Progress Lighting Airpro P250073 Bedienungsanleitung

P250073

93153464_A

Limited Lifetime Warranty

Date Purchased

Store Purchased

UL Model No.

Serial No.

Vendor No.

UPC

111017

P250073

Progress Lighting fan motors are warranted to the original purchaser to be free of electrical and/or mechanical

defects for so long as the original purchaser owns the fan. Pull chain switches, reverse switches, capacitors and

metal nishes are warranted to be free from defects in materials or workmanship for a period of 1 year from

the date of purchase. Warping of wooden or plastic blades is not covered by this warranty nor is corrosion and/

or deterioration of any nishes for fans installed within ten miles of any sea coast. Extended warranties for

ENERGY STAR® qualied products may apply.

Progress Lighting ceiling fans with built-in LED light sources, when properly installed and under normal

conditions of use, are warranted to be free from defects in material and workmanship which cause the light

sources to fail to operate in accordance with the specications for (i) ve (5) years from the date of purchase

on the LED Light modules and electrical components for fans used in single family residences, and (ii) three

(3) years from the date of purchase on the LED Light modules and electrical components for fans used in

multi-family or commercial applications. LED bulbs supplied by Progress Lighting carry no warranty other

than manufacturer’s warranty. Non-LED bulbs carry no warranty.

With proof of purchase, the original purchaser may return the defective fan to the place of purchase during the

rst 30 days for replacement. After 30 days, the original purchaser MUST contact Progress Lighting at (864)

678-1000 for repair or replacement which shall be determined in Progress Lighting’s sole discretion and shall

be purchaser’s sole and exclusive remedy.

Labor and Shipping Excluded. This warranty does not cover any costs or fees associated with the labor

(including, but not limited to, electrician’s fees) required to install, remove, or replace a fan or any fan parts.

This warranty shall not apply to any loss or damage resulting from (i) normal wear and tear or alteration,

misuse, abuse or neglect, or (ii) improper installation, operation, repair or maintenance by original purchaser

or a third party, including without limitation improper voltage supply or power surge, use of improper parts or

accessories, unauthorized repair (made or attempted) or failure to provide maintenance to the fan.

THE FOREGOING WARRANTIES STATE PROGRESS LIGHTING’S ENTIRE WARRANTY OBLIGATION

AND ORIGINAL PURCHASER’S SOLE AND EXCLUSIVE REMEDY RELATED TO SUCH PRODUCTS.

PROGRESS LIGHTING IS NOT RESPONSIBLE FOR DAMAGES (INCLUDING INDIRECT, SPECIAL,

INCIDENTIAL OR CONSEQUENTIAL), DUE TO PRODUCT FAILURE, WHETHER ARISING OUT OF

BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE. THIS WARRANTY IS GIVEN

IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, INCLUDING THOSE

OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT.

Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitations

of incidental or consequential damages, so the above limitations and exclusions may not apply to you. This

warranty gives you specic rights and you may have other rights which vary from state to state.

785247261000

785247261017

785247261024

Safety Rules

Unpacking Your Fan

Installing Your Fan

Wiring the Fan

Preparing the Remote Control

Operating Your Fan

Care of Your Fan

Troubleshooting

Specications

Table of Contents

1. To reduce the risk of electric shock, insure electricity has been

turned off at the circuit breaker or fuse box before beginning.

2. All wiring must be in accordance with the National Electrical

Code ANSI/NFPA 70-1999 and local electrical codes.

Electrical installation should be performed by a qualied

licensed electrician.

3. CAUTION: To reduce the risk of personal injury, use only the

screws provided with the electrical box.

4. The outlet box and support structure must be securely mounted

and capable of reliably supporting 35 lbs. (15.9 kg). Use only

UL Listed outlet boxes marked “Acceptable for Fan Support of

35 lbs. (15.9 kg) or less.”

5. CAUTION: The fan must be mounted with a minimum of 7

feet clearance from the trailing edge of the blades to the oor.

6. Do not wait for the fan to stop before pressing the reverse

button. The fan will not reverse direction if the fan is not

moving.

7. Avoid placing objects in path of the blades.

8. To avoid personal injury or damage to the fan and other items,

be cautious when working around or cleaning the fan.

9. Do not use water or detergents when cleaning the fan or fan

blades. A dry dust cloth or lightly dampened cloth will be

suitable for most cleaning.

10. After making electrical connections, spliced conductors should

be turned upward and pushed carefully up into electrical box.

The wires should be spread apart with the grounded conductor

and the equipment-grounding conductor on one side of the

electrical box and ungrounded conductor on the other side of

the electrical box.

11. Electrical diagrams are for reference only. Light kits that are

not packed with the fan must be UL Listed and marked suitable

for use with the model fan you are installing. Switches must be

UL General Use Switches. Refer to the instructions packaged

with the light kits and switches for proper assembly.

12. All set screws must be checked and retightened where

necessary before installation.

13. WARNING: To reduce the risk of re or electric shock,

this fan should only be used with fan speed control part

no. DP-5R, manufactured by DAWNSUN ELECTRONIC

TECHNOLOGY CO LTD ZHONGSHAN.

14. Suitable for use in damp locations.

1. Safety Rules

READ AND SAVE THESE INSTRUCTIONS

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL

INJURY, MOUNT TO OUTLET BOX MARKED “ACCEPTABLE FOR FAN

SUPPORT OF 35LBS. (15.9 KG) OR LESS”, AND USE SCREWS PRO-

VIDED WITH THE OUTLET BOX.

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE

BLADE BRACKETS (ALSO REFERRED TO AS (“FLANGES”) DURING

ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN

THE PATH OF THE BLADES.

TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED

WITH AN ISOLATION WALL CONTROL/SWITCH.

a. Blade attachment hardware

(16 screws)

b. Flywheel attachment hardware

(6 screws)

c. Decorative ring attachment hardware

(6 screws)

d. Upper housing attachment hardware

(7 screws)

e. Electrical hardware and Balancing kit

(1 plastic wire connector, blade balancing kit)

7. Upper housing

8. Flywheel

9. Decorative ring

10. Finial

11. Transmitter and Receiver

12. Lead Wire

1. Mounting Bracket (inside canopy)

2. 6” Ball/Downrod Assembly (hanger pin

and locking pin pre-attached)

3. Canopy with Canopy Ring (attached)

4. Decorative Motor Collar Cover

5. Fan Motor Assembly

6. Blades (5)

2. Unpacking Your Fan

Unpack your fan and check the contents. You should have the following items:

a b

2h 4h 8h

3. Installing Your Fan

Tools Required

Phillips screw driver or straight slotted screw

driver, adjustable wrench, step ladder, and

wire cutters.

Mounting Options

If there isn’t an existing electrical box, then

read the following instructions. Disconnect

the power by removing fuses or turning off

circuit breakers.

Secure the electrical box directly to the building

structure. Use appropriate fasteners and

building materials. The electrical box and

its support must be able to fully support the

moving weight of the fan (at least 35 lbs.).

Do not use plastic electrical boxes.

Figures 1, 2, and 3 are examples of different

ways to mount the electrical box.

Note: You may need a longer downrod to

maintain proper blade clearance when

installing on a steep, sloped ceiling.

The maximum angle allowable is 20˚. If the

canopy touches downrod, turn the canopy

180˚ before attaching the canopy to the

mounting plate.

To hang your fan where there is an existing

xture but no ceiling joist, you may need an

installation hanger bar as shown in Figure 4.

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PERSONAL INJURY, MOUNT

TO OUTLET BOX MARKED “ACCEPTABLE

FOR FAN SUPPORT OF 35LBS. (15.9 KG) OR

LESS”, AND USE SCREWS PROVIDED WITH

THE OUTLET BOX. ELECTRICAL BOXES

COMMONLY USED FOR THE SUPPORT

OF LIGHTING FIXTURES MAY NOT BE

ACCEPTABLE FOR FAN SUPPORT AND

MAY NEED TO BE REPLACED. CONSULT A

QUALIFIED ELECTRICIAN IF IN DOUBT.

Figure 1

Figure 2

Figure 4

Figure 3

Attaching the Fan Blades

1. Attach the blades to the ywheel by

aligning the notches on the blades with

alignment post on the ywheel and put

the blade on to the ywheel. Secure with

screws but do not tighten. (Figure 5)

2. Repeat these steps for remaining blades.

3. Put the ywheel upside as shown (Fig.

6). Attach the nial to the bottom of the

ywheel aligning the screw holes of the

nial with the holes of the blade, secure

with screws and tighten. (Figure 6)

4. Securely tighten the screws mentioned is

step 1.

Blade

Screws

Flywheel

Figure 5

Figure 6

Screws

Finial

Figure 7

Screws

Decorative ring

Attaching the Decorative

Ring

1. Attach the decorative ring through the

bottom of the ywheel by aligning the

holes on the decorative ring with the

holes on the tab and install the screws.

(Figure 7)

2. Put the fan motor assembly inside the

ywheel, engage the fan motor assembly

with tabs onto the ywheel by turning

clockwise till the screw holes on the fan

motor assembly align with the holes on

the tab of ywheel.(Figure 8)

3. After aligning the holes on the ywheel

with the holes on the tab, install the

screws. (Figure 9)

4. Put the upper housing on to the fan motor

assembly, then install the screws. (Figure

10)

5. Make sure all the screws are rmly

tightened.

Figure 8

Motor

assembly

Flywheel

Figure 9

Flywheel

Screws

Figure 10

Upper housing

Screws

5. Loosen, but do not remove, the set screws

on the collar on the top of the motor

housing.

6. Align the holes at the bottom of the

downrod with the holes in the collar on

top of the motor housing. (Figure 13 )

7. Carefully insert the hanger pin through

the holes in the collar and downrod. Be

careful not to jam the hanger pin against

the wiring inside the downrod. Insert the

locking pin through the hole near the end

of the bolt until it snaps into its locked

position, as noted in the circle inset of

Figure 13.

8. Re-tighten the set screws on the collar on

top of the motor housing.

9. Make sure the grommet is properly

installed in the collar cover, then slide

the collar cover on the downrod until it

rests on the motor housing. Be sure that

the canopy and the collar cover are both

oriented correctly.

10. Proceed to “Installing the Fan” section.

Figure 11

Figure 12

Hanging the Fan

REMEMBER to turn off the power. Follow

the steps below to hang your fan properly.

NOTE: This fan is recommended for

standard ceiling mount using the downrod

provided with this fan. When using standard

ceiling fan installation with the 6 inch

downrod provided, the distance from the

ceiling to the bottom of the fan blades will be

approximately 14 inches.

Standard Ceiling Mounting

1. Remove the canopy ring from the canopy

by turning the ring to the right until it

unlocks. (Figure 11)

2. Remove the mounting plate from the

canopy by loosening the four screws on

the top of the canopy. Remove the two

non-slotted screws and loosen the slotted

screws. This will enable you to remove

the mounting plate. (Figure 12)

3. Remove the hanger pin and locking pin

from downrod assembly.

4. Place downrod over canopy and canopy

ring, slide the motor collar cover onto

the downrod. Connect the extension lead

wires to the lead wires from motor. Make

sure the quick connectors are clasped

rmly. Route the wires through the ball/

downrod assembly. (Figure 13)

FAILURE TO PROPERLY INSTALL SET SCREWS

AS NOTED IN STEP 8 COULD RESULT IN FAN

LOOSENING AND POSSIBLY FALLING.

Turn Canopy to Remove

Remove

Loosen but Do Not Remove

Figure 13

Motor collar

Pin in locked

position

Locking pin

Tighten

screws

Hanger pin

Motor collar

cover

Canopy

ring

Lead wires

all/Downrod

assembly

Canopy

Standard mounting

Installing Fan to

the Electrical Box

1. Pass the 120-volt supply wires through the

center hole in the ceiling mounting bracket

as shown in Figure 14.

2. Install the ceiling mounting bracket on the

electrical box by using the mounting screws

provided with the electrical box. Note that

the at side of the mounting bracket is

toward the electrical box. (Figure 14)

3. Tighten the two screws on the electrical box

securely.

4. Carefully lift the fan assembly up to the

ceiling mounting bracket. Make sure the tab

on the mounting bracket is properly seated

in the groove in the hanger ball. (Figure 15)

WHEN USING THE STANDARD BALL/DOWNROD

MOUNTING, THE TAB IN THE RING AT THE

BOTTOM OF THE MOUNTING BRACKET MUST

REST IN THE GROOVE OF THE HANGER BALL.

FAILURE TO PROPERLY SEAT THE TAB IN THE

GROOVE COULD CAUSE DAMAGE TO WIRING.

Listed

Electrical

Box

Ceiling

Mounting

Bracket

Hook

120V Wires

Washer

Mounting

Screws

(Supplied with

Electrical Box)

Figure 14

Figure 15

Inhaltsverzeichnis

Andere Progress Lighting Lüfter Handbücher

Progress Lighting

Progress Lighting AirPro P250000 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250062 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P2554 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250102 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250060 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P2574-8030K Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250075 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250089 Bedienungsanleitung

Progress Lighting

Progress Lighting P2550 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro Trevina II P2555 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro Schaal P250101 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P2599 Bedienungsanleitung

Progress Lighting

Progress Lighting Springer P260004 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250030 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250006 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250069 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P2540 Bedienungsanleitung

Progress Lighting

Progress Lighting EF200D Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250061 Bedienungsanleitung

Progress Lighting

Progress Lighting Air Pro P2525 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250065 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro P250108 Bedienungsanleitung

Progress Lighting

Progress Lighting P2529 Bedienungsanleitung

Progress Lighting

Progress Lighting AirPro Claret P250007 Bedienungsanleitung

Beliebte Lüfter Handbücher anderer Marken

ELTA FANS

ELTA FANS H03VV-F Bedienungsanleitung

Hunter

Hunter 20714 Gebrauchsanweisung

Emerson

Emerson CARRERA VERANDA CF542ORB00 Bedienungsanleitung

Hunter

Hunter Caraway Gebrauchsanweisung

Panasonic

Panasonic FV-15NLFS1 Bedienungsanleitung

Kompernass

Kompernass KH 1150 Bedienungsanleitung

VES

VES FALA100/12V/TR Bedienungsanleitung

Vertiv

Vertiv Liebert DCD Bedienungsanleitung

Westinghouse

Westinghouse GFP Series Bedienungsanleitung

Venmar

Venmar KUBIX HRV PLUS Series Bedienungsanleitung

Maico

Maico ECR 31 Bedienungsanleitung

Sonnenkonig

Sonnenkonig Dinky Bedienungsanleitung

S&P

S&P ECOWATT HXBR Bedienungsanleitung

Wider

Wider IMP03369BH Bedienungsanleitung

Panasonic

Panasonic F-60DHN Bedienungsanleitung

Hinkley

Hinkley HIGHLAND Bedienungsanleitung

Broan

Broan 766BN Bedienungsanleitung

Premium

Premium PFS16022 Montageanleitung
