PowerWalker VFI 1000RT LCD Bedienungsanleitung

On-Line UPS

PowerWalker VFI 1000RT LCD

PowerWalker VFI 1500RT LCD

PowerWalker VFI 2000RT LCD

PowerWalker VFI 3000RT LCD

Manual

EN, DE, FR

CONTENT

USER MANUAL....................................Fehler! Textmarke nicht definiert.

1. Safety and EMC Instructions............................................................1

1.1 Installation ..........................................................................................1

1.2 Operation............................................................................................9

1.3 Maintenance, servicing and faults....................................................10

1.4 Transport..........................................................................................13

1.5 Storage.............................................................................................13

1.6 Standards.........................................................................................14

2. Description of Commonly Used Symbols.....................................15

3. Introduction ......................................................................................16

4. Panel Description.............................................................................17

5. Connection and Operation..............................................................19

5.1 Inspection.........................................................................................19

5.2 Connection.......................................................................................19

5.3 Battery charge..................................................................................21

5.4 Turn on the UPS...............................................................................21

5.5 Test function.....................................................................................21

5.6 Turn off the UPS...............................................................................22

5.7 Audible alarm mute function.............................................................22

5.8 Operation procedure of external battery for long backup time model

(“S” model) .............................................................................................22

6. Operating Mode for All Models.......................................................24

6.1 Line mode.........................................................................................24

6.2 Battery mode....................................................................................25

6.3 Bypass mode....................................................................................25

6.4 NO output mode...............................................................................26

6.5 EPO (Emergency Power Off)...........................................................26

6.6 ECO mode (Economy mode)...........................................................26

6.7 Converter mode................................................................................27

6.8 Abnormal mode................................................................................27

7. Setting by LCD Module....................................................................28

8. Trouble Shooting..............................................................................30

9. Maintenance......................................................................................32

9.1 Operation..........................................................................................32

9.2 Storage.............................................................................................32

9.3 Battery Replace................................................................................32

10. Technical Data................................................................................33

10.1 Electrical specifications..................................................................33

10.2 Operating Environment..................................................................33

10.3 Typical backup time (Typical values at 25°C in minutes:).................33

10.4 Dimensions and weights..................................................................34

11. Communication Port......................................................................35

11.1 RS-232 and USB communication ports.........................................35

11.2 RS-232 port....................................................................................35

11.3 USB port.........................................................................................36

11.4 Installing a Serial Network Management Card (optional)..............36

11.5 Dry Contact port...........................................................................36

12. Software Installation......................................................................38

Appendix: Rear panel ..........................................................................39

1. Safety and EMC Instructions

SAVE THESE INSTRUCTIONS – This manual contains important instructions for

models PowerWalker VFI 1000/1500/2000/3000RT LCD that should be followed

during installation and maintenance of the UPS and batteries.

1.1 Installation

•This product is specially designed for PCs and it is not recommended for use

in any life-supporting system and other specific important equipment.

•Do not connect household or other appliances or items of equipment which

would overload the UPS (e.g. laser printers, hair dryers, etc) to the UPS

output.

•This unit intended for installation in a controlled environment (temperature

controlled, indoor area free of conductive contaminants).

•Condensation may occur if the UPS is moved directly from a cold to a warm

environment. The UPS must be absolutely dry before being installed. Please

allow an acclimatization time of at least two hours.

•Risk of electric shock, do not remove cover. No user serviceable parts inside.

Refer servicing to qualified service personnel.

•The utility power outlet shall be near the equipment and easily accessible. To

isolate UPS from AC input, remove the plug from the utility power outlet.

•If UPS is to be stored for a long time, it is recommended to recharge the

batteries (by connecting the utility power to UPS, switch “ON”), once a month

for 24 hours to avoid a full battery discharge.

•Please do not use the UPS in excess of the rated load capacity.

•The UPS contains large-capacity batteries. So the shell shall not be opened,

otherwise such dangers as electric shock will be caused. If any internal

overhaul or replacement of the battery is required, please contact the

distributor.

•The internal short circuiting of the UPS will lead to dangers such as electric

shock or fire, therefore, no water containers (such as a water glass) shall be

placed on the top of the UPS so as to avoid such dangers as electric shock.

•Do not dispose of battery or batteries in a fire. The battery may explode.

Please read carefully the following user manual and the safety

instructions before installing the unit or using the unit!

•Do not open or mutilate the battery or batteries. Released electrolyte is

harmful to the skin and eyes. It may be toxic.

•Icon Φon the rating label stands for phase symbol.

•A battery can present a risk of electrical shock and high short circuit current.

The following precautions should be observed when working on batteries :

•Remove watches, rings, or other metal objects from the hand.

•Use tools with insulated handles.

•Servicing of batteries should be performed or supervised by personnel

knowledgeable of batteries and the required precautions. Keep

unauthorized personnel away from batteries.

•When replacing batteries, replace with the same type and number of the

sealed lead-acid batteries.

•This pluggable type A equipment with battery already installed by the supplier

is operator installable and may be operated by laymen.

•During the installation of this equipment it should be assured that the sum of

the leakage currents of the UPS and the connected loads does not exceed

3.5mA.

•Attention, hazardous through electric shock. Also with disconnection of this

unit from the mains, hazardous voltage still may be accessible through supply

from battery. The battery supply should be therefore disconnected in the plus

and minus pole of the battery when maintenance or service work inside the

UPS is necessary.

•The mains socket outlet that supplies the UPS shall be installed near the UPS

and shall be easily accessible.

•Place cables in such a way that no one can step on or trip over them.

•Assure to connect the UPS and external battery pack with the earth reliably

•Do not block ventilation openings in the UPS´s housing. Ensure the air vents

on the front and rear of the UPS are not blocked. Allow at least 25cm of space

on each side.

•In case smoke is found coming out from the device, please cut off the power

supply quickly and contact the distributor.

•An appropriate disconnect device as short-circuit backup protection should be

provided in the building wiring installation. Please see the disconnect device

specification in chapter 5.2

•Do not keep or use this product in any of the following environments:

oAny area with combustible gas, corrosive substance, heavy dust,

standing water or running water.

oAny area with extraordinarily high or low temperature (above 40˚C or

below 0˚C) and humidity of more than 90%.

oAny area exposed to direct sunshine or near any heating apparatus.

(Maximum ambient temperature rating is 40°C.)

oAny area with serious vibrations.

oOutdoor.

•In the event that there is fire occurring in the vicinity, please use dry-power

extinguishers. The use of liquid extinguishers may give rise to the danger of

electric shock.

★

1.1.1 Inspection of Unit

Inspect the UPS upon receiving. If the UPS is apparently damaged during the

shipment, please keep the box and packing material in original form for the

carrier and notify the carrier and dealer immediately.

1.1.2 Unpacking the Cabinet

To unpack the system:

1. Open the outer carton and remove the accessories packaged with the

cabinet.

2. Carefully lift the cabinet out of the outer carton and set it on a flat, stable

surface.

3. Discard or recycle the packaging in a responsible manner, or store it for

future use.

1.1.3 UPS Setup

All model series are designed for tower and rack purpose. They can be

installed into a 19 inches equipment rack. Please follow the instruction for

Tower Setup and Rack-Mount Setup.

Tower setup

This series of UPS can be placed horizontally and vertically. As a tower

configuration, it is provided with the optional UPS stands to stabilize the UPS

when the UPS is positioned in vertical. The UPS stand must be attached to the

bottom of the tower. Use the following procedure to install UPS in UPS stands.

1. Slide down the UPS vertically and put two UPS stands at the end of the tower.

2. Place down the UPS into two stands carefully.

3. Pull out the LCD box and rotate it in a clockwise direction to 90 degree and then

push it back in the front panel.

Rack-mount setup

The series can be installed in 19 inches racks. Both the UPS and external battery

enclosure need 2U of rack space.

Use the following procedure to install UPS in a rack.

1. Align the mounting ears with screw holes on the side of the UPS, and tighten

the screw.

2. Assemble the rack rails with the rack-mounting.

3. Slide in the UPS into the rack rail and lock it in the Rack-mounting.

4. Tighten the screw, and then the load can be connected.

1.1.4 EBM Installation (Optional)

Connecting the EBM in Tower form:

1. Slide down the UPS and EBM vertically and place two UPS stands with the

extend part at the end of the tower.

2. Tighten the screw on the metal sheet for stabilization

3. Connect the Earth line from UPS (port A ) to EBM (port B)

4. Take off the front panel, and connect the battery terminal (A) from UPS to

EBM terminal (B) shown as below. Users need to remove the small gate(C)

on side of the front panel to allow the outlet wire of the EBM to pass through

the gate and then reassemble front panel.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere PowerWalker UPS Handbücher

PowerWalker

PowerWalker VFI 6000CRM LCD Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000CRM LCD Bedienungsanleitung

PowerWalker

PowerWalker 1000 LCD/UK Bedienungsanleitung

PowerWalker

PowerWalker VI 500T/HID Bedienungsanleitung

PowerWalker

PowerWalker VFD 400 Bedienungsanleitung

PowerWalker

PowerWalker VFI 20000-40000TAP 3/3 BI Bedienungsanleitung

PowerWalker

PowerWalker VI 1000 Bedienungsanleitung

PowerWalker

PowerWalker VFI 10000CRM LCD Bedienungsanleitung

PowerWalker

PowerWalker VI 1200 RLE Bedienungsanleitung

PowerWalker

PowerWalker VI 3000RT LCD Bedienungsanleitung

PowerWalker

PowerWalker VFI 6000 CG PF1 Installations- und Betriebshandbuch

PowerWalker

PowerWalker VI 2000 LCD Bedienungsanleitung

PowerWalker

PowerWalker VI RT HID Series Bedienungsanleitung

PowerWalker

PowerWalker VFI 10000CP 3/3 Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000 CRM Bedienungsanleitung

PowerWalker

PowerWalker VFD 600 APFC Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000 Bedienungsanleitung

PowerWalker

PowerWalker VI THID Series Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000 LCD Bedienungsanleitung

PowerWalker

PowerWalker VI 400 SC Bedienungsanleitung

PowerWalker

PowerWalker Basic VI SB Series Bedienungsanleitung

PowerWalker

PowerWalker VFI ICT IoT Series Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000 R1U Bedienungsanleitung

PowerWalker

PowerWalker VI 400 Bedienungsanleitung

Beliebte UPS Handbücher anderer Marken

Pylontech

Pylontech Victron & Pylontech US5000 Bedienungsanleitung

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Bedienungsanleitung

Mecer

Mecer ME-1000-WTU Bedienungsanleitung

Mustek

Mustek PowerMust 530(B) Plus Installations- und Betriebshandbuch

Emerson

Emerson Liebert NXL series Bedienungsanleitung

MAKELSAN

MAKELSAN BOXER SERIES Bedienungsanleitung

Block

Block PC-0524-400-0 Bedienungsanleitung

CyberPower

CyberPower CP585LCD Bedienungsanleitung

Eaton

Eaton 3S Montageanleitung

CyberPower

CyberPower Office Tower Series UPS 1000 Bedienungsanleitung

CyberPower

CyberPower BM100 Bedienungsanleitung

Best Power

Best Power 610 Bedienungsanleitung

Best Power

Best Power Unity/I UT3K Bedienungsanleitung

Mustek

Mustek PowerMust 400 Offline Bedienungsanleitung

Xantrex

Xantrex Trace 512 UR-UPS Bedienungsanleitung

Forza

Forza SL-1501UL Bedienungsanleitung

LEGRAND

LEGRAND keor 310081 Bedienungsanleitung

ABB

ABB Conceptpower DPA 500 Bedienungsanleitung
