery.

PSIG: Pounds per square inch gauge; a unit of measure of pressure.

Code Certification: Products that bear one or more of the following marks: UL®,

CUL, ETL®, CETL, have been evaluated by OSHA certified independent safety

laboratories and meet the applicable Standards for Safety.

Cut-In Pressure:Whilethemotorisoff,airtankpressuredropsasyoucontinue

touseyouraccessory.Whenthetankpressuredropstoacertainlowlevelthe

motor will restart automatically. The low pressure at which the motor automatically

restarts is called "cut-in" pressure.

Cut-Out Pressure:When anaircompressoristurnedonand beginstorun,air

pressure in the air tank begins to build. It builds to a certain high pressure before

the motor automatically shuts off - protecting your air tank from pressure higher

than its capacity. The high pressure at which the motor shuts off is called "cut-out"

pressure.

Branch Circuit: Circuit carrying electricity from electrical panel to outlet.

DUTY CYCLE

This air compressor pump is capable of running continuously. However, to prolong

the life of your air compressor, it is recommended that a 50%-75% average duty

cycle be maintained; that is, the air compressor pump should not run more than

30-45 minutes in any given hour.

9- ENG

ACCESSORIES

Accessories for this unit are available at the store the unit was purchased.

The use of any other accessory not recommended for use with

this tool could be hazardous. Use only accessories rated equal to or higher

than the rating of the air compressor.

ASSEMBLY

TOOLS REQUIRED FOR ASSEMBLY

1 - 9/16" socket or open end wrench

1 - 3/8" socket or open end wrench

1 - 1/2" socket or open end wrench

UNPACKING

Remove unit from carton and dis-

card all packaging. NOTE: Save all

parts bags.

ASSEMBLE HANDLE

1. To make installation easier,

submerge handle grip into

warm soapy water. Remove

handle grip from soapy water

and slide onto handle.

2. Insert the handle inside the

compressor saddle and line up

the two bolt holes on each

side.

3. Install the four screws, two on

each side.

4. Tighten securely.

ASSEMBLE WHEELS

It will be necessary to brace or support one side of the outfit when

installing the wheels because the compressor will have a tendency to tip.

1. Attach wheels with shoulder bolts and nuts as shown. NOTE: Place the bolts

in the bottom hole of the wheel bracket.

2. Tighten securely. NOTE: The outfit will sit level if the wheels are properly

installed.

The wheels and handle do not provide adequate clearance, stabil-

ity or support for pulling the unit up and down stairs or steps. The unit must be

lifted, or pushed up a ramp.

ASSEMBLE RUBBER FEET

1. Attach rubber feet with the screws provided as shown in previous figure.

2. Tighten securely.

Rubber Feet

Screw

Nut

Wheel

Shoulder Bolt

Handle

Screw

Handle Grip

10- ENG

INSTALLATION

HOW TO SET UP YOUR UNIT

Location of the Air Compressor

• Locatetheaircompressorinaclean,dryandwellventilatedarea.

• Theaircompressorshouldbelocatedatleast12"(30.5cm)awayfromthe

wall or other obstructions that will interfere with the flow of air.

• Theaircompressorpumpandshroudaredesignedtoallowforpropercooling.

The ventilation openings on the compressor are necessary to maintain proper

operating temperature. Do not place rags or other containers on or near these

openings.

GROUNDING INSTRUCTIONS

Risk of Electrical Shock. In the event of a short circuit,

grounding reduces the risk of shock by providing an escape wire for the

electric current. This air compressor must be properly grounded.

The portable air compressor is equipped with a cord having a grounding wire with

an appropriate grounding plug (see following illustrations).

1. The cord set and plug with this unit contains a grounding pin. This plug

MUST be used with a grounded outlet.

IMPORTANT: The outlet being used must

Grounded

Outlets

Plug

Grounding Pin

be installed and grounded in accordance

with all local codes and ordinances.

2. Make sure the outlet being used

has the same configuration as the

grounded plug. DO NOT USE AN

ADAPTER. See illustration.

3. Inspect the plug and cord before each

use. Do not use if there are signs of damage.

4. If these grounding instructions are not completely understood, or if in doubt as

to whether the compressor is properly grounded, have the installation checked

by a qualified electrician.

Risk of Electrical Shock. IMPROPER GROUNDING CAN

RESULT IN ELECTRICAL SHOCK.

Do not modify the plug provided. If it does not fit the available outlet, a correct

outlet should be installed by a qualified electrician.

Repairs to the cord set or plug MUST be made by a qualified electrician.

EXTENSION CORDS

If an extension cord must be used, be sure it is:

• a 3wire extension cord that has a 3blade grounding plug, and a 3slot

receptacle that will accept the plug on the product

• ingoodcondition

• nolongerthan50feet

• 12gauge(AWG)orlarger.(Wiresizeincreasesasgaugenumber,decreases.

10AWGand8AWGmayalsobeused.DONOTUSE14OR16AWG.)

Andere Handbücher für C5101

Inhaltsverzeichnis

Sprachen:

Andere Porter-Cable Luftkompressor Handbücher

Porter-Cable

Porter-Cable JOB BOSS CFFC350B Bedienungsanleitung

Porter-Cable

Porter-Cable C7550 Bedienungsanleitung

Porter-Cable

Porter-Cable PXCMSAC420VW Bedienungsanleitung

Porter-Cable

Porter-Cable C2002-WK Bedienungsanleitung

Porter-Cable

Porter-Cable PXCMF226VW Bedienungsanleitung

Porter-Cable

Porter-Cable CPFC2TV3525VP Bedienungsanleitung

Porter-Cable

Porter-Cable C7501M Bedienungsanleitung

Porter-Cable

Porter-Cable CPFAC2600P Bedienungsanleitung

Porter-Cable

Porter-Cable C3001 Bedienungsanleitung

Porter-Cable

Porter-Cable C5512 Bedienungsanleitung

Porter-Cable

Porter-Cable CPFAC2600P Bedienungsanleitung

Porter-Cable

Porter-Cable 1000001703 Bedienungsanleitung

Porter-Cable

Porter-Cable CLFRP350 Bedienungsanleitung

Porter-Cable

Porter-Cable PXCML224VW Bedienungsanleitung

Porter-Cable

Porter-Cable CPF4515 Bedienungsanleitung

Porter-Cable

Porter-Cable D24938-044-2 Bedienungsanleitung

Porter-Cable

Porter-Cable CPLKC7080V2-1 Bedienungsanleitung

Porter-Cable

Porter-Cable JOB BOSS C3550 Bedienungsanleitung

Porter-Cable

Porter-Cable CPLDC2541S Bedienungsanleitung

Porter-Cable

Porter-Cable CPFAC2040P Bedienungsanleitung

Porter-Cable

Porter-Cable C2002 Bedienungsanleitung

Porter-Cable

Porter-Cable CPLC7060V Bedienungsanleitung

Porter-Cable

Porter-Cable CPL55GH8W Bedienungsanleitung

Porter-Cable

Porter-Cable CPLDC2541S Bedienungsanleitung

Beliebte Luftkompressor Handbücher anderer Marken

Sparmax

Sparmax DC-25XR Bedienungsanleitung

KAESER

KAESER M122 Bedienungsanleitung

GMC

GMC GAC1500 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton Air Compressor Bedienungsanleitung

Fini

Fini F3GST2TK Bedienungsanleitung

Industrial Air

Industrial Air CP1580325 Programmierhandbuch

Campbell Hausfeld

Campbell Hausfeld RP3300 Kurzanleitung

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Bedienungsanleitung

Hitachi

Hitachi EC99S Bedienerhandbuch

Parkside

Parkside PKO 270 A1 Bedienungsanleitung

Sullair

Sullair 185 Bedienungsanleitung

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Bedienungsanleitung

Ferm

Ferm CRM1046 Bedienungsanleitung

BE AC153 Bedienungsanleitung

RIDGID

RIDGID OF25150A Bedienungsanleitung

Johnson Controls

Johnson Controls QUANTUM LX Handbuch

Sears

Sears Craftsman 919.167463 Bedienungsanleitung

Ring Automotive

Ring Automotive RAC700 Bedienungsanleitung
