Precaster HT60 Bedienungsanleitung

LASER DISTANCE METER

HT60

Operation Manual

NEW BENCHMARK OF MEASURING

www.precaster.com.twHT60 Operation Manual

. Safety Information

1. This is a Class 2 laser tool, laser radiation is emitted from this product and is manufactured to comply IEC

60825-1: 2007, EN 60825-1:2007, EN 61326-1:2013 and CRF21, parts 1040.10 and 1040.11.

2. Use of controls, adjustment procedures other than those specified herein may result in laser radiation

exposure.

3. Never stare directly into beam or aim the laser beams at others.

4. Product contains semiconductor laser diodes with wavelengths of 650 nanometers.

5. The total continuous output of the beams never exceeds 1.0 milli-watts.

6. Product complies with EMC Test according to EN61000-6-3:2001+A11:2004, EN61000-6-1:2001,

EN61326-1:2013, IEC 61326:2012 and FCC Test according to PART 15.

7. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined

by turning the equipment oﬀ and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit diﬀerent from that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

8. This device complies with Industry Canada license-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause interference,

and (2) this device must accept any interference, including interference that may cause undesired

operation of the device.

Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio

exempts de licence. L'exploitation est autorisee aux deux conditions suivantes : (1) l'appareil ne

doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage

radioelectrique subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement.

NEW BENCHMARK OF MEASURING

FCC ID: YWSLB11310CA01

IC ID: 20299-LB11310CA01 HVIN:1.1

. Inside The Box

∙ HT60 Laser Distance Meter x1 ∙ AAA Battery x2 ∙ Operation Manual x1

∙ Carrying Case x1 ∙ Safety Strap x1

. Specification

∙ Measuring Range

∙ Resolution

∙ Accuracy

∙ Measuring Speed

∙ Laser Type

∙ Beam Size

∙ Battery

∙ Dimension

∙ Operation Temperature

∙ Storage Temperature

∙ Automatic Power-Oﬀ

0.05m- 60m

0.001m

±1.5mm

0.5sec

650nm, Class II, <1mW

25mm@15m

AAA Battery x2, Up to 10,000 measures

105x48x21mm

-5°C~40°C

-20°C~60°C

-Laser 30 Seconds -Device 180 Seconds

. Error Code

Err01

Err02

Err03

Out of measuring range Measuring in a proper range

Reflected signal is too weak

Pythagorean calculation error

Low Battery

Out of working temperature

Ambient light is too strong

Check and verify values and

steps are correct

Install a new battery

Measure in an environment

within specified working

temperature

Measure in a darker place

(shadow target)

Select a better surface

Out of display range (Max Value:

99999), e.g: result of area or

dimension is out of display range.

Divide caculation into

intermediate steps

Err04

Err05

Err06

Err07

Code Description Solution

WWW.PRECASTER.COM.TW

HT60 OPERATION MANUAL

. Overview for HT60

. Overview for Screen

HT-60

∙ LCD

∙ Clear / Power

∙ Addition /

Subtraction

∙ Functions / Units

-Area

-Volume

-Indirect Measure

I, II, III

-Stake Out Setup

∙ Measure

∙ Measurement Records

∙ Reference / Bluetooth

∙ Laser Emitted Window

∙ Laser Receiving Window

1. Measuring Reference

2. Measuring Function

3. Memories

4. Laser Indicator

5. Add and Subtract

6. Maxmum Display

7. Indirect Measuring

8. Minimum Display

9. Stakes Direction Indicator

10. Main Screen and Units

11. Countdown Measuring

12. Bluetooth Indicator

13. Battery Status

14. Sub-Screen and Units

2 3 11 12

. Battery Installation & Power Status

1. This unit is powered by 2 x AAA Batteries.

2. Remove battery lid and observing correct polarity before install batteries.

3. Battery level is showed on screen with batty icon on screen .

4. When the icon appears, there are approximately 1000 times to measure.

NEW BENCHMARK OF MEASURING

5. Replace batteries when low battery icon flash on screen.

6. To change new batteries, when install new batteries, then close back lid.

Single Measurement Mode

1. Move the laser dot onto the target.

2. Keep your position stable and click .

3. The measurement will be displayed on LCD Screen and laser will be turn oﬀ.

4. Click again to enable the laser dot for next measurement.

Continuous Measurement Mode

1. Continuous Measurement is also called tracking measurement and is recommend to use for seeking proper

distance.

2. Move the laser dot onto the target.

3. Keep your position stable and tap and hold , the laser distance meter will enter continuous

measurement mode.

4. Move the device back and forward to proper distance.

5. Click to pause the measurement.

6. Click again to leave the continuously measurement mode.

. Switch On and Oﬀ

1. Be sure to check battery status before start.

2. Click the or to turn on the device.

3. Device will process the initial procedure and get ready to measure by turn on the laser dot.

4. Tap and hold for 2 seconds to turn oﬀ.

5. The device will turn oﬀ automatically aer 180 seconds.

. Distance Measurement

. Measurement Reference

1. There are two reference positions for measurement .

They are back of the unit, front of the unit, tripod thread and the spike

2. Click to select the proper position.

WWW.PRECASTER.COM.TW

HT60 OPERATION MANUAL

1. To make summary or diﬀerence between two measurements is easy

2. Finish your first measure, than click to save as addend or hold to save as Minuend.

3. Take the second measurement, than click to add from addend or hold to subtract minuend.

. Measuring Functions

Area Measurement

1. Click to enable Area measurement.

2. Laser will be activated when entering area measurement mode.

3. Follow the instructions on main screen to measure WIDTH and LENGTH.

4. Aer finish all the instructions, the result [AREA] will be showed on screen.

2. Volume Measurement

1. Click twice to enable Volume measurement.

2. Laser will be activated when entering volume measurement mode.

3. Follow the instructions on main screen to measure WIDTH, LENGTH and HEIGHT.

4. Aer finish all the instructions, the result [VOLUME] will be showed on screen.

. Measurement Addition & Subtraction

meter

Length

Area

Volume

m²

m³



²

³

²

³

0’0”1/32

²

³

1/32in

²

³

1/16in

²

³

1/8in

²

³

10/33

m³

feet inch inch inch inch 尺0’0”1/32

. Unit Setting

1. There are 8 units inside the laser distance meter.

2. Click and hold to select preferred unit.

3. Unit Switch Reference

NEW BENCHMARK OF MEASURING

3. Indirectly Height I, II & III Measurement (base on Pythagorean)

1. Click thrice, four and five times to enable Indirectly Measurement.

2. Laser will be activated when entering indirectly measurement mode.

3. Follow the instructions on main screen to measure the LENGTH OF HYPOTENUSE(S) and BASE.

4. Aer finish all the instructions, the result [HEIGHT] will be showed on screen.

Indirect

Measure I Indirect

Measure II Indirect

Measure III

. iM² app & Bluetooth Setup

For the model supported Bluetooth could connected with phones support BLE4.0,

For Bluetooth version on your phone, please contact with your phone manufacturer.

We currently oﬀer Measurement Kit on iTune and Play Store.

1. To turn on Bluetooth in pairing mode, press and hold .

2. The Bluetooth icon will keep flashing during paring.

3. Select proper device in the Connection Manager of APP

4. Aer connected with a beep sound the icon will stop flashing.

Pairing Connected

. Store Measurement to Memory and Lookup

1. When you want to add the measurements on the screen, press to add to memory.

You could find the location in memory on the top of screen.

2. To lookup stored measurements, press and hold to enter the lookup mode.

3. Press to move the index up and hold to move index down.

4. To clear all stored measurements, press and hold again in lookup mode to clear all memory.

WWW.PRECASTER.COM.TW

HT60 OPERATION MANUAL

NEW BENCHMARK OF MEASURING

www.precaster.com.twHT60 Operation Manual

Precaster Enterprises CO., LTD. Made in Taiwan

. Service Support

Please contact your local dealer or contact us through servise email :

[ reps@precaster.com.tw ] for further assistance.

. FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired

operation.
