PUIG 6805 Bedienungsanleitung
MOTOPLASTIC, S.A.
Molí de la sal, 1 - 08403 Granollers (Barcelona) SPAIN
Tel. 34 93 849 06 33 - Fax 34 93 849 09 88
www.puig.tv
-
www.puigusa.com
INSTRUCCIONES DE MONTAJE - MOUNTING INSTRUCTIONS - MONTAGEANLEITUNG
DESCRIPCIÓN DESCRIPTION
ID. PIEZA / PART QTY.
Created by: www.ciandisseny.com
TAPAS LATERALES ADAPTABLES A - INFILL PANELS ADAPTABLE TO
BMW R1200GS/RALL./EXC. - R1250GS/HP
Ref.: 6805
Juego de tapas laterales
Soporte metálico derecho
Soporte metálico izquierdo
Silemblock Ø int. 9,6 Ø ext. 23x9
Tornillo Allen M5x16 ISO 7380 cabota Ø9mm
PERFIL PVC 1048 negro autoadhesivo
(se entrega montado)
Silemblock M5
Infill panels
Right metal support
Left metal support
Silemblock Ø inner 9,6 Ø outer 23x9
M5x16 ISO 7380 Allen screw - Head Ø9mm
Self-adhesive black PROFILE PVC 1048
(supplied mounted)
M5 Silemblock
1
1
1
4
2
4
2
1
2
3
4
5
7
6
21
Pg. 1/2
Tornillos originales
Original screws
4
4
3
1
2
MOTOPLASTIC, S.A.
Molí de la sal, 1 - 08403 Granollers (Barcelona) SPAIN
Tel. 34 93 849 06 33 - Fax 34 93 849 09 88
www.puig.tv
-
www.puigusa.com
INSTRUCCIONES DE MONTAJE - MOUNTING INSTRUCTIONS - MONTAGEANLEITUNG
Created by: www.ciandisseny.com
4
5
TAPAS LATERALES ADAPTABLES A - INFILL PANELS ADAPTABLE TO
BMW R1200GS/RALL./EXC. - R1250GS/HP
3
Pg. 2/2
Tornillos originales
Original screws
Tapa izquierda
Left infill
Tapa derecha
Right infill
1
1
5
6
7
7
7
7
