8
BATTERY CHARGING
E
N8417pr-0920
Use the charger in dry locations only.
ELECTRICAL HAZARD
Important Notes
• Your new battery must be charged for at least 18 hours before
you use it in your vehicle for the first time.
• We recommend that you start charging your battery before
beginning assembly of your new vehicle.
• The battery must be upright while charging.
• The charger is not a toy.
• Do not short circuit the battery.
• You do not need to remove the battery from your vehicle to
recharge it.
• Before charging the battery, examine the battery case for
cracks and other damage which may cause sulfuric acid
(electrolyte) to leak during the charging process. If damage is
detected, do not charge the battery or use it in your vehicle.
Battery acid is very corrosive and can cause severe damage to
surfaces it contacts.
• Do not charge the battery on a surface (such as a kitchen
counter top) which could be damaged by the acid contained
inside the battery. Take precautions to protect the surface on
which you charge your battery.
• Use only a Power Wheels®12 volt charger with "12V"
connector (input 120 VAC, 60 Hz with an output of 12 VDC,
1200 mA) to charge your Power Wheels®12 volt battery.
Adults Note: Regularly examine the charger for damage to the
cord, plug, housing or other parts that may result in the risk of
fire, electric shock or injury. In the event of any damage, do not
use the charger until the damage has been properly repaired.
Please call 1-800-348-0751.
• If your battery is old and will not accept a charge, do not
leave it in the vehicle. Always remove a dead battery from
the vehicle.
About Thermal Fuses
Your Power Wheels®12 volt battery is equipped with a built-in
thermal fuse. The thermal fuse is a self-resetting safety device
which automatically “trips” and shuts down operation of the
vehicle if the vehicle is overloaded or the driving conditions too
severe. Once a fuse has “tripped”, remove your foot from the
pedal and wait approximately 25 seconds before operating the
vehicle again. To avoid repeated automatic shut-downs, do not
overload the vehicle by exceeding the 130 lbs (59 kg) maximum
weight capacity or by towing anything behind the vehicle. Avoid
severe driving conditions, such as driving up slopes or running
into fixed objects, which can cause the wheels to stop spinning
while power is still being supplied to the motors and make sure
your child stops the vehicle before switching speeds or direction.
If a thermal fuse in a battery continually trips under normal
driving conditions, please contact your local Power Wheels®
Authorized Service Center. For the location of the Authorized
Service Center nearest to you, visit us on-line at
www.powerwheels.com, or call 1-800-348-0751.
• Battery can fall out and injure a child
if vehicle tips over. Always use battery
retainer.
• PREVENT FIRE
- Never modify the electrical system.
Alterations could cause a fire resulting
in serious injury and could also ruin the
electrical system.
- Use of the wrong type battery or charger
could cause a fire or explosion resulting
in serious injury.
- Use of Power Wheels®components in
products other than Power Wheels®
vehicles could cause overheating, fire
or explosion.
• The battery must be handled by adults
only. The battery is heavy and contains
sulfuric acid (electrolyte). Dropping the
battery could result in serious injury.
• Never allow children to charge the battery.
Battery charging must be done by adults
only. A child could be injured by the elec-
tricity involved in charging the battery.
• Read the safety instructions on the battery.
• Examine the battery, charger and their
connectors for excessive wear or damage
each time you charge the battery. If
damage or excessive wear is detected, do
not use the charger or the battery until you
have replaced the worn or damaged part.
WARNING CAUTION
