Powerx Electric Bedienungsanleitung
Water Heater
Electric
WELCOME TO THE POWERX FAMILY
Join us on our mission to save energy, water and the planet.
community.powerx.co
Table of Contents
What’s included
Installation guide
1. Download the PowerX App & connect Hub
2. Connect to Wifi & add PowerX Water Heater
3. Prepare installation of PowerX Water Heater
4. Mount PowerX Water Heater - Electric
5. Attach sensors
6. Turn circuit breaker back on
7. Add water leak detection cable (optional)
Connectors
Product specifications
Disclaimer
PowerX Suite
4
5
6
8
11
14
16
17
18
19
21
22
WARNING
3
PowerX Water Heater - Electric connects to high voltage
outputs. Improper use or installation can be dangerous
or even fatal. Please be careful and follow these
guidelines:
1. PowerX Water Heater - Electric should be installed by
a qualified professional.
2. Personal protective equipment should be worn when
installing PowerX Water Heater - Electric. Using or
installing PowerX Water Heater - Electric in an
unspecified manner can impair protective equipment.
3. Do not open the PowerX unit or attempt to repair it. If
there is an issue please contact our customer service
team.
4. If you believe the PowerX unit is damaged, do not use
them and instead contact our customer support team at
5. The PowerX unit was designed for the United States
and Canada. Use PowerX Water Heater - Electric only
with a 60Hz 120V/240V system. Never use PowerX with
heaters that draw more than 5,000 Watt.
6. Install PowerX Water Heater - Electric where it will not
be exposed to direct sunlight or extremely low or high
temperatures.
PowerX Water Heater - Electric USB wall adapter
and power cable
Ground washer
and screw
2 Washers 3 Zip Ties
PowerX Hub
Set of temperature sensors
(Black, Blue, and Red)
Water leak
detection cable
Optional
Water Heater
4
What’s included
1.1 Plug in the PowerX Hub
Download the PowerX App & connect Hub
1
Download and open the PowerX
App from your device’s app store
and follow the on-screen
instructions.
Scan your PowerX Hub’s QR code,
or type in the Hub’s ID manually.
You can find the Hub’s ID on the
bottom of the unit.
1.2 Download the PowerX App
1.3 Scan Hub’s QR code
5
PowerX Water
Get the PowerX App
www.powerx.co/app
CALIBRATION
COMPLETE
PowerX Water
Scan QR code
SCAN QR CODE
Enter code Validate
Connect the PowerX Hub to the wall
adapter and cable, and plug it in an
electrical outlet.
The Hub’s LED light will start to blink.
CALIBRATION
COMPLETE
PowerX Water
Select Wifi network
Wi-Fi 1
Home internet
Wi-Fi 2 Successfully added Hub
Water Heater
2.1 Connect to Wifi
Choose your local Wifi network,
select “Connect”, and enter your
Wifi credentials.
Your device is successfully
connected if you see the message
“Successfully added Hub” in the
mobile app, and the blinking blue
light on the device changes to
remain ON steadily.
2.2 Add PowerX Water Heater
Connect to Wifi and add PowerX Water Heater
2
6
CALIBRATION
COMPLETE
PowerX Water
Scan QR code
SCAN QR CODE
Enter code Validate
If you need further help please go to help.powerx.co
ADD DEVICE
In the PowerX App select
“Add device”.
Then scan the QR code on
the bottom of the PowerX
Water Heater - Electric
sensor or type in the sensor’s
ID manually.
Step by step guide to installing
PowerX Water Heater - Electric
8
Turn the main breaker in your
electric panel OFF, this will turn o
all electric circuits in your home.
3
3.1 Breaker OFF
Prepare installation of PowerX Water Heater - Electric
9
WARNING: Always treat
line wires as if they were
live and use appropriate
protective equipment.
Remove the junction box cover. This
box is usually on the top of the
water heater, and normally requires
unscrewing only one or two screws.
There will be two wires coming out
of the water heater, one black and
one red or white.
Prepare installation of PowerX Water Heater - Electric
3
3.2 Open junction box of electric heater
Open both covers from the
junction box and remove the
wire nuts.
Release the ground wire,
and unscrew and remove
the conduit nut.
3.3 Unscrew conduit nut
