JA-103
User's Manual
CONTENT
01
Before you use the electrolysis water ionizer, please read the following
notices carefully and adhere to them during the use of it, or it is possible
to damage the machine and your family's health.
È È Ë ®
¾ ƾ «¾ ƾ «
1Do not use turbid water like well,
underground, or heavy metal polluted
water.
2Do not connect any containers or
0
machines with hot water above 40 C,
minor damage can occur.
3Do not use aluminum or copper made containers to prevent the machine
from rusting or discoloring.
4Do not wash the machine with water directly, and do
not use volatile solvents as alcohol to clean the
machine body. Please wipe it with a soft cloth or
soaked cloth with soap water.
5Please replace the filter regularly.
6Do not disassemble the machine. Do not block, curve and twist water
inlet/outlet tube. During using the machine, do not hang high acidic water
tube for getting remaining water out of the tube.
Attention
02
7Please prevent the machine from extreme bumping or shaking, andavoid
heavy heat and strong sunlight.
8Please pour water into the machine every day
prior to using it.
9Please drink ionized water generated by electrolysis
as soon as possible. (Under a sealed condition, the
period of water efficiency keeps one day long in
normal atmosphere temperature, and two days if
fridge freezed)
10 Do not use ionized water to breed goldfish or tropical fish, in case the
cause of death.
11 Do not use take medicine with alkaline ionized
water, you should use purified water.
12 Do not drink acidic water; it is used for beautifying
the face and skin.
13 Please disconnect the power supply when the machine is not in use for a
long period of time.
Attention
CLEAN
FILTER
CHANGE
STRONG
MINOR
PURE
WATER
STRONG
MAKING FOODS
COOKING STAFF
DAILYDRINKING
RICE COOKING
MAKING TEA
INITIAL PERIOD
DRINKING
TAKEMEDICINE
MILK
BEAUTYAND
COSMETICS
FACECLEANING
STRONG
ACID
JA-103
10.09.08.07.06.05.04.0
IONIZED ALKALINE WATER
PRO
P
URE
DRINKING WATER SYSTEM
ALKALINE
ACID
03
Operation panel
Water drain hose
Alkaline water
Acidic water
Power supply cable
Preparation
Tap water input
Acidic water output port
Power supply cable
Flexible Hose
Simply cut a sufficient length of hose to reach "acidic water output" port. Allow
some extra length in the event of acidic water to be collected for external or
plant use.
Flexible hose
Output port for connection
04
Accessories
Snake Hose x 1
1 2 Hose Clip x 2
4Hanging Fixture 1x 6
3
PH Testing Liquid
10ml
5
Water Inlet / Outlet
Hose x 2
Suction Used to Fix
Water Drain Hose
Ionizer accessories
Top assembly
1 2 Connection valve
3Washer x 2
1
Filter
4
Double threaded
joint
Top accessories Optional accessories
(When the lightis on,
please press startbutton to
begin intense internal
cleaning; the machinewill
begin cleaning
automatically when it's
filled with 60Lwater)
CLEAN
FILTER
CHANGE
STRONG
MINOR
PURE
WATER
STRONG
MAKING FOODS
COOKING STAFF
DAILY DRINKING
RICE COOKING
MAKING TEA
INITIAL PERIOD
DRINKING
TAKE MEDICINE
MILK
BEAUTY AND
COSMETICS
FACE CLEANING
STRONG
ACID
JA-103
10.0
9.08.0
7.06.05.04.0
IONIZED ALKALINE WATER
PRO
P
URE
DRINKING WATER SYSTEM
ALKALINE ACID
Acidic Water
Selection Button
Replacement/life
Cleaning Button
(Select different intensity alkaline
water according todifferent needs)
Alkaline Water Selection Button
Panel Operations and Functions
î Ñ° ×½ ð
Purified Water
Selection Button
05
(Filter Cartridge
Replacement
Indicator When
replacement light
goes on, itindicates
the filter's lifeis
over. Replacement
Signal Reset Button)
1. Generation of Alkaline Water: turn the tap on and water
flows into the machine. During puocessing back light goes
on, buzzer beeps 3 times and arrow indicator points toward
Alkaline water. Press the selection button for the required
PH level. With different press, PH value size varies. Purple
colored back light represents heavy alkaline, blue colored
back light represents everyday drinking alkaline.
2. Generation of purified Water: when the button is pressed,
water flows into the machine. Arrow indicator points toward
purified water, buzzer beeps 3 times; both alkaline and acidic
water outlet are without electrolysis (green colored back light
goes on ). After the tap is closed for about 1 minute, back
light goes off and the everyday drinking button is
automatically triggered on by default.
3. Generation of Alkaline Water: when the button is pressed,
water flows into the machine. Buzzer beeps continuously
(back light becomes red). Arrow indicator points toward
Acidic. Press the selection button for the required PH level.
With different press, PH value size varies. After the tap is
closed for about 1 minute, back light goes off and the
veryday drinking button is automatically triggered on by
default.
Notice: when alkaline calcium ionized water generation stops each time,
computer in the machine automatically performs internal cleaning. When
done, back light goes off, the machine is in a state of power saving.
Alkaline Water
Purified Water
Acidic Water
Generation fo Calcium Ionized Water
06
07
1
2-layer
screw tooth
2345
Way1
If the tap your family has
is similar to this pattern
(as the above picture)
If the water outlet is internal screw thread (the
below picture 1)
1.At first combine 2-layer screw tooth with the
water separator, then screw them tight
(procedure 1,2,3).
2.Unscrew the waver of the tap (procedure 4).
3.The set of water separator equipped with the
gasket is fixed to the tap, then screw tight
(procedure 5).
According to your own habits, the handle of
the alternative switch can fasten left or right.
If the water outlet is external screw thread (as
the left picture 2), installation procedures:
unscrew the waver of the tap, then screw the
alternative switch.
If the tap your family has is
a different pattern (as the
above picture)
Procedures:
1.First place the installation
ring.
2.Select internal socket ring,
fit over the tap.
3.Use fixtures to fasten.
Lock the alternative switch.
If the water outlet is external screw thread
(as the left picture 2), installation
procedures: unscrew the waver of the tap,
then screw the alternative switch.
Way2
Water SEPARATOR Fix the tap to
the Water SEPARATOR
Unscrew the
water of tap
Combine and screw
the waver of tap
1 2
Unscrew the
water of tap
Screw the
alternative switch
Installation
Alternative Switch
Fix the tap to
the Water SEPARATOR
08
CLEAN
FILTER
CHANGE
STRONG
MINOR
PURE
WATER
STRONG
MAKING FOODS
COOKING STAFF
DAILYDRINKING
RICE COOKING
MAKING TEA
INITIAL PERIOD
DRINKING
TAKEMEDICINE
MILK
BEAUTY AND
COSMETICS
FACE CLEANING
STRONG
ACID
JA-103
10.09.08.07.06.05.04.0
IONIZED ALKALINE WATER
PRO
P
URE
DRINKING WATER SYSTEM
ALKALINE ACID
Stainless steel outlet hose
for alkaline water
Controls panel
Faucet
Hose clamp
Quick fitting
Flexible hose
for connection
Acidic water hose
Power cord connection
(Lenght: 1.5M)
Plug
Illustration
Installation
09
Replacement of Filter Cartridge
Cleaning
Button
When using 50L water, indicating light goes on, which means to require
cleaning. It can be adjusted according to different water condition in regions.
The procedures are as follows:
When waiting, 1.press and hold "purified Water Selection" button for 5 seconds,
water flow volume 50L is revealed on the top left-hand part of the screen.
2.Adjustable range is from 30L to 90L by use of "cleaning" button or
"replacement" button (plus or minus). 3.After range adjustment is over, press
"cleaning" button once again, so the setrp is completed.
ACF Feature activated carbon pores structure
1.When replacement light
goes on, the filter
cartridge has exceeded
total water flow volume;
it must be replaced
immediately to ensure
electrolysis water quality.
2.After the filter cartridge
is replaced, press and
hold Replacement Signal
Reset Button for 3
seconds. When you hear a
long hua sound and
replacement light goes
off, release the button.
î Ñ° ×½ ð
When intense cleaning
light is on, please turn
the tap on, press start
button, cleaning light
flickers and music is
played. After cleaning is
done, cleaning light
goes off, music stops,
the everyday drinking
button is selected by
default.
(High-technology long-life coconut shell fiber activated filter cartridge)
Type of Material: silver fiber coc
onut shell activated carbon
Flowing Rate: 5.0L/Minute
Purifying Capacity: take away
salty particle residue
Flowing Volume: about 12000L
Remove foul and bad odor
Replacement
Signal Rest
Button
