PROAIM VCTR-LT-HAP Bedienungsanleitung

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Height Adjustable Telescopic Poles for Victor

Lite Carts (VCTR-LT-HAP)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

4 x Height Adjustable Telescopic Poles

Assemb ly Manua l

• Now, remove the top shelf by liing it

upwards.

NOTE: Two people are required to detach the

top shelf from the foldable rods.

• Aer removing the top shelf, loosen and

remove the bolts and washers of the rod on

the boom shelf.

• Aer removing the bolts from the Foldable

Rod, loosen the locking knobs from both

sides, as shown in the image.

• All rods from the Victor Lite Cart

(Not Included) have been removed.

• Loosen and remove the bolts of the

Adjustable Telescopic Poles.

Telescopic Poles Setup

• Remove the locking knobs at all corners of

the top shelf of the Victor Lite Cart

(Not Included) by loosening them.

• Now, remove the Foldable Rod from the

boom shelf.

• Similarly, follow the same steps to remove

the remaining rods.

• Aer aaching to Pole, insert the bolt, as

shown in the image.

• Aer inserng the bolt, ghten it using the

Allen key and wrench.

• Detach the Locking knobs, as shown in the

image.

• Remove the upper knob xed in the

adjustable pole by loosening it.

• Follow the same process to remove bolts

from the remaining Adjustable Telescopic

Poles.

• Aach the Adjustable Telescopic Pole to the

boom shelf of the Victor Lite cart.

• Insert the locking knob in the provided hole

of the adjustable Pole and insert the second

knob from outside, as shown in the image.

• Tighten the knobs to secure the

aachment.

• Aer inserng the knobs, ghten them to

secure the Pole at your desired height.

• Similarly, secure the remaining Poles at the

desired height and ghten their knobs, as

shown in the image.

• Mount the top shelf of the Victor cart on

the rod.

• Insert the Locking knobs on all corners of

the top shelf.

Features: The height of the top shelf can be

adjusted from 2.46 feet / 29.6" to 1.67 feet /

20.1"

• The locking knobs are properly aached all

to four corners of the cart's top shelf.

Feature: The aluminum Poles easily lock into

place at the desired height range, ensuring

longevity and ease of use.

• Adjust the height of the adjustable Pole per

your requirement and insert the locking

knob in the Pole to x the Pole.

NOTE: The adjustable poles extend the height

and range of operaon of the Victor Lite Cart.

Height Range- 2.46 / 29.6” To 1.67 / 20.1”

YOUR PROAIM HEIGHT ADJUSTABLE POLES FOR VICTOR LITE CARTS

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.
