PROAIM RCSW-CNBD-01 Bedienungsanleitung
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Cinebird Camera Rickshaw Dolly Support (RCSW-CNBD-01)
3 x T-Type Allen key
(5mm, 5/16mm, 6mm)
Seat rod
2 x Jockey Wheels
2 x Side support Extension
Cheese Plate
Handle Frame
2 x 21’’ Wheels
Seat
2 x Foot rest & Ratchet
2 x Handle Clamps
2 x Wheel Brackets
2 x Foot rest
Brackets
Jockey Wheel Bracket
2
Handle Frame
Easy of Movement handling
21’’ Wheels
with 360° Rotaon with Break
Easy Maneuvering & Stability
Jockey Wheel
Bracket
Safety & locking
system
Footrests & Ratchet
Comfortable Long
Hour Shoong
Side support Extension
Handle aached with handle clamp
Jockey Wheels
Jockey Wheels For Easy
Maneuvering & Stability
Handle Clamps
Safety & locking
system
Cheese Plate
Adapts Mul-Mounng
Accessories Cheese Plate
with Mitchell Mount
Wheel Brackets
Three height adjustment
points, 5", 6" & 7"
Seat
Adjustable seat and rotates 360°
Foot rest Brackets
Adjustable Footrest with ratchet
Features of Rickshaw Dolly
3
• Remove the seat mount adapter, mounted on
the cheese plate, with the help of the Allen
key, as shown in the image.
Cinebird Camera Rickshaw Dolly Setup
• Mulple threads are provided on the Cheese
Plate. Adjust and mount your seat adaptor
anywhere on the plaorm as per your needs.
• Aer inserng the bolt, secure it by properly
by re-ghtening it with the help of the Allen
key.
• Properly remove the bolt from the Jockey
Wheel Bracket using the 5/16mm Allen key.
• Insert the bolts from the boom of the
Cheese Plate and properly secure them using
the Allen key, as shown in the image.
• Then place the Jockey Wheel Bracket by
matching it with the thread hole of the
Cheese Plate.
4
• Manually pull up the ratchet knob present on
the Jockey Wheel bracket.
• Match the jockey wheel brackets hole and
then insert the jockey wheels, as shown in the
image.
• Match the Jockey Wheel bracket’s hole and
then insert the Jockey Wheels, as shown in
the image.
• The foot rest bracket is properly aached to
the Cheese Plate.
• Aer inserng the Jockey Wheels knob,
properly ghten it with the Allen key.
• To stabilize the 360° movement of the Jockey
Wheels, properly insert the ratchet knob of
the Jockey Wheel bracket and then secure it.
5
• Jockey Wheel bracket is properly aached to
the Jockey Wheels.
• Remove the bolts of the Handle Clamps using
the Allen key.
• Place the Clamp by matching it to the threads
on the side of the Cheese Plate.
• Tighten the bolts using the Allen key and to
aach the second Handle Clamp, repeat the
same process given above.
• Remove all the bolts aached to the Wheel
Bracket using the Allen key.
• Aer aaching the clamp to the Cheese Plate,
insert the bolts from the boom.
6
• Remove the bolts of the Foot Rest Brackets
using the 5/16mm Allen key.
• Then place the Wheel Bracket by matching it
to the threads on the side of the Cheese
Plate.
• Aer aaching the clamp to the Cheese Plate,
insert the bolts from the boom and ghten
them with the Allen key. To aach the second
Handle Clamp, repeat the same process.
• Place the Foot Rest Bracket to the side of the
Wheel Bracket and then insert the bolt aer
matching it with the hole at the boom of the
Cheese Plate.
• Properly ghten it with the 5/16mm Allen key
and then follow the same process to aach
the second Foot Rest Bracket.
• Manually remove the bolts of the wheel.
7
• Aer aaching the wheel to the wheel
bracket, insert the knob and secure it
properly with the help of the Allen key.
• Follow the same above process to aach the
2nd Wheel.
• Loosen the knob of the Handle Clamp and
open it.
• Place the Handle Frame over the clamp, as
shown in the image.
• Aer placing the Handle Frame over the
handle clamp, secure it properly with the
provided knob of the clamp and then ghten
it.
• Follow the same above process to aach the
2nd Wheel.
NOTE: The pneumac wheels feature three
height adjustment points, 5", 6" & 7", allowing
the setup to adapt the height according to the
rough and bumpy roads.
8
• Similarly, following the same process ghten
it properly with the second clamp's knob.
• Loosen the side bolt of the center rod of the
Handle Frame with the Allen key.
• Then set the center rod posion of the
Handle Frame according to you and then
ghten it properly with the Allen key.
• Handle Frame’s center rod posion is now
properly secured.
• Remove the bolts in the Side Support
Extension using the Allen key.
• Loosen the bolts of the clamp in the Handle
Frame.
9
• Match the thread holes of the Handle Clamp
and Side Support Extension and then insert
the bolts.
• Properly ghten it with the help of the Allen
key and align the Side Extension with the
clamp.
• Aer aligning the Side Extension, insert the
bolt and then properly ghten it with the
Allen key.
• Follow the above same Process for aaching
the second side support extension.
• Loosen the knob of the seat mount adapter,
present on the Cheese Plate and then insert
the rod on the clamp.
• Aer placing the seat rod over the clamp,
properly secure it with the help of the ratchet
knob of the clamp.
10
• Then mount the seat over the seat rod, as
shown in the image.
• Then properly secure the bolt at the boom
of the seat using the Allen key to properly
secure the seat on the seat rod.
• Adjust and properly lock the buckle of the
seat strap and then ghten it, as shown in the
image.
• The Seat rod has a height adjusng feature so
you can easily set your seat up and down.
Lock the seat to your desired posion using
the seat break.
NOTE: The seat is fully adjustable and rotates
360°, you can also mount it anywhere on the
rickshaw plaorm.
• Insert the footrest by aligning it with the Foot
rest Brackets thread. Then, secure it correctly
with the rachet knob, as shown in the picture.
• Follow the above same process for aaching
another side Foot rest.
