1
MODEL #LWS1204E
ITEM #0338654
Français p. 9
Español p. 17
POST LANTERN
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. -
5 p.m., EST, Friday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
Portfolio ® is a registered trademark
of LF, LLC. All Rights Reserved.
XXXXXX Lowes.com/portfolio
PART DESCRIPTION QUANTITY
A
B Center Stem
Fixture Hood Assembly 1
1
C Fixture Body 1
PACKAGE CONTENTS
2
B
A
B
C
B
B
Lowes.com/portfolio
HARDWARE CONTENTS (shown actual size)
Washer
Qty. 1 Finial
Qty. 1
DDCC
3
SAFETY INFORMATION
AA BB
Wire
Connector
Qty. 3
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
Estimated Assembly Time: 20 - 30 minutes
Tools Required for Assembly (not included): Flathead screwdriver, Phillips screwdriver, Pliers,
Wire cutters, Electrical tape, Safety goggles and Ladder.
Helpful Tools (not included): Wire strippers
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit
breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
Mounting Screw
Qty. 3
Lowes.com/portfolio
4
ASSEMBLY INSTRUCTIONS
1. Carefully fit the post fitter on the fixture body (C)
over the end of the post (not supplied), making
sure the post fitter is fully seated. Mark the drill
point for the 3 mounting screws using 3 mounting
holes as reference. After marking hole locations,
remove fixture from post and drill 1/16 in. pilot
holes for screws (AA).
1
2. Attach ground fixture wire to the ground wire
from the post (usually GREEN or BARE). Connect
the neutral WHITE or RIBBED side fixture wire to
the neutral usually WHITE wire from the post.
Connect the hot BLACK or SMOOTH side fixture
wire to the hot usually BLACK wire from the
post. Fasten wires together with a wire
connector (BB) and tightly wrap wire connector
(BB) with electrical tape (not included).
2
White Wire
From Post
Black Wire
From Post
Bare, or Green
Ground Wire Bare, or Green
Fixture Ground Wire
From Post
White or
Ribbed Side
From Fixture
From Fixture
Black or
Smooth Side
BB
Hardware Used
BB x 3
Wire
Connector
Post
Post Fitter
C
Lowes.com/portfolio
5
Hardware Used
AA x 3
Mounting
Screw
AA
B
4. Thread the beaded end of the center stem (B)
into the mounting hole on the top center of the
junction box in the fixture body (C). Hand tighten
until snug.
I
4
ASSEMBLY INSTRUCTIONS
C
3. Coat the top 1 in. of the post with clear silicone
caulk (not supplied) and position the post fitter
on the fixture body (C) onto the post. Be sure to
seat it completely, aligning the holes in the fitter
with the 1/16 in. pilot holes drilled into the post.
Secure the fixture to post with 3 mounting screws (AA).
3
Post
Mounting
Hole
Mounting
Hole
Post Fitter
C
Lowes.com/portfolio
Hardware Used
x 1
x 1
CC
DD
CC
Washer
DD Finial
5Bulb
5. Install (2) 60-watt max. candelabra-base incandescent
bulbs or use (2) 13-watt max. spring self-ballasted
candelabra-base CFLs (none included).
A
B
C
6
6
ASSEMBLY INSTRUCTIONS
6.
Place the fixture hood assembly (A) over the top
end of the center stem (B), attach to the top edge
of the fixture body (C). Pass the washer (CC) over
the center stem (B) and secure with the finial (DD).
Hand tighten until snug.
Lowes.com/portfolio
7
CARE AND MAINTENANCE
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives
to clean fixture as they may damage the finish.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Bulbs will not light. 1. Bulb is burned out.
2. Power is off.
3. Faulty wire connection.
4. Faulty switch.
1. Replace light bulb.
2. Make sure power supply is on.
3. Check wiring.
4. Test or replace the switch.
Fuse blows or the
circuit breaker trips
when light is turned
on.
1. Crossed wires or power wire is
grounding out. 1. Check wire connection.
WARRANTY
The manufacturer warrants all of its lighting fixtures against defects in materials and workmanship for
one (1) year from the date of purchase. If within this period the product is found to be defective in
material or workmanship, the product must be returned, with a copy of the original sales receipt as
proof of purchase in the original carton, to the place of purchase. The manufacturer will, at its option,
repair, replace or refund the original purchase price to the consumer. This warranty does not cover
fixtures becoming defective due to misuse, accidental damage, improper handling and/or installation
and specifically excludes liability for direct, incidental or consequential damages. As some states do
no allow exclusions or limitations on an implied warranty, the above exclusions and limitations may
not apply to you. This warranty gives you specific legal rights. You may have other rights that vary
from state to state.
BB
K
J
I
Lowes.com/portfolio
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST,
Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday.
8
PART DESCRIPTION PART #
DD Finial
EE Candle Cover
II
M2227CCK
M2221FIK DD
EE
Printed in China
2015-01-12 Lowes.com/portfolio
Portfolio ® is a registered
trademark of LF, LLC.All
Rights Reserved.
9
MODÈLE N°
LWS1204E
ARTICLE N
°
0338654
LAMPADAIRE
Portfolio® est une marque déposée de
LF, LLC. Tous droits réservés.
Des questions, des problèmes, des pièces manquantes? Avant de retourner l'article à
votre détaillant, appelez notre service à la clientèle au 1 800 643-0067, entre 8 h et 18 h
(HNE), du lundi au jeudi, ou entre 8 h et 17 h (HNE), le vendredi.
JOINDRE LE REÇU ICI
Numéro de série Date d’achat
Lowes.com/portfolio
A
B Tige centrale
Ensemble de boîtier
de luminaire 1
1
C Corps du luminaire 1
CONTENU DE L'EMBALLAGE
10
PIÈCE DESCRIPTION QUANTITÉ
B
A
B
C
B
B
Lowes.com/portfolio
